REFERENCE MANUAL
9400CE

MOBILE COMPUTER

DOC Version 1.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9400CE and is the answer not in the manual?

Questions and answers

Related Manuals for CipherLab 9400CE

Summary of Contents for CipherLab 9400CE

  • Page 1: Mobile Computer

    REFERENCE MANUAL 9400CE MOBILE COMPUTER DOC Version 1.02...
  • Page 2 CIPHERLAB and the client and remains the exclusive property of CIPHERLAB CO., LTD. If you find any problems in the documentation, please report them to us in writing. CIPHERLAB does not warrant that this document is error-free.

  • Page 3: Safety Precautions

    The use of any batteries or charging devices, which are not originally sold or manufactured by CipherLab, will void your warranty and may cause damage to human body or the product itself. The charging and communication cradle uses an AC power adaptor. A socket outlet shall be installed near the equipment and shall be easily accessible.

  • Page 4: Care & Maintenance

    CARE & MAINTENANCE This mobile computer is intended for industrial use. The mobile computer is rated IP 64, however, it may do damage to the mobile computer when being exposed to extreme temperatures or soaked wet. When the body of the mobile computer gets dirty, use a clean and wet cloth to wipe off the dust.

  • Page 5: Release Notes

    RELEASE NOTES VERSION DATE NOTES Modified: Appendix I – RFID Tag Supported: table corrected 1.02 Oct. 05, 2007 (TI_RFID Module 1.0.A) Modified: Installing the Pistol Grip – No power connector required. 1.01 Oct. 03, 2007 1.00 Aug. 10, 2007 Initial release...

  • Page 7: Table Of Contents

    FCC Regulations ..........................3 Safety Precautions ..........................3 Care & Maintenance ......................... 4 RELEASE NOTES ..........................5 INTRODUCTION ............................ 1 Getting Familiarized with 9400CE ....................2 Installing the Hand Strap......................3 Installing the Pistol Grip....................... 4 Dimensions............................5 Features............................. 5 Inside the Package..........................
  • Page 8 2.5.1 Software Reset (Warm Reboot)..................35 2.5.2 Hardware Reset (Cold Reboot)..................35 2.5.3 Auto Run ........................... 35 2.6 Updating OS Image........................36 PERSONALIZING THE 9400CE MOBILE COMPUTER ................ 39 3.1 Changing System Settings .......................39 3.2 Changing Connection Settings....................42 3.2.1 USB Connection .......................44 3.2.2 GPRS ..........................
  • Page 9 9400CE Mobile Computer Reference Manual 4.4.2 Synchronizing Inbox ......................71 4.5 Backup Utility ..........................72 4.5.1 Managing the Registry ..................... 72 4.5.2 Getting Ready for Backing up Files ................. 73 4.5.3 Backing up Files .......................74 4.5.4 Using Backups for Restore ....................74 4.6 Button Assignment Utility ......................76...

  • Page 11: Introduction

    INTRODUCTION The 9400CE Mobile Computer, running Windows CE 5.0 in palm size, is our first product line of rugged PDA-style Mobile Computer. Light-weight, streamlined and ergonomic, it adds even more powerful and handy tools to delivering the flexibility in customization.

  • Page 12: Getting Familiarized With 9400Ce

    9400CE Mobile Computer Reference Manual GETTING FAMILIARIZED WITH 9400CE Figure 1: Front / Back View...

  • Page 13: Important Notices

    Introduction INSTALLING THE HAND STRAP The hand strap is ideal for one-handed operation, which requires safe and convenient hold of the mobile computer. Warning: Always make sure the hand strap is well hooked and screwed to the back of the mobile computer before use.

  • Page 14: Installing The Pistol Grip

    9400CE Mobile Computer Reference Manual INSTALLING THE PISTOL GRIP This contoured pistol grip enables intuitive trigger-and-scan operation, which is very helpful in scan intensive applications. When a pistol grip is necessary, install it to the mobile computer by following these steps: 1) Press for the mobile computer to enter suspend mode.

  • Page 15: Dimensions

    Introduction DIMENSIONS Figure 4: Dimensions FEATURES Ergonomic design - ruggedized yet streamlined, with hand strap for secure hold. Built tough to survive drop test and sealed against moisture/dust to industrial standard IP 64. Microsoft Windows CE 5.0 operating system, 520 MHz Intel PXA270 processor 128 MB non-volatile NAND flash memory to store OS and software programs (part of the free space is used as a storage card called DiskOnChip) 64 MB / 128 MB SDRAM to store and run programs, as well as store program data...

  • Page 16: Inside The Package

    9400CE Mobile Computer Reference Manual Application Generator (AG*.exe for desktop PC) enables easy customization of data collection applications. Programming support includes Reader DLL and System API. Accessories and peripherals include pistol grip, international AC charging cradle, etc. INSIDE THE PACKAGE The following items are included in the package.

  • Page 17: Using The 9400Ce Mobile Computer

    1.1 BATTERY Main Battery The 9400CE Mobile Computer is powered by a rechargeable 3.7 V/1800 mAh Li-ion battery pack, and it takes approximately 4 hours to fully charge it. However, the charging time may vary by working condition. During normal operation, the mobile computer can work for up to 10 hours.
  • Page 18 9400CE Mobile Computer Reference Manual 3) Hold the mobile computer still and press the release button to unlock the battery cover. 4) Slide off the battery cover. 5) Use the stylus (or a sharp-pointed object, such as a pencil) to adjust the DIP switch to the ON position (top).

  • Page 19: Charging The Battery

    Chapter 1 Using the 9400CE Mobile Computer 1.1.2 CHARGING THE BATTERY The main and backup batteries may not be charged to full for shipment. When you first receive the package, you will need to charge batteries to full before using the mobile computer.
  • Page 20 9400CE Mobile Computer Reference Manual Stop wireless connectivity, Bluetooth, 802.11b/g or GSM/GPRS that is not in use. Refer to the Wireless Power Manager. To save power, go to Start > Settings > Control Panel and select Display (for backlight settings) or select Power (for power schemes).

  • Page 21: Memory

    Chapter 1 Using the 9400CE Mobile Computer 1.2 MEMORY Read-only Memory (ROM) 128 megabytes flash memory for storing OS (Windows CE 5.0) and custom application programs. Yet a small portion of the memory is referred to as DiskOnChip, which can store data and programs that you wish to retain even after a hardware reset.

  • Page 22: Inserting The Minisd Card

    9400CE Mobile Computer Reference Manual START > SETTINGS > CONTROL PANEL AND DOUBLE-TAP THE STORAGE MANAGER ICON Here provides a tool for administrators to reformat the DiskOnChip folder or storage card (miniSD). Warning: This tool is for the use of system administrators only. Everything on the storage device will be permanently erased after reformatting.

  • Page 23: Keypad

    Chapter 1 Using the 9400CE Mobile Computer Figure 6: Inserting the miniSD Card REMOVING THE MINISD CARD If you wish to remove the miniSD card, simply push the card after removing the side plate. The miniSD card will be rejected automatically.

  • Page 24: Using The Keypad

    9400CE Mobile Computer Reference Manual Note: Functionality of keys is application-dependent. 1.3.1 USING THE KEYPAD PRESS FIRST, AND THEN The LED backlight of keypad is turned off by default. It can be toggled ON/OFF by the key combination: [Func] + [0].

  • Page 25: Programmable Keys

    Chapter 1 Using the 9400CE Mobile Computer A circular icon of the letter "F" will appear on the status bar. This modifier key is hold down as long as the icon is displayed. 2) Now press another key to get the value of key combination (say, press [1] to get the value of F1).

  • Page 26: Adjusting The Backlight

    9400CE Mobile Computer Reference Manual The LED backlight of screen, which helps ease reading under dim environments, can be controlled manually and automatically. Warning: Using backlight while on battery power will substantially reduce battery life. It is suggested to dim the backlight while working in a well-lit area or automatically turn off the mobile computer when not in use.

  • Page 27: Re-Calibrating The Screen

    Chapter 1 Using the 9400CE Mobile Computer 3) Tap the [Advanced] button (right above). 4) In the Settings tab, you can select the luminosity of backlight when it is set to be automatically turned on by pressing any key or tapping the screen. Tap, hold, and drag the slider for AC and battery powered respectively.

  • Page 28: Audio

    9400CE Mobile Computer Reference Manual Charging done Good Read Bluetooth enabled Note: The green LED is also used for "Good Read" while collecting data. 1.5.2 AUDIO Speaker The mobile computer is integrated with a mono speaker, a low power transducer type, used for playing sounds applied to events in Windows and programs, as well as playing audio files such as .WAV files.

  • Page 29: Digital Camera

    Chapter 1 Using the 9400CE Mobile Computer 1.6.2 DIGITAL CAMERA An integrated 2 mega-pixel CMOS camera inside the computer is specifically designed for collecting image data. Refer to the Image Capture Utility. 1.7 COMMUNICATIONS 1.7.1 USING THE CRADLE The cradle is designed for charging and communications at the same time.

  • Page 30: Inserting The Sim Card

    9400CE Mobile Computer Reference Manual Figure 8: Understanding the Cradle 1.7.2 INSERTING THE SIM CARD 1) Press for the mobile computer to enter suspend mode. 2) Hold the mobile computer still and remove the hand strap as well as the battery.

  • Page 31: Turn Off The Wireless Networks

    Chapter 1 Using the 9400CE Mobile Computer 4) Flip up the SIM card holder. 5) Insert the SIM card to the SIM card holder, using the card orientation shown below. 6) Push the SIM card holder down. 7) Slide the locking plate away from its hinge to secure the SIM card holder.
  • Page 32 9400CE Mobile Computer Reference Manual...

  • Page 33: Learning Windows Ce Basics

    2.6 Updating OS Image ..................36 2.1 GETTING STARTED When the 9400CE Mobile Computer is fully charged, you may remove it from the cradle. Then, press to turn on the mobile computer and wait for the Windows CE desktop to come up. If you are using the mobile computer for the first time, there are a couple of things to do after the desktop comes up.

  • Page 34: Desktop

    9400CE Mobile Computer Reference Manual SUSPEND MODE Like your PDA, Pocket PC and most handheld devices, the 9400CE Mobile Computer functions when it is turned on. This is because the Windows CE operating system eliminates the booting process and runs continuously.

  • Page 35: Taskbar

    Chapter 2 Learning Windows CE Basics Note: To customize the desktop, tap anywhere blank on the desktop and select Properties. When you turn on the mobile computer and seat it in the cradle for the first time, you will find these icons displayed on the taskbar.
  • Page 36 9400CE Mobile Computer Reference Manual UNDERSTANDING THE ICONS ON THE TASKBAR ICON DESCRIPTION SEE ALSO The USB connection for ActiveSync operation is successfully 3.2.1 USB established. Connection (via cradle) Double-tap it to view status. Tap [Disconnect] if necessary. The Bluetooth PAN connection fails. (= disconnected) 3.2.4 BTPAN...

  • Page 37: Start Menu

    Start Menu. 2.1.4 INPUT METHODS Data entry can be performed by the following methods: Type with the physical keypad. Scan barcode or RFID tag in applications, e.g. WordPad, CipherLab's Application Generator, etc. Tap or write using SIP (Soft Input Panel)

  • Page 38: Finding Out The Capabilities Of Your Mobile Computer

    2) Select the Device Name tab to change the identification for the mobile computer. DEVICE CONFIGURATION CODE The device configuration of the 9400CE Mobile Computer is displayed in 5 digits: xxxx-x Take the screenshot of System Properties below for example. Its device configuration is “2410-0”,...

  • Page 39: Using Activesync

    Keypad module 0= 28-key 2.3 USING ACTIVESYNC ActiveSync is used to synchronize information between the 9400CE Mobile Computer and your desktop computer, to install programs on the mobile computer, and to backup and restore the mobile computer. The Microsoft ActiveSync program has to be installed on your desktop computer first.

  • Page 40: Add/Remove Programs

    9400CE Mobile Computer Reference Manual 2) Your computer will automatically detect the USB device. Click [OK] when the connection is established. 3) Select which partnership to set up. If you want to synchronize data between the mobile computer and your personal computer, select Standard Partnership; otherwise, select Guest Partnership.

  • Page 41: Backup/Restore

    Chapter 2 Learning Windows CE Basics 7) On the mobile computer, go to Start > Programs and the new program will appear. ALTERNATIVE TO REMOVE PROGRAMS (CONTROL PANEL) Alternatively, you may un-install a new program manually. 1) Go to Start > Settings > Control Panel and select Remove Programs. 2) Tap the name of the program that you want to delete.
  • Page 42 9400CE Mobile Computer Reference Manual If you wish to quick launch a new program, add it to the Programs folder: My Device\Windows\Programs. The program will become available in the Start Menu. To add a new program or subfolder to the Programs folder, you can either use Windows Explorer or ActiveSync.
  • Page 43 Chapter 2 Learning Windows CE Basics 5) Tap and hold anywhere blank on the screen to select [Paste Shortcut] from the pop-up menu. The new program will be added to the Programs folder. 6) Go to Start > Programs and the new program will appear now. USING ACTIVESYNC TO ADD A PROGRAM TO START MENU 1) When connected, open the Microsoft ActiveSync window on your desktop computer.

  • Page 44: Create A Folder

    9400CE Mobile Computer Reference Manual 5) Right-click the shortcut and select [Cut] from the pop-up menu. 6) Navigate to the Programs folder – My Device\Windows\Programs. 7) Right-click anywhere blank on the window and select [Paste] from the pop-up menu. The new program will be added to the Programs folder.

  • Page 45: System Reset & Auto Run

    Chapter 2 Learning Windows CE Basics to close an active window, a dialog box, or a running application. If the button is not displayed on the toolbar, press on the physical keypad. to save the current settings and exit the application (or minimize the window in some applications).

  • Page 46: Updating Os Image

    9400CE Mobile Computer Reference Manual IF AUTORUN.EXE EXISTS Upon cold boot, the OS shall automatically execute AutoRun.exe Upon warm boot, the OS shall automatically execute AutoRun.exe IF AUTORUN.INI EXISTS Upon cold boot, the OS shall automatically check the contents of AutoRun.ini and execute them (if there is any).
  • Page 47 Learning Windows CE Basics 3) Press [Reset] + to perform a hardware reset on 9400CE. 4) Press simultaneously in three seconds so that 9400CE can enter the "Download" mode. 5) Seat 9400CE in the cradle. 6) Press on 9400CE to start image update.
  • Page 48 9400CE Mobile Computer Reference Manual...

  • Page 49: Personalizing The 9400Ce Mobile Computer

    In this chapter, a brief on the system settings is provided for your reference. Note: User settings are stored in SDRAM and will be overwritten by the system defaults after a hardware reset. However, you can use the CipherLab Backup Utility to backup the current registry for restore purpose.
  • Page 50 9400CE Mobile Computer Reference Manual Keyboard tab: Select StickyKeys to enable simultaneous keystrokes while pressing one key at a time; select ToggleKeys to emit sounds when certain locking keys are pressed. Sound tab: Select SoundSentry to provide visual warnings for system sounds.
  • Page 51 Chapter 3 Personalizing the 9400CE Mobile Computer In the [Network and Dial-up Connections] window, you may configure settings for the mobile computer connects to a network directly or through a modem. Alternatively, you may tap Start > Settings > Network and Dial-up Connections.

  • Page 52: Changing Connection Settings

    9400CE Mobile Computer Reference Manual In the [Stylus Properties] dialog box, Double-Tap tab: You may configure and test your double-tap settings. Calibration tab: You may need to re-calibrate the touch screen if it is not responding properly to your taps.
  • Page 53 Chapter 3 Personalizing the 9400CE Mobile Computer CONNECTIONS DESCRIPTION SEE ALSO This is a shortcut to USB Connection, and the Start > Settings > Control selected interface is USB for factory setting. This connection is reflected in the control panel for direct PC connection.

  • Page 54: Usb Connection

    9400CE Mobile Computer Reference Manual 3.2.1 USB CONNECTION The USB connection is specifically for performing the ActiveSync operation via the cradle. Generally, it will automatically establish the connection and start the ActiveSync operation when you seat the mobile computer in the cradle. To stop the ActiveSync operation, simply remove the mobile computer.

  • Page 55: Gprs

    Chapter 3 Personalizing the 9400CE Mobile Computer 3.2.2 GPRS Tap and hold "GPRS". The pop-up menu provides a number of options. Refer to section 1.7.2 Inserting the SIM Card. CONNECT/DISCONNECT 1) Turn on the power to the GPRS module through the Wireless Power Manager. Its associated...
  • Page 56 9400CE Mobile Computer Reference Manual 2) If the default PIN code does not match the one of your SIM card, the SIM PIN CODE dialog box (above) will appear to request the correct PIN code. You will have two chances to enter the correct PIN code.
  • Page 57 Chapter 3 Personalizing the 9400CE Mobile Computer 4) After you tap the [Connect] button, the GPRS status will go through opening port, user authenticated, device connected until it is connected finally. The status icon will appear on the taskbar to indicate the GPRS connection is established successfully.

  • Page 58: Wlan

    9400CE Mobile Computer Reference Manual 3.2.3 WLAN Tap and hold "WLAN1". The pop-up menu provides a number of options. CONNECT/DISCONNECT Turn on the power to the 802.11b/g module through the Wireless Power Manager. Wait a few seconds for the mobile computer to automatically connect to the preferred network you have configured.
  • Page 59 Chapter 3 Personalizing the 9400CE Mobile Computer INITIAL CONNECTION 1) For initial connection, turn on the power to the 802.11b/g module through the Wireless Power Manager first. 2) Double-tap on the taskbar. 3) Select an available network and tap [Connect].
  • Page 60 9400CE Mobile Computer Reference Manual RSSI TRIGGER RSSI stands for Received Signal Strength Indication. Use an RSSI value to determine when it comes below a certain threshold at which point the mobile computer will seamlessly switch the network connection, for example, while moving in and out of range between different access points. Select [Adaptive Connection] and pick up a suitable value.

  • Page 61: Btpan

    Chapter 3 Personalizing the 9400CE Mobile Computer 3.2.4 BTPAN Tap and hold "BTPAN1". The pop-up menu provides a number of options. ENABLE/DISABLE CONNECTION ICONS DESCRIPTION This is the control of Bluetooth module for wireless personal area networking (WPAN) connection, which is not available until the Bluetooth Manager is executed.
  • Page 62 9400CE Mobile Computer Reference Manual...

  • Page 63: Using Applications

    Chapter 4 USING APPLICATIONS The 9400CE Mobile Computer provides several utilities and key applications which are made accessible from the desktop or the taskbar. Wireless Power Manager lets you determine whether the power is supplied to the GPRS or WLAN module, along with its associated driver installed.

  • Page 64: Wireless Power Manager

    9400CE Mobile Computer Reference Manual 4.1 WIRELESS POWER MANAGER Wireless Power Manager is a control panel applet, which allows you to choose and enable 802.11b/g or GPRS card. Note: Meanwhile, you may enable Bluetooth connectivity through the Bluetooth Manager. 1) Double-tap the associated icon on the taskbar to run Wireless Power Manager.

  • Page 65: Bluetooth Manager

    Chapter 4 Using Applications 4.2 BLUETOOTH MANAGER Bluetooth Manager is a utility that helps you access and manage the available Bluetooth services efficiently. 4.2.1 BLUETOOTH PROFILES SUPPORTED The supported Bluetooth profiles are: Serial Port Profile (SPP) Object Push Profile (OPP) File Transfer Profile (FTP) Dial-Up Networking Profile...
  • Page 66 9400CE Mobile Computer Reference Manual Serial If "Auto Server COM Port" is enabled, the COM port providing Serial Port Port service will be assigned automatically (COM6 by default). Properties If "Auto Server COM Port" is disabled, you can select a COM port by...

  • Page 67: Security Tab

    Chapter 4 Using Applications Tap this button to view Bluetooth properties. General It displays device name, MAC address, as well as the device type. If you wish to change the device name of the mobile computer, go to Start > Settings >...

  • Page 68: Options Tab

    9400CE Mobile Computer Reference Manual Options Start minimized: When selected, once you run the Bluetooth Manager program, its window will be minimized to an icon on the taskbar, which serves as a toggle to open or close the Bluetooth Manager window.

  • Page 69: Starting Bluetooth Services

    Chapter 4 Using Applications DUN for Dial-Up Networking Profile (supports Client only) Note that the mobile computer also supports the following profiles - PAN Service Profile Human Interface Device (HID) Profile 4.2.3 STARTING BLUETOOTH SERVICES 1) Go to Start > Programs > BTManager to open the Bluetooth Manager. 2) It takes several seconds to enable the Bluetooth services.

  • Page 70: Pairing

    9400CE Mobile Computer Reference Manual 4.2.5 PAIRING When authentication is enabled on the target device, you will have to pair with it before starting a connection. 1) From the device list, tap and hold the desired device to select [Pair] from the pop-up menu. (left below) 2) Enter the PIN code that is specified on the remote device.

  • Page 71: Connecting

    Chapter 4 Using Applications 3) Once paired successfully, the paired device will be displayed along with a lock icon " ". UNPAIR DEVICES To unpair with a device from the device list, you will have to tap and hold the desired device to select [Unpair] from the pop-up menu.
  • Page 72 9400CE Mobile Computer Reference Manual BLUETOOTH ACTIVESYNC For ActiveSync via Bluetooth, tap and hold Serial Port Service to select [Connect to Activesync] from the pop-up menu. It uses COM8 to connect to your computer by default. To stop ActiveSync via Bluetooth, tap...
  • Page 73 Chapter 4 Using Applications USING SERIAL PORT SERVICE Tap and hold Serial Port Service to select [Connect] from the pop-up menu. If "Auto Client COM Port" is disabled in , you will need to select a COM port. Once the connection has been established, the connected service will be displayed along with a plug icon "...
  • Page 74 9400CE Mobile Computer Reference Manual 3) Tap and hold anywhere blank to select [Add file] from the pop-up menu. 4) Choose the file you wish to upload to the remote device. 5) The mobile computer will start transferring the file.

  • Page 75: Reader Configuration Utility

    Chapter 4 Using Applications 4.3 READER CONFIGURATION UTILITY The Reader Configuration Utility is the control applet and tool to manage the barcode and RFID readers integrated on the mobile computer. 1) Go to Start > Programs > 94ReaderConfig to open the Reader Configuration Utility. The associated icon will appear on the taskbar.

  • Page 76: Barcode Reader Settings

    9400CE Mobile Computer Reference Manual 4.3.1 BARCODE READER SETTINGS The barcode reader configurations depend on the scan engine(s) installed. You can tell which reader is currently in use and make necessary changes on the General tab. BARCODE READER DESCRIPTION CCD/Laser Reader If enabled, tap the [Barcode Reader] button to configure the reader settings for CCD or Laser scan engine.

  • Page 77: Data Output

    Chapter 4 Using Applications READ OPERATION By default, the RFID tag is read from byte 0 of the default page. However, the default page, amount of bytes and number of pages of each tag may be different. Specify how many bytes of data you want to read from the tag.

  • Page 78: Beeper / Vibrator

    9400CE Mobile Computer Reference Manual Note: (1) Refer to 9400CE Programming Guide for details on Windows Message and Windows Event. Sample programs are provided by request. (2) For the use of a different program rather than 94ReaderCfg, a dynamic-link library (DLL) file is provided.

  • Page 79: Symbology Settings

    Chapter 4 Using Applications Warning Mute, or Sound 1~9 Sound 2 Beep Vibration 0~30 (sec.) 0 (= Disable) Duration 0 = Disable the vibrator 4.3.5 SYMBOLOGY SETTINGS For barcode settings, tap the Symbologies tab. Refer to Appendix I – Scan Engine Settings for the symbologies or RFID tags supported by a scan engine.
  • Page 80 9400CE Mobile Computer Reference Manual 3) Tap and drag the dialog box to show the right edge. Tap [Add] to create an e-mail service. 4) In the Service Name dialog box, select POP3 Mail or IMAP4 Mail for the service type. (right below) Change the name of e-mail service if necessary.

  • Page 81: Synchronizing Inbox

    Chapter 4 Using Applications TOOLBAR BUTTON DESCRIPTION SEE ALSO Compose a new message Compose > New Message Reply to sender Compose > Reply to Sender Reply to all Compose > Reply to All Forward this message Compose > Forward Delete this message File >...

  • Page 82: Backup Utility

    ActiveSync 3.7.1 installed on your computer. 4.5 BACKUP UTILITY The CipherLab Backup Utility is provided to help you easily make copies of data and restore your mobile computer's specific registry settings, install applications, user data, etc. Find out your OS version: go to Start > Settings > Control Panel and select System. Select the Device Name tab.

  • Page 83: Getting Ready For Backing Up Files

    Chapter 4 Using Applications 4.5.2 GETTING READY FOR BACKING UP FILES Tap the Backup tab and it will automatically start scanning the file system. Within a few minutes, it will generate a list for the backup operation. IF THE ITEMS "WIFI" AND "REGISTRY" ARE NOT LISTED... This means no Registry.dat and Wifi.dat are found in "\DiskOnChip\Sysbak\".

  • Page 84: Backing Up Files

    9400CE Mobile Computer Reference Manual WiFi - Turn on the power to the 802.11b/g module through the Wireless Power Manager, and then select an available network to connect. Registry - Go to the Registry tab and tap [Save]. Warning: You may not be able to backup all data when programs are still running! It is suggested that you exit all the applications before backup.
  • Page 85 Chapter 4 Using Applications FILE MANIPULATION Tap [Refresh] to refresh the list of available backups. If a backup file is not desired any more, select it and tap [Delete]. AUTO RESTORE Select a desired backup file from the list and tap [AutoRestore]. It will prefix an asterisk to the selected file, indicating the specific file will be used in the restore process that starts automatically right after a cold boot.

  • Page 86: Button Assignment Utility

    Note: By default, the four side triggers are programmed to serve as ENTER keys (upper ones) as well as SCAN keys (lower ones). Now go to Start > Programs > Buttons to open the CipherLab Button Assignment Utility. 1) Tap the label of one of these seven keys.
  • Page 87 Chapter 4 Using Applications 2) You may assign one of the following key values to the upper-left side trigger or have it serve as a shortcut key to launch a specific program. Enter Scan Delete Backspace Space F1 ~ F12 3) Tap [OK] for the change to take effect.
  • Page 88 9400CE Mobile Computer Reference Manual...

  • Page 89: Specifications

    SPECIFICATIONS PLATFORM, PROCESSOR & MEMORY OPERATING SYSTEM Microsoft Windows CE 5.0 Intel PXA270 at 520 MHz MEMORY 128 MB non-volatile NAND flash memory 128 MB on-board SDRAM memory Ordering Option - 64 MB on-board SDRAM memory Expansion Slot One miniSD card slot for inserting memory card, optional COMMUNICATIONS &...

  • Page 90: Electrical Characteristics

    9400CE Mobile Computer Reference Manual ELECTRICAL CHARACTERISTICS BATTERIES Main Battery Pack Rechargeable Li-ion battery – 3.7 V, 1800 mAh Backup Battery Rechargeable Lithium battery – 3.7 V, 70 mAh Data retention for at least 20 hours POWER ADAPTER For Cradle AC 110/220 V (Input) to DC 6 V, 3.3 A (Output)

  • Page 91: Environmental Characteristics

    DEVELOPMENT ENVIRONMENT & TOOLS Integrated Visual Studio 2005 Development Visual Studio .NET 2003 Environment eMbedded Visual C++ 4.0 SP4 Software 9400CE SDK or Windows CE 5.0 Standard SDK Development Kit System API (static and DLL) for system configuration ReaderDLL for reader configuration...

  • Page 92: Accessories

    9400CE Mobile Computer Reference Manual SOFTWARE & UTILITIES Reader Configuration Utility Terminal Emulation for VT100/220 or IBM 5250 Application Generator STREAM Wireless Studio Web Browser Third-party software – Wavelink Avalanche Enabler & Telnet Client MCL Collection - MCL Client ACCESSORIES...

  • Page 93: Scan Engine Settings

    Appendix I SCAN ENGINE SETTINGS The Reader Configuration Utility (94ReaderCfg.exe) allows configuring the following reader types, depending on the module equipped on your mobile computer: 1D CCD scan engine 1D Laser scan engine 2D scan engine RFID reader Options of different reader combination are allowed, such as 1D+RFID and 2D+RFID. For each combination, both readers can be initialized and ready for scanning at the same time (dual mode operation).
  • Page 94 9400CE Mobile Computer Reference Manual Code 2 of 5 Industrial 25 (i.e. Discrete 25) Interleaved 25 Matrix 25 Code 3 of 9 Code 39 Trioptic Code 39 Italian Pharmacode (i.e. Code 32) French Pharmacode EAN/UPC EAN-8 EAN-13 Bookland EAN (i.e. ISBN)

  • Page 95: Rfid Tags Supported

    Appendix I Scan Engine Settings RFID TAGS SUPPORTED The RFID reader supports read/write operations depending on the tags. The supported labels include ISO 15693, Icode®, ISO 14443A, and ISO 14443B. Currently, the performance of some tags has been confirmed, and the results are listed below for your reference.
  • Page 96 9400CE Mobile Computer Reference Manual...

  • Page 97: Ccd/Laser Scan Engine

    Appendix II CCD/LASER SCAN ENGINE The tables below list reader settings as well as symbology settings for the CCD or Laser scan engine. READER SETTINGS TABLE CCD/LASER DESCRIPTION DEFAULT Scan Mode Laser mode Continuous Mode Non-stop scanning To decode the same barcode repeatedly, move away the scan beam and target it at the barcode for each scanning.

  • Page 98: Symbology Settings Table

    9400CE Mobile Computer Reference Manual Read Redundancy None Level 0 = None No redundancy means one successful decoding will make the reading valid and induce the "READER Event". Level 1 = One time The higher the reading security is (that is, the more redundancy the user selects), the slower the reading speed gets.
  • Page 99 Appendix II CCD/Laser Scan Engine Transmit Checksum Decide whether to include the checksum in the data being transmitted. One or two fixed lengths Select Length 4~127 Range (1~127) Interleaved 25 Enable Start/Stop Selection Refer to Industrial 25. Interleaved Verify Checksum Decide whether to verify the checksum.
  • Page 100 9400CE Mobile Computer Reference Manual Code 39 Full ASCII Code 39 Full ASCII includes all the alphanumeric and special Disable characters. Code 93 Enable Disable Verify Checksum Select one of the three calculation formulas to verify the Single checksum. If the checksum is incorrect, the barcode will not Modulo 10 be accepted.
  • Page 101 Appendix II CCD/Laser Scan Engine Transmit Application Refer to RSS-14. Transmit Checksum Refer to RSS-14. RSS Expanded Disable Transmit Code ID Refer to RSS-14. EAN-8 Enable Convert to EAN-13 The EAN-8 barcode will be expanded into EAN-13, and the next processing will follow the settings configured for EAN-13.
  • Page 102 9400CE Mobile Computer Reference Manual *It cannot read UPC-E1 barcodes!

  • Page 103: Scan Engine

    Appendix III 2D SCAN ENGINE The tables below list reader settings as well as symbology settings for the 2D scan engine. READER SETTINGS TABLE DESCRIPTION DEFAULT Focus Mode Select the focus mode to control the working range: Far Focus Far Focus – optimized to read at its far position Near Focus –...

  • Page 104: Symbology Settings Table

    9400CE Mobile Computer Reference Manual Discrete 25 (=Industrial 25) 8 characters of less Interleaved 25 8 characters of less Level 4 All barcodes must be successfully read three times before being decoded. Select a decode security level appropriate for the barcode...
  • Page 105 Appendix III 2D Scan Engine UCC/EAN-128 Read UCC/EAN-128 barcodes with leading FNC1 Enable character. ISBT 128 Read ISBT 128 barcodes. Enable Industrial 25 (= Discrete 25) Enable One or two fixed lengths Select Length 4~55 Range (1~55) Interleaved 25 Enable Convert to EAN-13 Convert a 14-character barcode into EAN-13 if the following requirements are met:...
  • Page 106 9400CE Mobile Computer Reference Manual Code 93 Disable One or two fixed lengths Select Length 4~55 Range (1~55) Disable Verify Checksum If Two Check Digits option is selected, an additional Single verification is required to ensure integrity. Select one of the Modulo 10 algorithms below.
  • Page 107 Appendix III 2D Scan Engine UPC-A Enable Transmit Checksum Decide whether to include the UPC-A checksum in the data being transmitted. Transmit Preamble Decide whether to include the UPC-A preamble System System Number (and Country Code) in the data being transmitted. Number Addon 2 / Addon 5 Refer to UPC/EAN Addon setting.
  • Page 108 9400CE Mobile Computer Reference Manual Verify Checksum Decide whether to verify the checksum. If the checksum is incorrect, the barcode will not be accepted. No verification One Check Digit Two Check Digits Transmit Checksum Decide whether to include the checksum in the data being transmitted.
  • Page 109 Appendix III 2D Scan Engine If the 2D portion is not detected, the UPC barcode will not be transmitted. CC-A/B or CC-C must be enabled! AUTO-DISCRIMINATE UPC COMPOSITES Transmit UPC barcodes as well as the 2D portion if present. 2D Symbologies PDF417 Enable MicroPDF417...

  • Page 110: Miscellaneous Options

    9400CE Mobile Computer Reference Manual TRANSMIT ANY SYMBOL IN SET / NO PARTICULAR ORDER Transmit data from each Macro PDF symbol as decoded, regardless of the sequence. PASSTHROUGH ALL SYMBOLS Transmit and decode all Macro PDF symbols and perform no processing. In this mode, the host is responsible for detecting and parsing the Macro PDF sequences.
