Battery Memory Set And Call Out - Skyrc iMAX B6 mini Instruction Manual

Professional balance charger / discharger
Hide thumbs

Advertisement

BATTERY MEMORY SET AND CALL OUT

The charger can store up to 10 different charge/discharge profiles for your
convenience, and the stored profiles can be recalled quickly without having to go
through the setup process.
When you are willing to alter the parameter value in the program, press
START/ENTER to make it blink then change the value with INC or DEC. The value
will be stored by pressing START/ENTER once.
Note: All following screen are taking 2S(7.4V) LiPo battery for example.
[ B A T T M E M O R Y 1 ]
E N T E R S E T - >
START/ENTER
B A T T T Y P E
L i P o
DEC INC
B A T T V O L T S
7 . 4 V ( 2 S )
DEC INC
C H A R G E C U R R E N T
4 . 9 A
DEC INC
D S C H C U R R E N T
2 . 0 A
DEC INC
D S C H V O L T A G E
3 . 0 V / C E L L
DEC INC
T V C = Y O U R R I S K
4 . 2 0 V
DEC INC
S A V E P R O G R A M
E N T E R
START/ENTER
· 14
1. Battery Memory Set
Enter the battery memory program.
(10 different charge/discharge profiles can be stored).
Set the battery type(LiPo/LiFe/LiIon/NiMH/NiCd/Pb).
Set the voltage and number of cells(1S-6S).
Set the charge current(0.1-6.0A).
Set the discharge current (0.1A-2.0A).
Set the discharge voltage(3.0-3.3V/Cell).
Set the terminal voltage(4.18-4.25V).
Press ENTER to save program.
B6 mini
