CipherLab 9700 Reference Manual page 207

9700 Mobile Computer (WEH)
Note: UPC portion of composite is transmitted using UPC rules.
PDF417,
Micro PDF417
Data Matrix
Maxicode
QR Code
196
1 Data packet is a EAN-128 barcode (= data is preceded with
"]JC1").
0 Scan engine is set to conform to protocol defined in 1994
PDF417 symbology specifications.
 When this option is transmitted, the receiver cannot
reliably determine whether ECIs have been invoked or
whether
transmission.
1 Scan engine is set to follow the ECI protocol (Extended
Channel Interpretation). All data characters 92
doubled.
2 Scan engine is set for Basic Channel operation (no escape
character transmission protocol). Data characters 92
not doubled.

When decoders are set to this mode, unbuffered Macro
symbols and symbols requiring the decoder to convey ECI
escape sequences cannot be transmitted.
3 The barcode contains a EAN-128 symbol, and the first
codeword is 903-907, 912, 914, 915.
4 The barcode contains a EAN-128 symbol, and the first
codeword is in the range 908-909.
5 The barcode contains a EAN-128 symbol, and the first
codeword is in the range 910-911.
A PDF417 barcode, ABCD, with no transmission protocol enabled, is
transmitted as ]L2ABCD.
0 ECC 000-140, not supported.
1 ECC 200.
2 ECC 200, FNC1 in first or fifth position.
3 ECC 200, FNC1 in second or sixth position.
4 ECC 200, ECI protocol implemented.
5 ECC 200, FNC1 in first or fifth position, ECI protocol
implemented.
6 ECC 200, FNC1 in second or sixth position, ECI protocol
implemented.
0 Mode 4 or 5
1 Mode 2 or 3
2 Mode 4 or 5, ECI protocol implemented.
3 Mode 2 or 3, ECI protocol implemented in secondary
message.
0 Model 1
1 Model 2 / MicroQR ECI protocol not implemented.
2 Model 2, ECI protocol implemented.
data byte 92
DEC
Reference Manual
has been doubled
DEC
DEC
in
are
are
