Now you have the unsecured Suspension Column extending through the ceiling tile with the Ceiling
Mounting Plate and Suspended Ceiling Trim Lock Plate above the tile, and the Trim Plate and Mic
Mounting Plate below the tile. Attach the Position Clamps against the wide sides of the Suspension
Column above the ceiling tile. Allow the assembled position clamps to be loose enough to slide up
and down for positioning.
2X
HC
E 2X
14
Beamforming Microphone Array
