Quick-Start Guide
BMA 360
QSG-0086-001 v1.0 October 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BMA 360 and is the answer not in the manual?

Questions and answers

Related Manuals for ClearOne BMA 360

Summary of Contents for ClearOne BMA 360

  • Page 1 Quick-Start Guide BMA 360 QSG-0086-001 v1.0 October 2020...

  • Page 2: Table Of Contents

    Important Safety Information ................. 3 Introduction ......................4 Operating and System Requirements ..............6 Setup ........................6 .................. 6 Step 1: Unpack the BMA 360 ..................6 Step 2: Install the BMA 360 ................. 7 Step 3: Connect the BMA 360 Compliance ......................

  • Page 3: Important Safety Information

    BMA 360 Quick-Start Guide Important Safety Information Read and follow all instructions. Keep these instructions. Do not use these devices near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with manufacturer instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 4: Introduction

    Quick-Start Guide Introduction The patented BMA 360 is the world’s most technologically advanced ceiling tile beamforming mic array, delivering unrivaled audio performance and deployment ease. The world’s first truly wideband, frequency invariant beamforming mic array with uniform gain response across all frequency bands.
  • Page 5 BMA 360 Quick-Start Guide System Diagram Three daisy-chained BMA 360 microphone arrays, with 2x30W and 4x15W speaker configurations, connected to a CONVERGE Pro 2. Room Coverage Full Circle/Square Rectangular Semi-Circle/Classroom Room size Beams Room size Beams Room size Beams 10’ x 10’ to 18’ x 18’...

  • Page 6: Operating And System Requirements

    Important: Please note the following PoE requirements: No speakers: 36W PoE, connected via P-Link or PoE++ • Speakers: Requires 90W PoE or 70W PoE. Must be connected via direct PoE++ port on the BMA 360. • ClearOne recommends the following PoE power supply kits: 36W: ClearOne part number: 910-3200-202 •...

  • Page 7: Step 3: Connect The Bma 360

    Step 3: Connect the BMA 360 a. Description of Controls and Connection Warning: Power over Ethernet (PoE) equipment used with a BMA 360 must meet the IEEE 802.3af, 802.3at or 802.3bt • standards. When speakers are connected, you must provide power via the PoE++ port on the BMA 360.
  • Page 8 CONVERGE Pro 2 (CP2) Figure 2. CONVERGE Pro 2 Back Panel Item Description P-Link Out: RJ45 connector. Connects to the BMA 360. b. Connect the BMA 360 to Your System On the BMA 360 back plane, make the following connections: If you have not already done so, •...

  • Page 9: Compliance

    BMA 360 Quick-Start Guide Compliance Details about compliance for the BMA 360 are available online on ClearOne’s website (www.clearone.com) in Support & Training > Resource Library. ClearOne Contacts Headquarters Sales 5225 Wiley Post Way Tel: 801.975.7200 Suite 500 e-mail: sales@clearone.com Salt Lake City, UT 84116 www.clearone.com...
