Note: If no modes are selected in Screen Rotation, the mobile computer's touch screen
will be fixed in portrait mode.

1.6.3. ADJUST BACKLIGHT

Screen backlight can be adjusted manually or automatically. Upon shipping, the mobile
computer is set to automatic adjustment, which helps saves power. Alternatively you can
set the backlight manually according to your preferences.
MANUAL BACKLIGHT ADJUSTMENT
To adjust screen backlight:
1) Tap Start | Settings | System | Backlight Setting
Brightness tab page opens with a checkbox to enable manual backlight setting, and a
slider bar for setting screen backlight level.
By default, Manual backlight setting is checked, and screen and keypad backlights
will stay at the set level and will not adjust automatically. When Manual backlight
setting is unchecked, the light sensor embedded on the front of the mobile computer
will detect current lighting environments, and screen and keypad backlights will adjust
automatically according to the backlight profiles set under the Profile tab page.
2) Tap Save in the lower right corner to apply the settings.
Chapter 1 Use Mobile Computer
.
Brightness tab page
Select whether to enable manual
backlight setting
Slide to set backlight level as desired
37
