  • Page 1 DIALOG 20 and DIALOG 10 USB ® ® Wireless Microphone Systems Antenna Installation Guide www.ClearOne.com...
  • Page 2 10 USB ® The ClearOne DIALOG 20 and DIALOG 10 USB Wireless Microphone System Receivers include two, built-in, passive antennas. When using a ClearOne DIALOG 20 or DIALOG 10 USB Antenna Cable Kit, the antennas can be extended to either 10’...
  • Page 3 Female TNC Connector. • Tilt the antennas slightly outward. Antenna Cable Kits: DIALOG 20 and DIALOG 10 USB Antenna Cable Kits are available in two lengths. The DIALOG Antenna Cable kit can be used to extend the passive, Plenum rated, dipole antennas that are included with the DIALOG 20 and DIALOG 10 USB Receivers.
  • Page 4 _____________________________ ClearOne ® ® DIALOG 20 and DIALOG 10 USB ® Confirm the Box Contains the Following: THIS SIDE UP THIS SIDE UP Fig. 1 Bracket Hole Templates (Actual Size) Use these cable extension bracket templates to mark the pilot holes.
  • Page 5 _____________________________ ClearOne ® ® DIALOG 20 and DIALOG 10 USB ® Hollow Wall Antenna Installation: Determine required mounting location. Fig. 2 Using the antenna extension brackets or the Wall templates mark the two (2) mounting (fig. 1; Pg. 2), Anchor hole locations.
  • Page 6 _____________________________ ClearOne ® ® DIALOG 20 and DIALOG 10 USB ® Wood Stud Antenna Installation: Determine required mounting location. Using the antenna extension bracket or the template , mark two (2) (fig. 1; pg. 2) mounting hole locations. Drill two 7/64” (2.5mm) pilot holes to a depth of 1-3/4” (45mm).
  • Page 7 TNC Panel Mount Connector (Fig. 8) . Attach the other end of the extension cable to the Dialog 20 Receiver and secure by using a non-conductive adhesive on the threads of the Female TNC Connector.
  • Page 8 Other product names may be registered trademarks of their respective owners who do not necessarily endorse ClearOne or ClearOne’s products. All rights reserved. Information in this document subject to change without notice. © 2022 ClearOne. DOC-0307-001 DIALOG20 ANTENNA INSTALLATION GUIDE V6.0...
