9700 Mobile Computer (WEH)

1.7.3. INSERT SD CARD

Day-to-day use of the mobile computer might cause the available internal storage to run
short. Equip the mobile computer with an external memory unit to expand storage capacity.
Follow the steps below to install a SD card:
1) Power off the mobile computer.
2) Place the mobile computer face-down on a flat and soft surface.
3) Lift up the handstrap slightly to remove the main battery pack as described in
Install/Remove Main
4) The SD card socket is equipped with a hinged cover. Push the hinged cover right and lift
the cover up to open the card socket. Insert your SD card in the indicated direction
5) Close the hinged cover and push the cover left to have it locked.
6) A plastic cover is provided for the SD card socket to prevent moisture accumulation.
Press the plastic cover down to secure it on top of the SD card socket.
7) Replace the main battery pack.
Figure 10: Inserting SD Card
42
Battery.
