Lift the assembly, along with the ceiling tile, into place in the drop-ceiling support framework.
Install the Support Rails in the ceiling over the ceiling tile and supported by the suspended
framework. Lower the Position Clamps into the Support Rail channels.
»
NOTE: The support rails are only long enough to span 2' suspensions. If that
orientation does not orient the Beamforming Microphone Array in the correct axis
for your room, you may need to rotate the Mic Mounting plate 90 degrees to orient it
correctly.
Chapter 2: Ceiling Mount Installation
F 2X
15
