SYSTEM SETTING

It will be operated with the default value of the essential user settings when it is
powered on for the first time.The screen displays the following information in
sequence and the user can change the value of parameter on each screen.
When you are willing to alter the parameter value in the program, press
START/ENTER to make it blink then change the value with INC or DEC. The value
will be stored by pressing START/ENTER once.
ITEM
S a f e t y
T i m e r
O N
1 2 0 M i n
C a p a c i t y C u t - O f f
O N
5 0 0 0 m A H
T e m p C u t - O f f
O N
5 0 ° C
1 2 2 ° F
T e m p e r a t u r e U n i t
C e l s i u s
R e s t T i m e
C H G > D C H G
1 0 M i n
· 16
SELECTION
OFF/
ON
1-720 Min
(
)
OFF/
ON
(
100-50000 mAh)
OFF/
ON
(20 C/68 F -
80 C/176 F
)
Celsius
Fahrenheit
1-60Min
DESCRIPTION
When you start a charge process, the
integral safety timer automatically starts
running at the same time. This is
programmed to prevent overcharge the
battery if it proves to be faulty, or if the
termination circuit cannot detect the
battery full. The value for the safety timer
should be generous enough to allow a full
charge of the battery.
This program sets the maximum charge
capacity that will be supplied to the
battery during charge. If the delta peak
voltage is not detected nor the safety
timer expired by any reason, this feature
will automatically stop the process at the
selected capacity value.
The battery's internal chemical reaction
will cause the temperature of the battery
to rise. If the temperature limit is reached,
the process will be terminated.
You can choose the temperature
displayed by Celsius or Fahrenheit as
you like.
A rest time allowing the battery to cool
down between charging/discharging
cycle.
B6 mini
