SOLTEK SL-65F+ User Manual And Technical Manual page 32

65F+ BIOS
UART Mode Select
UART2 Duplex Mode
RxD, TxD Active
IR Transmission Delay
Onboard Paralle Port
Parallel Port Mode
ECP Mode Use DMA
EPP Mode Select
32
Choose Standard (default), HPSIR or ASKIR.
Choose Half (default) or Full.
Choose Lo,Lo (default) / Lo,Hi / Hi,Hi / Hi,Lo.
Enabled: Enable delay when transferring data.
Disabled (default): Disable delay when transferring data.
Choose the printer I/O address: 378H/IRQ7 (default), 3BCH/
IRQ7, 278H/IRQ5 or Disabled.
Choose Normal (default), ECP/EPP, SPP mode. The mode
depends on the external device connected to this port.
Choose DMA3 (default) or DMA1. Most sound cards use
DMA1. Check with your sound card configuration to make
sure that there is no conflict with this function.
Choose EPP1.7 (default) or EPP1.9. EPP1.9 supports hard-
ware handshake. This setting is dependent upon your EPP
device.
