SOLTEK SL-65MIV-C User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
T h e
S o u l
O f
C o m p u t e r
T e c h n o l o g y
SL-65MIV-C/65MIV2
USER MANUAL V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-65MIV-C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOLTEK SL-65MIV-C

Summary of Contents for SOLTEK SL-65MIV-C

  • Page 1 T h e S o u l C o m p u t e r T e c h n o l o g y SL-65MIV-C/65MIV2 USER MANUAL V1.2...
  • Page 2 In no event shall Soltek Computer inc. be liable for any loss or profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or con- sequential damages of any kind, even if Soltek Computer inc.
  • Page 3 SOLTEK AROUND THE WORLD SOLTEK COMPUTER INC. Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei- Hsien, Taiwan, R.O.C. Telephone : 886-2-2642-9060 : 886-2-2642-9065 E-mail : sales@soltek.com.tw Web site : http://www.soltek.com.tw SOUL TECHNOLOGY EUROPE B.V. Address : Hongkongstraat 55 3047 BR, Rotterdam, The...

  • Page 4: Table Of Contents

    65MIV-C / 65MIV2 C O N T E N T CHAPTER 1 INTRODUCTION ........8 1- 1 MAINBOARD SPECIFICATION ........... 9 1-1-1 CPU ..................... 9 1-1-2 CHIPSET ..................... 9 1-1-3 AWARD BIOS V6.0, SUPPORTING ........... 9 1-1-4 EXPANSION SLOTS ................9 1-1-5 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER ....
  • Page 5 Content 2-5-1 JUMPER JBAT1 FOR CLEARING CMOS DATA: ......24 2-5-2 JP4/JP5 USB PORT SELECT ............25 2-5-3 JP9 POWER LOST RESUME ............25 2-6 CONNECTORS CONFIGURATIONS ......... 26 2-6-1 ONBOARD FAN (JFAN1/JFAN2) ............26 2-6-2 CD-ROM AUDIO CONNECTOR (JCD1/JCD2) ......... 27 2-6-3 WAKE ON LAN FUNCTION (WOL1) ..........
  • Page 6 65MIV-C / 65MIV2 4-4 WHAT IS POST ................54 4-5 BIOS UPGRADE ................. 54 4-5-1 BEFORE UPGRADING BIOS ............55 4-5-2 UPGRADE PROCESS ..............55 4-6 BIOS SETUP-- CMOS SETUP UTILITY ........59 4-6-1 STANDARD CMOS SETUP .............. 60 4-6-2 ADVANCED BIOS FEATURES ............63 4-6-3 ADVANCED CHIPSET FEATURES ..........
  • Page 7 Content ====== ITEMLIST CHECKUP Mainboard Support CD User’s Manual Bundled Bonus Pack CD Bundled Bonus Pack Manual Temperature Sensor Cable (for 65MIV2 only) ATA66/100 IDE Cable RS232 Cable FDD Cable...

  • Page 8: Chapter 1 Introduction

    65MIV-C / 65MIV2 CHAPTER INTRODUCTION • This chapter briefly introduces the characteristics of this mainboard. It includes the information regarding the chipset, CPU types, built-in functions and layout. Users will have more ideas about mainboards after reading this chapter. THIS CHAPTER CONTAINS THE FOLLOWING TOPICS : 1-1 MAINBOARD SPECIFICATION 1-2 MAINBOARD LAYOUT 1-3 CHIPSET DIAGRAM...

  • Page 9: Mainboard Specification

    Chapter1 Introduction 1- 1 MAINBOARD SPECIFICATION 1-1-1 CPU ® ® • Supporting Intel FC-PGA370 Pentium III up to 1GHz. • Supporting Celeron & PPGA370 Celeron processors up to 850MHz. • Supporting VIA Cyrix III processors up to 800MHz. • Supporting 66 to 200 MHz system bus speed. •...

  • Page 10: Integrated Savage4 2D/3D/Video Accelerator

    65MIV-C / 65MIV2 • Two UART’s for Complete Serial Ports. • One dedicated IR connector: --- A third serial port dedicated to IR function either through the two complete serial ports or the third dedicated port Infrared-IrDA (HPSIR) and ASK (Amplitude Shift Keyed) IR.

  • Page 11: Form Factor

    Chapter1 Introduction • Supporting Wake On LAN (WOL) & Wake On Modem. • Supporting real time clock (RTC) with date alarm, month alarm, and cen- tury field. 1-1-11 FORM FACTOR • ATX form factor, 4 layer PCB. • Mainboard size: 22.0cm X24.5cm. 1-1-12 HARDWARE MONITORING •...

  • Page 12: Mainboard Layout

    65MIV-C / 65MIV2 1-2 MAINBOARD LAYOUT 1-2-1 MAINBOARD LAYOUT --- 65MIV-C • Default Setting: Intel Celeron 300A/66 MHz VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C 686A PCI 3 JCD1 JCD2 WOL1...

  • Page 13: Mainboard Layout

    Chapter1 Introduction 1-2-2 MAINBOARD LAYOUT --- 65MIV2 • Default Setting: Intel Celeron 300A/66 MHz VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C 686B PCI 3 JCD1 JCD2 WOL1...

  • Page 14: Chipset Diagram

    65MIV-C / 65MIV2 1-3 CHIPSET DIAGRAM • The VT8605 is a high performance, cost-effective and energy efficient SMA chip set for the implementation of AGP / PCI / LPC desktop personal com- puter system with 66MHz, 100MHz, and 133MHz CPU host bus (“Front Side Bus”) frequencies and based on 64-bit Socket-370 (Intel Pentium III, Celeron) super-scalar processors.

  • Page 15: High Screen Resolution Crt Support

    Chapter1 Introduction 1-4 HIGH SCREEN RESOLUTION CRT SUPPORT System Memory Frame Buffer Size (8MB Default) Resolution Supported 640x480x8 /16/ 32 16/32MB 800x600x8 /16/ 32 1024x768x8 /16/ 32 1280x1024x8 1280x1024x16 1280x1024x32 1600x1200x8 1600x1200x16 1600x1200x32 1920x1440x8 1920x1440x16 High Screen Resolution CRT Support...

  • Page 16: Motherboard Specification Table

    65MIV-C / 65MIV2 1-5 MOTHERBOARD SPECIFICATION TABLE Model 65MIV-C 65MIV2 North bridge VIA VT8605 South bridge VIA VT82C686A VIA VT82C686B Supports PC133 and PC100 SDRAM and Virtual Channel Memory Memory (VCM) up to 1.5GB 3 DIMM Slots AGP Interface AGP 4X Mode On-chip S3 SAVAGE 4 AGP 4X Graphics...
  • Page 17 Chapter1 Introduction MEMO...

  • Page 18: Chapter 2 Hardware Setup

    65MIV-C / 65MIV2 CHAPTER HARDWARE SETUP ATTENTION !!! 1. Please refer to your processor installation or other documentation attached with your CPU for more detailed installing instruction. 2. Installing a heat sink and cooling fan is necessary for proper heat dissipation from your CPU. Incorrect installation may result in overheating and damage of your CPU.

  • Page 19: Cpu Installation

    Chapter2 Hardware Setup 2- 1 CPU INSTALLATION WARNING !!! Never run you processor without the heat sink properly and firmly attached. PERMANENT DAMAGE WILL RESULT! • Pull out the lever from the socket, and then raise the le- ver up to a 90-degree angle. •...

  • Page 20: Memory Installation

    65MIV-C / 65MIV2 2- 2 MEMORY INSTALLATION WARING !!! • Make sure that you unplug your power supply when adding or removing memory modules or other system components, failure to do so may cause severe damage to both your mainboard and expansion cards. •...

  • Page 21: Hdd/Fdd Installation

    Chapter2 Hardware Setup 2- 3 HDD/FDD INSTALLATION • To install HDD (Hard Disk Drive), you may connect the cable’s blue connector to the mainboard’s primary (IDE1) or secondary IDE connector, and then connect the gray connector to your slave device and the black connector to your master device.
  • Page 22 65MIV-C / 65MIV2 • To install FDD (Floppy Disk Drive), connect the end with single connector to the mainboard, and connect other end with two connectors to the floppy drives. Floppy Disk Drive Connector: Orient the red line on the floppy ribbon cable to Pin1.

  • Page 23: Cpu Bus Ratio Select

    Chapter2 Hardware Setup 2-4 CPU BUS RATIO SELECT • Normally, the Bus Ratio (Frenquency Multiple) of your processor is locked by processor’s Vendor, setting of the CPU Bus Ratio will have no effect. • Bus Ratio exceed 8.0X, user can not change all values from DIP switch the Bus ratio will be detected by BIOS automatically.

  • Page 24: Jumper Setting For Devices On Board

    65MIV-C / 65MIV2 2- 5 JUMPER SETTING FOR DEVICES ON BOARD: • The following diagrams show the location for jumper blocks on the mainboard. CAUTION • Do not remove the jumper when power is on. Always make sure the power is off before changing any jumpers.

  • Page 25: Jp4/Jp5 Usb Port Select

    Chapter2 Hardware Setup 2-5-2 JP4/JP5 USB PORT SELECT Redirect USB port 2 to USB 2 connector (default) Redirect USB port 2 to AGP VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C...

  • Page 26: Connectors Configurations

    65MIV-C / 65MIV2 2-6 CONNECTORS CONFIGURATIONS • This section lists out all connectors configurations for users’ reference: 2-6-1 ONBOARD FAN (JFAN1/JFAN2) CPU FAN JFAN1 SYSTEM FAN JFAN2 VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 +12V JBAT1 PCI 2...

  • Page 27: Cd-Rom Audio Connector (Jcd1/Jcd2)

    Chapter2 Hardware Setup 2-6-2 CD-ROM AUDIO CONNECTOR (JCD1/JCD2) PIN NO. JCD1 JCD2 PIN 1 Left Channel Left Channel PIN 2 PIN 3 Right Channel PIN 4 Right Channel VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2...

  • Page 28: Thermal Sensor Connector (Rt2) -- For 65Miv2 Only

    65MIV-C / 65MIV2 2-6-4 THERMAL SENSOR CONNECTOR (RT2) --- FOR 65MIV2 ONLY VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C 686B PCI 3 JCD1 JCD2 WOL1 We provide a thermal cable in the mainboard package. This thermal cable is to monitor device which will generate a lot of heat, such as HDD, graphics card etc..

  • Page 29: Header J2&J3

    Chapter2 Hardware Setup 2-6-5 HEADER J2&J3 • Header J2&J3 includes seven connectors for different functions: A1 : 1st HDD LED A2 : 2nd HDD LED A1 A2 B : INFRARED (IR) C : POWER SWITCH D : SMI E : SPEAKER F : RESET SWITCH G : POWER LED H : NONE...
  • Page 30 65MIV-C / 65MIV2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 INFRARED CONNECTOR PIN 6 INFRARED TRANSMIT SIGNAL PIN 7 PIN 8 INFRARED RECEIVE SIGNAL PIN 9 NONE PIN 10 This connector supports an optional wireless transmitting and receiving infrared module.
  • Page 31 Chapter2 Hardware Setup 1 2 3 4 5 6 7 8 9 10 11 12 13 SMI CONNECTOR PIN 14 SMI(System Managment Interrupt) SIGNAL PIN 15 This allows user to manually place the system into a suspend mode or "Green" mode, where system activity is decreased to save electricity and prolong the life of certain components when the system is not in use.
  • Page 32 65MIV-C / 65MIV2 1 2 3 4 7 8 9 10 11 12 13 14 15 RESET SWITCH CONNECTOR PIN 5 RESET SIGNAL PIN 6 RESET SWITCH connector connects to the case- mounted reset switch for rebooting your system DESCRIPTION without having to turn off your power switch.

  • Page 33: Chassis Panel Connector

    Chapter2 Hardware Setup 2-6-6 CHASSIS PANEL CONNECTOR A : PS/2 MOUSE PORT B : USB 0 PORT C : LPT1 PORT D : GAME/MIDI PORT E : PS/2 KEYBOARD PORT F : USB 1 PORT G : COM1 PORT H : VGA PORT : LINE / SPEAKER OUT J : LINE IN K : MICROPHONE INPUT...

  • Page 34: Atx Power Supply Connector

    65MIV-C / 65MIV2 2-6-7 ATX POWER SUPPLY CONNECTOR • This connector is connected to an ATX power supply by a plug from the power supply. The plug can only be inserted in a specific orientation be- cause of the different hole sizes. Find the proper orientation and push down the plug firmly to make sure that all pins are aligned.

  • Page 35: Second Usb Header (Usb2)

    Chapter2 Hardware Setup 2-6-9 SECOND USB HEADER (USB2) • This header is for the additional USB cable to provide you two additional USB ports. Users can order the additional USB cable from your mainboard dealers or venders. Additional USB Cable (Optional) Black Black Green...

  • Page 36: Serial Port Connector

    65MIV-C / 65MIV2 2-6-10 SERIAL PORT CONNECTOR • The first serial port COM1 is ready for a mouse or other serial devices. The second serial port COM2 is available by using a RS232 serial cable con- necting from the mainboard to an expansion slot opening. COM2 PIN1 VT8605...

  • Page 37: Flat-Panel Display Connector (Dvc1) -- For 65Miv2 Only

    Chapter2 Hardware Setup 2-6-11 FLAT-PANEL DISPLAY CONNECTOR (DVC1) --- 65MIV2 ONLY • This motherboard provides a special socket “ DVC1 ”. Which has the capa- bility of displaying graphics on TFT flat panel desktop monitors using a 12- bit digital interface to an external encoder. The motherboard also supports auto expansion and centering of all VGA text and graphics modes to en- sure that the entire flat panel display will be utilized.

  • Page 38: Irqs Description For Various Devices

    65MIV-C / 65MIV2 2-6-12 IRQs DESCRIPTION FOR VARIOUS DEVICES Function Description Priority IRQ 0 System Timer IRQ 1 Keyboard Controller IRQ 2 Programmable Interrupt IRQ 3 Serial Port (COM 2) IRQ 4 Serial Port (COM 1) IRQ 5 IRQ 6 Floppy Disk Controller IRQ 7 Parallel Port (LPT1)
  • Page 39 Chapter2 Hardware Setup MEMO...
  • Page 40 65MIV-C / 65MIV2 MEMO...

  • Page 41: Chapter 3 Software Setup

    Chapter3 Software Setup CHAPTER SOFTWARE SETUP ABOUT SUPPORT CD • In Support CD, it contains most information for users’ requirement, such as Acrobat Reader, BIOS, Users’ full version Manual, Driver, Hardware Monitor (if motherboard supports this function), Patch, and Utilities etc., User can browse the CD and get further details in regard of our motherboard.

  • Page 42: Via Chipset Driver Installation (4-In-1 Driver)

    65MIV-C / 65MIV2 3-1 VIA CHIPSET DRIVER INSTALLATION (4-IN-1 DRIVER) • Please put the Support CD • Click on the “VIA Chipset into the CD-ROM drive. Driver”. • When a welcome window appears on the screen, choose “Install Driver”. • Click on the “4-in-1 driver”. •...
  • Page 43 Chapter3 Software Setup • Press select the checkbox as below: Bus Master PCI IDE Driver AGP VxD Driver VIA Chipset Function’s Registry Next IRQ Routing Miniport Driver Note: For users who are upgrading VIA Drivers, we recommend to install the 4-in-1 as it will automatically detect and update the necessary drivers.
  • Page 44 65MIV-C / 65MIV2 • Select “Install VIA AGP VxD” in turbo mode and press Next button to continue. Next • Select “Install VIA IRQ Routing Miniport Driver” checkbox, then click the “Next” button to continue. Next • After all these setup proce- dures have finished, please restart your computer by clicking on Finish.

  • Page 45: On Board Vga Driver Installation

    Chapter3 Software Setup 3-2 ON BOARD VGA DRIVER INSTALLATION • We provide a simple process for user to install VGA driver. Whichever Microsoft Windows operating system user adopts, the installations are simi- lar to each other as shown below. 3-2-1 INSTALL PM133 VGA DRIVER FOR WINDOWS 95/ 98/98SE •...

  • Page 46: Install Pm133 Vga Driver For Windows Me

    65MIV-C / 65MIV2 • Click on the “VIA PM133 • Click on the “Install VGA VGA Driver” to continue. Driver for NT4.0”. • Follow the instruction on screen to complete the installation, after which please restart your PC. 3-2-3 INSTALL PM133 VGA DRIVER FOR WINDOWS ME •...

  • Page 47: Install Pm133 Vga Driver For Windows 2000

    Chapter3 Software Setup 3-2-4 INSTALL PM133 VGA DRIVER FOR WINDOWS 2000 • Please put the Support CD • Click on the “VIA chipsets into the CD-ROM drive. Driver”. • When a welcome window appears on the screen, choose “Install Driver”. •...

  • Page 48: Ac97 Audio Codec Driver Installation

    65MIV-C / 65MIV2 3-3 AC97 AUDIO CODEC DRIVER INSTALLATION • Please put the Support CD • Click on the “VIA chipsets into the CD-ROM drive. Driver”. • When a welcome window appears on the screen, choose “Install Driver”. • Click on the “AC’97 driver”. •...
  • Page 49 Chapter3 Software Setup • Please click the “Finish” button to complete setup. Finish...

  • Page 50: Hardware Monitor Driver Installation

    65MIV-C / 65MIV2 3-4 HARDWARE MONITOR DRIVER INSTALLATION • Please put the Support CD • Click on the “VIA chipsets into the CD-ROM drive. Driver”. • When a welcome window appears on the screen, choose “Install Driver”. • Click on the “Hardware Monitor Utility”.
  • Page 51 Chapter3 Software Setup • Press Next button to finish the Hardware Monitor setup process.
  • Page 52 65MIV-C / 65MIV2 MEMO...

  • Page 53: Chapter 4 Bios Setup

    Chapter4 BIOS Setup CHAPTER BIOS SETUP THE BIOS • BIOS stands for Basic Input and Output System. It is sometimes called ROM BIOS because it is stored in a Read-Only Memory (ROM) chip on the mainboard. BIOS is the first program to run when you turn on your computer. •...

  • Page 54: What Is Bios Setup

    65MIV-C / 65MIV2 4-1 WHAT IS BIOS SETUP • BIOS Setup is an interactive BIOS program that you need to run when: 1. Changing the hardware of your system. (for example: installing a new Hard Disk etc..) 2. Modifying the behavior of your computer. (for example: changing the sys- tem time or date, or turning special features on or off etc..) 3.

  • Page 55: Before Upgrading Bios

    Chapter4 BIOS Setup replace an EPROM component. • The upgrade utility can be loaded on a floppy diskette and used to provide the capability to save, verify, and update the system BIOS. The upgrade utility can also be run from a hard disk drive or a network drive. 4-5-1 BEFORE UPGRADING BIOS •...
  • Page 56 65MIV-C / 65MIV2 specific mainboard.) Step 5. Please press <F1> or <F10> to exit or reset your system, Warning ! If the message “Write Fail” appears while Award “FLASH MEMORY WRITER” is verifying Flash memory, just repeat the process. Please DO NOT reset or turn off the system.
  • Page 57 Chapter4 BIOS Setup Figure 4-5-1 Award Flash Memory Writer Start Screen Figure 4-5-2 Award Flash Memory Writer Complete Screen...
  • Page 58 65MIV-C / 65MIV2 The parameters of AWDFLASH.EXE /sn: No original BIOS backup /py: Program flash memory /cc: Clear CMOS data (and update data automatically) after programming NOTE: Users can type AWDFLASH /? to get further details about the parameters. Incorrect usage of the parameter will damage the BIOS information, so we strongly recommend users to leave parameters alone unless you fully understand their function.

  • Page 59: Bios Setup-- Cmos Setup Utility

    Chapter4 BIOS Setup 4-6 BIOS SETUP CMOS SETUP UTILITY • This VIA PM-133 mainboard comes with the AWARD BIOS from AWARD Software Inc. Enter the CMOS Setup Utility Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 60: Standard Cmos Setup

    65MIV-C / 65MIV2 4-6-1 STANDARD CMOS SETUP • Standard CMOS Setup records some basic system hardware configuration and sets the system clock and error handling. You only need to modify the configuration values of this option if you want to change your system hard- ware configuration or when the data stored in the CMOS memory gets lost or damaged.
  • Page 61 Chapter4 BIOS Setup Date (mm:dd:yy) The BIOS determines the day of the week from the other date information. This field is for information only. Press the left or right arrow key to move to the de- sired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the de- sired value into the field.
  • Page 62 65MIV-C / 65MIV2 Halt On Set this warning feature for the type of errors that will cause the system to halt. The choices are: All Errors; Post stops for all error. No Errors; Post does not stop for any error. All, But Keyboard;...

  • Page 63: Advanced Bios Features

    Chapter4 BIOS Setup 4-6-2 ADVANCED BIOS FEATURES • ADVANCED BIOS FEATURES improves your system performance or sets up system features according to your preference. Run the ADVANCED BIOS FEATURES as follows: 1. Choose “ADVANCED BIOS FEATURES” from the Main Menu and a list of options will appear: 2.
  • Page 64 65MIV-C / 65MIV2 CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced BIOS Features Item Help Virus Warning Disabled Menu Level Enabled CPU Internal Cache Enabled External Cache Enabled CPU L2 Cache ECC Checking Disabled Process or Number Feature Enabled Quick Power On Self Test Floppy...
  • Page 65 Chapter4 BIOS Setup Virus Warning Enabled: Activates automatically when the system boots up showing a warning message if anything attempts to access the boot sec- tor or hard disk partition table. Disabled: No warning message will appear when there is something attempting to access the boot sector or hard disk partition table.
  • Page 66 65MIV-C / 65MIV2 First/Second/Third/ The BIOS attempts to load the operating system from Other Boot Device the devices in the sequence selected in these items. The choices: Floppy; LS/ZIP; HDD; SCSI; CDROM; Disabled. Swap Floppy Drive When enabled, floppy drives A and B will be exchang- ing without any physical connection and modification on the cables.
  • Page 67 Chapter4 BIOS Setup Typematic Delay Choices: 250; 500; 750; 1000. This option sets the (Msec) time interval for displaying the first and the second characters. If enabled, the time interval is optional. Security Option If you have set a password, select whether the pass- word is required every time the System boots, or only when you enter setup.

  • Page 68: Advanced Chipset Features

    65MIV-C / 65MIV2 4-6-3 ADVANCED CHIPSET FEATURES • ADVANCED CHIPSET FEATURES is used to modify the values of chipset registers. These registers control the system options. Run the ADVANCED CHIPSET FEATURES as following: 1. Choose “ADVANCED CHIPSET FEATURES” from the Main Menu and a list of options will appear: 2.
  • Page 69 Chapter4 BIOS Setup CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced Chipset Features Item Help DRAM Timing by SPD Disabled Menu Level DRAM Clock Host CLK SDRAM Cycle Length Bank Interleave Disabled DRAM Drive Strength Auto DRAM Drive Value Memory Hole Disabled P2C/C2P Concurrency...
  • Page 70 65MIV-C / 65MIV2 DRAM Timing by SPD When this item is Enabled, DRAM Timing is set by SPD. SPD (Serial Presence Detect) is located on the memory modules, BIOS reads information coded in SPD during system boot up. DRAM Clock This item allows you to control the DRAM speed. The choices: Host Clock;...
  • Page 71 Chapter4 BIOS Setup Video RAM Cacheable Selecting Enabled allows caching of the video memory (RAM) at A0000h to AFFFFh, resulting in better video performance. However, check your AGP manual to find out if any compatibility problem exists. Frame Buffer size This option allows you select memory size shared to on-chip graphics.
  • Page 72 65MIV-C / 65MIV2 USB Mouse Select Enabled if your system contains a Universal Support Serial Bus (USB) controller and you have a USB mouse. The choices: Enabled; Disabled. OnChip Sound Select Enabled to use the on-chip Audio capability of your system. Most of the following field do not appear when this field is Disabled.
  • Page 73 Chapter4 BIOS Setup AGP Master 1 WS Leave this field at default Read The choice: Enabled, Disabled(default). CPU Vcore Select This item allows users to adjust the CPU Vcore voltage. The instant damage of CPU is due to the wrong Vcore voltage setting, so we highly recommend that user should leave this item to Default setting un- less you fully understand it.

  • Page 74: Integrated Peripherals

    65MIV-C / 65MIV2 4-6-4 INTEGRATED PERIPHERALS • INTEGRATED PERIPHERALS option allows you to get some information inside your system when it is working. Run the INTEGRATED PERIPHERALS as follows: 1. Choose “INTEGRATED PERIPHERALS” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Integrated Peripherals...
  • Page 75 Chapter4 BIOS Setup 2. Use one of the arrow keys to move between options and modify the se- lected options by using PgUp / PgDn / + / - keys. <F1>: “Help” gives options available for each item. <F5>: Get the previous values. These values are the values with which the user starts the current session.
  • Page 76 65MIV-C / 65MIV2 IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/write per sector the drive can support.
  • Page 77 Chapter4 BIOS Setup Onboard Paralle Mode Select an operating mode for the onboard parallel (printer) port. Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes. The choices: SPP; EPP; ECP; ECP + EPP. ECP Mode Use DMA Select a DMA channel for the parallel port for use during ECP mode.

  • Page 78: Power Management Setup

    65MIV-C / 65MIV2 4-6-5 POWER MANAGEMENT SETUP • POWER MANAGEMENT SETUP allows you to set the system’s power saving functions. Run the POWER MANAGEMENT SETUP as follows: 1. Choose “POWER MANAGEMENT SETUP” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Power Management Setup Enabled...
  • Page 79 Chapter4 BIOS Setup ACPI Function Select Enabled only if your computer’s operating sys- tem supports the Advanced Configuration and Power Interface (ACPI) specification. Currently, Windows NT 5.0 support ACPI. • Press <Enter> on the Power Management item, then there appears a list of options for you to configure further setting.
  • Page 80 65MIV-C / 65MIV2 HDD Power Down After the selected period of drive inactivity, the hard disk drive powers down while all other devices re- main active. Doze Mode After the selected period of system inactivity, the CPU clock runs at slower speed while all other devices still operate at full speed.
  • Page 81 Chapter4 BIOS Setup o i t l l i c i t o i t e t i o i t t i r o i t t i n MODEM Use IRQ This determines the IRQ which the MODEM can use. The choices: 3;...
  • Page 82 65MIV-C / 65MIV2 CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Wake Up Events Item Help LPT & COM LPT/COM Menu Level HDD & FDD PCI Master PowerOn by PCI Card Disabled Wake Up On LAN/Ring Disabled RTC Alarm Resume Disabled Date (of Month) Resume Time (hh:mm:ss)
  • Page 83 Chapter4 BIOS Setup Wake Up On LAN/Ring An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awak- ens the system from a soft off state. The choices: Enabled; Disabled. RTC Alarm Resume When Enabled, you can set the data and time at which the RTC (Real Time Clock) alarm awakens the sys- tem from suspend mode.
  • Page 84 65MIV-C / 65MIV2 CMOS Setup Utility - Copyright (C) 1984-2001 Award Software IRQ Activity Monitoring Item Help IRQ 3 (COM2) Enabled IRQ 4 (COM1) Enabled Menu Level IRQ 5 (LPT2) Enabled IRQ 6 (Floppy Disk) Enabled IRQ 7 (LPT1) Enabled IRQ 8 (RTC Alarm) Disabled IRQ 9 (IRQ2 Redir)

  • Page 85: Pnp / Pci Configuration

    Chapter4 BIOS Setup 4-6-6 PNP / PCI CONFIGURATION • PNP/PCI CONFIGURATION allows you to modify the system’s power sav- ing functions. Run the PNP/PCI CONFIGURATION as follows: 1. Choose “PNP/PCI CONFIGURATION” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software PnP/PCI Configurations PNP OS Installed...
  • Page 86 65MIV-C / 65MIV2 PNP OS Installed Select Yes if the system operating environment is Plug-and Play aware (e.g., Windows 95). NOTE: BIOS will automatically disable all PnP resources except the boot device card when you select Yes on Non-PnP operating system. Reset Configuration Normally, you leave this Disabled.
  • Page 87 Chapter4 BIOS Setup DMA Resources Press Enter. Please refer to the list below: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software DMA Resources DMA-0 assigned to PCI/ISA PnP Item Help DMA-1 assigned to PCI/ISA PnP Menu Level DMA-3 assigned to PCI/ISA PnP DMA-5 assigned to PCI/ISA PnP...

  • Page 88: Smartdoc Anti-Burn Shield

    65MIV-C / 65MIV2 4-6-7 SMARTDOC ANTI-BURN SHIELD • This section helps you to get more information about your system including CPU temperature, FAN speed and voltage. It is recommended that you contact your mainboard supplier to get proper values about the setting of the CPU temperature.
  • Page 89 Chapter4 BIOS Setup Current CPU Temp. Shows current CPU temperature. ( for 65MIV2 only ) Current System Temp. Shows current system temperature. ( for 65MIV2 only ) Current CPUFAN1 Shows current CPUFAN1 speed. The fan must pro- Speed vide rotary pulse. (Normally this type of fan has a three-wire connector) Current CPUFAN2 Shows current CPUFAN2 speed.

  • Page 90: Frequency/Voltage Control

    65MIV-C / 65MIV2 4-6-8 FREQUENCY/VOLTAGE CONTROL Run the “FREQUENCY/VOLTAGE CONTROL” as follows: 1. Choose “FREQUENCY/VOLTAGE CONTROL” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Frequency Control Item Help Auto Detect DIMM/PCI CLK Enabled Spread Spectrum...
  • Page 91 Chapter4 BIOS Setup Auto Detect This item allows you to enable/disable to detection of DIMM/PCI CLK DIMM/PCI Clock. The choices: Enabled; Disabled. Spread Spec- This item allows you to enable/disable the spread trum Modulated spectrum modulate. The choices: Enabled; Disabled. CPU Host/PCI This item allows you to select CPU/PCI frequency.

  • Page 92: Load Optimized Defaults

    65MIV-C / 65MIV2 4-6-9 LOAD OPTIMIZED DEFAULTS • When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y / N) ? N ” “Y” is for “Yes”, and “N” is for “No”. •...

  • Page 93: Set Supervisor / User Password

    Chapter4 BIOS Setup 4-6-10 SET SUPERVISOR / USER PASSWORD • These two options allow you to set your system passwords. Normally, the supervisor has a higher priority to change the CMOS setup option than the users. The way to set up the passwords for both Supervisor and Users are as follows: 1.

  • Page 94: Save & Exit Setup

    65MIV-C 4-6-11 SAVE & EXIT SETUP • SAVE & EXIT SETUP allows you to save all modifications you have speci- fied into the CMOS memory. Highlight this option on the Main Menu and the following message appears: “SAVE to CMOS and EXIT (Y/N) ? Y “...

  • Page 95: Appendices

    Appendices APPENDICES THIS CHAPTER CONTAINS THE FOLLOWING TOPICS : APPENDIX-1 TECHNICAL TERMS INTRODUCTION APPENDIX-2 IDENTIFYING BIOS VERSION APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER...

  • Page 96: Appendix-1 Technical Terms Introduction

    65MIV-C APPENDIX-1 TECHNICAL TERMS INTRODUCTION Technical Terms Introduction Tech Term Meaning Accelerated Graphic Port Audio Modem Riser Advanced Communication Riser Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface DIMM Dual Inline Memory Module DRAM...

  • Page 97: Appendix-2 Identifying Bios Version And Bios Part Number

    Appendices APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS PART NUMBER When you boot up your computer, you may see a screen which tells your computer is phoenixnet™ enabled, please see the example below. When the main screen Figure1 shows up, press “Tab” key to display BIOS information (Figure2).
  • Page 98 65MIV-C Figure2 shown below displays the BIOS version and BIOS part number identification. Figure 2 BIOS VERSION example: REV T2.1 BIOS ID STRING example: 6A69RSNCC...

  • Page 99: Appendix-3 Identifying Mainboard \ Model Number

    Appendices APPENDIX-3 IDENTIFYING MAINBOARD \ MODEL NUMBER Usually the mainboard model number is labeled on the side of ISA slot or PCI slot, please see the picture shown below: MAINBOARD MODEL NUMBER example: SL-65KV2 MAINBOARD SERIAL NUMBER example: 0012000T005679...
  • Page 100 65MIV-C MEMO...
  • Page 101 Appendices MEMO...

This manual is also suitable for:

Sl-65miv2

Table of Contents
