INTRODUCTION
Please read this entire operating manual completely and attentively before
using this product, as it covers a wide range of information on operating
and safety. Or please do use this product in company with a specialist!
PC Link
DC Input
Power Port
DC 11-18V
Temperature
Sensor Port
· 02
LCD Display
Balance Lead
Socket JST-XH
Ports
Output Charge
Lead 4mm
Banana Plug
Resume or Start
Charge Processes
Confirm Any Action
Alter Values
See the Status of Individual
Cells in Balance Charge Mode
Scroll Through the Main Menu
Stop Any Charge Processes
B6 mini
