CipherLab 9700 Owner Reference Manual

Windows embedded compact 7.0
Hide thumbs Also See for 9700:
Table of Contents

Advertisement

Quick Links

See also: Reference Manual
Windows Embedded Compact 7.0
9700
Mobile Computer
Version 0.65

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9700 and is the answer not in the manual?

Questions and answers

Related Manuals for CipherLab 9700

Summary of Contents for CipherLab 9700

  • Page 1 Windows Embedded Compact 7.0 9700 Mobile Computer Version 0.65...
  • Page 2 The information contained in this document, including all pictures, illustrations and software, is the proprietary information of CIPHERLAB CO., LTD. and its respective legal owners; it is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties, with all rights reserved.
  • Page 3 FOR USA This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 5 RELEASE NOTES Version Date Notes Apr 8, 2014 Draft release...

  • Page 7: Table Of Contents

    1.8. Direct Data Communication ............41 1.8.1. Use Snap-on Cable ..............41 1.8.2. Use Cradle................42 1.8.3. Syncing Tools ............... 43 1.8.4. Sync Partnership ..............43 1.8.5. USB Sync ................. 44 1.8.6. Disconnect USB ActiveSync ............45 1.8.7. ActiveSync Actions to Take............46 1.9.
  • Page 8 4.3. Taskbar and Start Menu Settings ..........137 SPECIFICATIONS..................139 Platform, Processor & Memory ..............139 Communications & Data Capture ..............139 Electrical Characteristics................140 Physical Characteristics ................141 Environmental Characteristics..............142 Programming Support ................142 Accessories ..................143...
  • Page 10 A high-spec 5 mega-pixel camera also comes inside to take pictures and shoot videos to deliver better documentation for users. Rated with IP65, the rugged 9700 is light-weighted and easy to cradle in your hand, and will be your good help on field works.
  • Page 11 9700 Mobile Computer (CE) Reference Manual FEATURES Rugged yet smoothened outlined, with hand strap for secure hold IP65-rated tough form to survive drop, shock, heat, cold, and impervious to moisture/dust Windows CE 6.0 OS, TI OMAP3730 1GHz CPU 512MB SDRAM to run application programs...
  • Page 12 Chapter 1 USE MOBILE COMPUTER Before the mobile computer takes part in your work, get to know it first. This chapter includes the basic features of the mobile computer including the power supply, memory, and the units that bridge users with the mobile computer. This chapter helps you set the mobile computer to work at the earliest.
  • Page 13 9700 Mobile Computer (CE) Reference Manual 1.1. TAKE A TOUR This section shows the major components on the mobile computer and inside battery chamber. You will also learn how to power on/off the mobile computer and how the mobile computer gives information about its status.
  • Page 14 Chapter 1 Use Mobile Computer 1.1.2. BEFORE INITIAL USE Prior to using the mobile computer for the first time, we recommend applying the protective film over the LCD. This will prevent scratching the touchscreen during daily usage, and also help enhance the durability of the touchscreen. To apply the LCD protective film: 1) Upon delivery, the touchscreen of the mobile computer is covered with a thin transparent film.
  • Page 15 The mobile computer powers on. 1.1.1. POWER MENU The 9700 mobile computer features a power menu. This menu allows you to select whether you would like to power off the mobile computer, enter suspension, or enter sleeping mode for main battery replacement.
  • Page 16 Chapter 1 Use Mobile Computer Select this option if you would like to power off the mobile computer. This will close all applications and tasks currently running. All Power Off unsaved data will be lost. To power on the mobile computer, press the power button. Selecting this option will close the menu and return to the previously Cancel active screen.
  • Page 17 Config Notification Settings page. To set the good read LED via API deployment, see the (Right) 9700 Programming Guide for details. SPEAKER The mobile computer has a speaker on the back for audio signaling and playback. The speaker sounds for system events, application warnings, on-screen item selection and physical keypad stroke.
  • Page 18 Same as the speaker and LED light, the vibrator also works for good barcode reading. Enable/disable vibration and set its duration on the Reader Config Notification Settings page. Alternatively, program the vibrator through API deployment to have it vibrate when a successful reading occurs. See the 9700 Programming Guide for details.
  • Page 19 Reference Manual 1.4. BATTERY The 9700 mobile computer is fed by two batteries, main battery pack and backup battery. The main battery is removable and replaceable from the battery chamber while the backup battery is mounted on the main board inside the mobile computer.
  • Page 20 Chapter 1 Use Mobile Computer Figure 2: Install main battery Follow the steps below to remove the main battery: 1) A battery located at the lower end of the main battery. Push the latch down and the battery will be released. Note: (1) When main battery level drops to low level, charge it ASAP or replace it with a charged battery.
  • Page 21 9700 Mobile Computer (CE) Reference Manual 1.4.2. CHARGE BATTERIES Due to shipment, it is likely that the main battery and backup battery won’t be fully charged when you receive the package. Before setting the mobile computer to work, charge the main battery to full by direct charging via a power adapter (with the help of a Snap-on Charging &...
  • Page 22 Chapter 1 Use Mobile Computer DIRECT CHARGING USING SNAP-ON CABLE Direct charging of the mobile computer relies on the Snap-on Charging & Communication Cable (hereinafter “snap-on cable”). There is a power jack on the connector of this cable to connect external power. Prior to charging, install the main battery as described in Install/Remove Main Battery.
  • Page 23 9700 Mobile Computer (CE) Reference Manual DIRECT CHARGING USING CRADLE Direct cradle charging makes use of a Charging & Communication Cradle (hereinafter “cradle”). The cradle is one of the accessories you can opt for. Prior to charging, install main battery as described in Install/Remove Main Battery.
  • Page 24 Chapter 1 Use Mobile Computer 1.4.3. MONITOR BATTERY LEVEL The main battery is the only source that feeds the mobile computer to work. It also supplies the backup battery on main board to retain the data stored in DRAM. Hence when main battery level gets low, recharge it or change it as soon as possible.
  • Page 25 9700 Mobile Computer (CE) Reference Manual BATTERY STATUS ICONS The OS features a couple of icons that deliver main battery status. These icons can be found on the taskbar, which is settled at the bottom of every screen. Battery charging icon...
  • Page 26 Chapter 1 Use Mobile Computer LOW BATTERY ALERT When main battery level drops below 40%, the mobile computer prompts “Main Battery Low” for a recharge. When further reduced to under 20%, the mobile computer prompts “Main Battery Very low” to solicit your immediate action. Low battery may incur shutdown to the mobile computer and cause DRAM data damage.
  • Page 27 9700 Mobile Computer (CE) Reference Manual BACKUP BATTERY LEVEL 1) To check backup battery level, tap Start | Settings | Control Panel | Power On Battery tabbed page of Power Properties window, backup battery level is summarized as “Good”, “Low” or “Very Low” under the Power label.
  • Page 28 Chapter 1 Use Mobile Computer LOW BATTERY ALERT When backup battery level drops to “Very Low”, the mobile computer prompts a “Backup Battery Very Low” warning to alert users that backup battery level is almost drained out. Backup battery is rechargeable by the main battery pack or the power adapter. Low backup battery puts DRAM data in great danger.
  • Page 29 9700 Mobile Computer (CE) Reference Manual 1.5. KEYPAD The mobile computer has a physical keypad and a touchscreen to receive user’s input. Among the two, the touchscreen provides more intuitiveness in interacting with the device. This section shows how to input text using physical keypad and on-screen keyboard. To...
  • Page 30 Chapter 1 Use Mobile Computer NUMERIC KEYPAD (30-KEY) The numeric keypad possesses 30 keys, including the number keys 0-9, and Esc, Ctrl, Space, Backspace, Enter and period key (.). Also featured are function keys F1 to F4. The power key is seated at the lower right corner of the keypad.
  • Page 31 By default, these two keys input the functions F14 and F15. You may also SEND/END KEY define their new key functions using CipherLab’s Button Assignment.
  • Page 32 Chapter 1 Use Mobile Computer MODIFIER KEYS The keypads have five different modifier keys integrated on it. The key trigger and recovery methods differ slightly according to keypad type. Keypad Key Location How to enter How to resume Alpha Numeric keypad Available on (30-key) keypad...
  • Page 33 9700 Mobile Computer (CE) Reference Manual Press Alt key first, and upon pressing Numeric and function Available under then press the key to button keypad (38-key) Fn mode deliver the Alt function to. For instance, press Alphanumeric keypad Available under...
  • Page 34 Chapter 1 Use Mobile Computer ALPHA KEY The Alpha key is equipped with an LED indicator. When the Alpha key is pressed, the LED will light up in blue to indicate that Alpha key is activated. When Alpha key is pressed once more, the LED will go off and the keypad will return to normal input mode.
  • Page 35 9700 Mobile Computer (CE) Reference Manual Under Shift mode, press number keys 0-9 to enter Shift+0-9 Numeric & Function keypad Under Shift mode, press arrow keys to move the cursor up, down, right or left (38-key) Under Shift mode, press Backspace key to lock the keypad...
  • Page 36 Chapter 1 Use Mobile Computer 1.5.2. ON-SCREEN KEYBOARD The OS provides users with an on-screen keyboard. The on-screen keyboard supports entering a series of diacritics for European languages by tapping a modifier key. The on-screen keyboard auto-opens in some applications when a text input field is selected. In case the on-screen keyboard doesn’t open automatically, tap the keyboard icon the taskbar and select Keyboard to open it.
  • Page 37 9700 Mobile Computer (CE) Reference Manual MODIFIER KEYS Although the touchscreen is a resistive single-touch type, use of modifier keys, which normally involves hitting two keys, are still available on the on-screen keyboard. On the on-screen keyboard there are four modifier keys, which are seated at the left edge.
  • Page 38 Chapter 1 Use Mobile Computer key on on-screen keyboard. key becomes color-inverted Then tap a character key. Letter variant “ü” is entered After the letter variant “ü” is entered, the on-screen keyboard restores to normal English alphanumeric layout. Diacritical letters and letter variants are presented both in lowercase and uppercase.
  • Page 39 9700 Mobile Computer (CE) Reference Manual Lowercase Uppercase OTHER KEYS Description Tab key Navigates among the highlight items in some applications. For text input, it inserts Tab character, which means it moves caret to the next tab stop. Backspace Erases the characters to the left of caret.
  • Page 40 Chapter 1 Use Mobile Computer CHANGE KEYBOARD ORIENTATION The mobile computer is built-in with a G-sensor and supports screen orientation, which is enabled by default. So when the mobile computer turns sideways or upright, the screen changes its orientation, and on-screen keyboard also readjusts itself to the new orientation. Upright (Portrait Mode) Sideways (Landscape Mode) To disable automatic screen rotation, see...
  • Page 41 9700 Mobile Computer (CE) Reference Manual 1.5.3. EDIT TEXT On the mobile computer, cut, copy, and paste text within an application or across applications by the menu commands. Some applications don’t support editing some or all of the text they display while others may offer their own way to edit text.
  • Page 42 Chapter 1 Use Mobile Computer 1.6. TOUCH CONTROL The mobile computer’s LCD is overlaid by a resistive touch panel and thus forms a resistive touchscreen. Since a resistive touchscreen locates the user’s touch by the force applied on it, by operating with the stylus one can apply minimum force to trigger actions from the touchscreen.
  • Page 43 9700 Mobile Computer (CE) Reference Manual Screen Rotation window opens with three orientation modes to select from and an option to suspend the mobile computer when the screen is facing down. Three screen orientation modes Allows mobile computer to enter suspension when facing down 2) Tap the modes that you wish to enable.
  • Page 44 Chapter 1 Use Mobile Computer SIGNATURE MODE The signature mode is for combined usage with the CipherLab application Signature. With this mode enabled, the screen will immediately rotate 180° when the front of the mobile computer is tilted outwards, which is convenient for signing by a second party.
  • Page 45 9700 Mobile Computer (CE) Reference Manual AUTOMATIC BACKLIGHT PROFILES The mobile computer stores three backlight profiles to represent backlight level under different environments. These can be configured according to user’s likings. To set backlight profiles: 1) Tap Start | Settings | Control Panel | Backlight Setting 2) Uncheck Manual backlight setting to enable profile function.
  • Page 46 Chapter 1 Use Mobile Computer 1.6.4. CALIBRATION A resistive touchscreen needs calibration to work accurately after serving for a period of time. Calibration aligns the coordinates of the touch panel and the LCD underneath to improve touch accuracy. To calibrate the touchscreen: 1) Tap Start | Settings | Control Panel | Stylus 2) Tap Calilbration tabbed page.
  • Page 47 9700 Mobile Computer (CE) Reference Manual 1.7. MEMORY The mobile computer packs the following memory units to retain data and instructions from users: Internal Storage: Random-access Memory (RAM) and Flash memory 512 MB SDRAM for temporary storage and fast access of active applications. When the main battery pack is absent, SDRAM is fed by backup battery to retain data.
  • Page 48 Chapter 1 Use Mobile Computer EXTERNAL STORAGE Tap Start | Settings | Control Panel | Storage Information . The Storage Card label shows the available space on the storage card (if no storage card is installed on the mobile computer, the available size will be displayed as 0).
  • Page 49 9700 Mobile Computer (CE) Reference Manual 1.7.3. INSERT SD CARD Day-to-day use of the mobile computer might cause the available internal storage to run short. Equip the mobile computer with an external memory unit to expand storage capacity. Follow the steps below to install a SD card: 1) Power off the mobile computer.

  • Page 50: Direct Data Communication

    Syncing Tools and subsequent sections to know how to use ActiveSync. Note: The 9700 mobile computer uses COM9 for serial transmission via RS-232. Figure 10: Direct Data Communication Using Snap-on Cable...

  • Page 51: Use Cradle

    9700 Mobile Computer (CE) Reference Manual 1.8.2. USE CRADLE Direct cradle charging makes use of a Charging & Communication Cradle (hereinafter “cradle”). The cradle is one of the accessories you can opt for. Prior to charging, install main battery as described in Install/Remove Main Battery.

  • Page 52: Syncing Tools

    Chapter 1 Use Mobile Computer 1.8.3. SYNCING TOOLS Microsoft’s syncing tools enables users to update or back up the data on their mobile computers to desktop computers. Two syncing tools are featured by Microsoft - ActiveSync and Windows Mobile Device Center (“WMDC”).

  • Page 53: St Usb Sync

    9700 Mobile Computer (CE) Reference Manual 1.8.5. 1 USB SYNC This section will guide you through USB syncing. To connect ActiveSync using USB: 1) Download the right syncing tool as described in Syncing Tools and install it on your PC.

  • Page 54: Disconnect Usb Activesync

    Chapter 1 Use Mobile Computer A “Temporary Relationship” is established between the mobile computer and the PC Note: If you encounter trouble during USB ActiveSync connection, tap Start | Settings | Control Panel | USB Connection and make sure “ActiveSync Serial Mode” is selected.

  • Page 55: Activesync Actions To Take

    9700 Mobile Computer (CE) Reference Manual 1.8.7. ACTIVESYNC ACTIONS TO TAKE Once “Synchronization Relationship” or “Temporary Relationship” is established between two computers, a variety of actions can be taken to enhance resource sharing between them as previously mentioned in Sync Partnership.
  • Page 56 Chapter 1 Use Mobile Computer 4) Select the application program(s) to install to the mobile computer, and deselect the application program(s) to uninstall from the mobile computer. 5) Press the OK button. ActiveSync proceeds to install programs and/or remove programs to/from the mobile computer.
  • Page 57 9700 Mobile Computer (CE) Reference Manual 3) On the PC, from ActiveSync’s menu bar, select Tools | Explore Device, or from its toolbar, press Explore button. The mobile computer’s internal storage root directory “Mobile Device” opens presenting a few folders (and files).
  • Page 58 Chapter 1 Use Mobile Computer REMOVE ITEMS FROM START MENU To remove an added shortcut from Start menu, simply use ActiveSync’s Explore delete the shortcut from My Device\Windows\Programs folder. You can also remove an added shortcut from Start menu directly on the mobile computer. Add Items to Start Menu for more details.
  • Page 59 9700 Mobile Computer (CE) Reference Manual BACKUP DATA To best protect your work, back up the data on your mobile computer regularly. You may choose to manually back up using ActiveSync to copy & paste the files to your PC.

  • Page 60: Volume And Audio

    Chapter 1 Use Mobile Computer 1.9. VOLUME AND AUDIO 1.9.1. AUDIO PLAYBACK Use a headset for audio playback and hands-free telephone communication. The headset jack (3.5 mm DIA) is built up on one side of the mobile computer and sealed with a hinged rubber.
  • Page 61 9700 Mobile Computer (CE) Reference Manual...

  • Page 62: Operating System

    Chapter 2 OPERATING SYSTEM The mobile computer is powered by Windows Embedded Compact 7.0, a member of Windows Embedded family. Windows Embedded Compact 7.0 bears much similarity to desktop OS, and users rely only on a few basic gestures such as tap, double-tap and drag to navigate within the OS 2.

  • Page 63: Desktop

    Chapter 2 Operating System 2.1. DESKTOP Desktop is where all features on the mobile computer are accessed from. Basic operations on the desktop: Tap the Start button to open the Start menu. Double-tap an application icon on the desktop to open it. Tap a blank spot on the desktop to open an option menu for customizing the wallpaper and the items to display.

  • Page 64: Taskbar

    Chapter 2 Operating System 2.1.1. TASKBAR At the bottom of the screen is the taskbar, which is divided into the following sections: Start button: opens Start menu Task button section that shows a button of the current application open on-screen Notification area which displays icons for connection status of the mobile computer, as well as system time A keyboard icon for switching input mode...

  • Page 65: Start Menu

    9700 Mobile Computer (CE) Reference Manual A specific wireless connection is terminated or has failed. Double-tap the icon to open a window to check IP information. Included connections are: Bluetooth PAN 802.11a/b/g/n WWAN A specific wireless connection has been established successfully.

  • Page 66: Customize Desktop And Start Menu

    Chapter 2 Operating System 2.1.3. CUSTOMIZE DESKTOP AND START MENU Customize the desktop by changing the background, application shortcuts, and so on. Rearrange the application shortcuts to make the applications that you use most often easy to access. CHANGE BACKGROUND You may change the background of the desktop to a picture of your own choice.
  • Page 67 9700 Mobile Computer (CE) Reference Manual The selected file will appear on the desktop as the background image. CHANGE APPEARANCE You may change the overall scheme, color of title bars, dialog boxes, menu text, selected items and so on to suit your preferences.
  • Page 68 Chapter 2 Operating System ADD ITEMS TO DESKTOP ADD APPLICATION SHORTCUTS 1) On the mobile computer, tap My Device on the desktop. 2) Browse to the executable file of the program you would like to create a shortcut for. 3) Tap and hold the file. A pop-up menu will show on the screen. 4) Tap Copy in the pop-up menu.
  • Page 69 9700 Mobile Computer (CE) Reference Manual A shortcut to the program is added to the Start Menu. REMOVE ITEMS FROM START MENU 13)On the mobile computer, tap My Device on the desktop. 14)Browse to My Device\Windows\Programs. Programs folder opens. All applications available in the Start menu can be found here.

  • Page 70: Managing Programs

    2) Tap the desired program to launch it on-screen. The programs pre-installed on the mobile computer include: Icon Description CIPHERLAB UTILITIES (Reserved folder.) APPLOCK AppLock limits access to programs and settings on the mobile computer through an authorization mechanism. See the AppLock User Guide for details.

  • Page 71: Switch Between Active Tasks

    9700 Mobile Computer (CE) Reference Manual MEDIA PLAYER Audio/video file player. MICROSOFT WORDPAD Wordpad for entering text. REMOTE DESKTOP CONNECTION Program for connection to a remote computer. SIGNATURE Signature application which is available for C++ programming via API deployment. See the CP60 C++ Programming Guide for details.

  • Page 72: Install Applications

    Chapter 2 Operating System 2.2.4. INSTALL APPLICATIONS As mentioned in Add/Remove Programs, you can download and install an application on your PC first and offload it to the mobile computer later using Microsoft ActiveSync. Alternatively, the OS allows you to install an application right from the mobile computer. Follow the steps below to complete installation: 1) Using your PC, copy the installation file (.CAB) to the mobile computer’s internal storage via ActiveSync.
  • Page 73 9700 Mobile Computer (CE) Reference Manual 4) When installation is finished, launch it by tapping Start | Programs and locating it in the Programs menu. Alternatively, you may download an application to install from the Internet. See Use Wi-Fi for how to connect the mobile computer to the Internet.
  • Page 74 Chapter 2 Operating System UNINSTALL APPLICATIONS On the mobile computer, the acquired (non-inherent) applications can be depleted from the OS through manual removal (uninstallation). To uninstall an application: 1) Tap Start | Settings | Control Panel | Remove Programs Remove Programs opens showing the applications downloaded and installed from external sources.

  • Page 75: Suspend & Reset Mobile Computer

    9700 Mobile Computer (CE) Reference Manual 2.3. SUSPEND & RESET MOBILE COMPUTER To save from repeatedly charging and replacing batteries, suspend the mobile computer when you are not actively using it. Suspending (or “turning off”) the mobile computer holds the device from running without cutting off power. It is a “soft-off” state which enables less power consumption, and also a state which the device can quickly awake from since there is no need to restart the OS and applications.

  • Page 76: Wake Up Mobile Computer

    Chapter 2 Operating System 2.3.2. WAKE UP MOBILE COMPUTER “Waking up” refers to restoring the suspended device to its previous working state. The mobile computer can be awoken both manually and automatically. MANUAL AWAKENING Press (without holding) the power button or central scan key to wake up the mobile computer.

  • Page 77: Restart Mobile Comptuer

    9700 Mobile Computer (CE) Reference Manual 2.3.3. RESTART MOBILE COMPTUER When the system becomes erroneous and applications fail to respond properly, proceed to restart the mobile computer. After the mobile computer is restarted, DRAM will be initialized, and all data cached in DRAM and any unsaved tasks will be erased. However all user data, system settings and clock/calendar time will be preserved.

  • Page 78: Radios

    Chapter 3 RADIOS The mobile computer is a versatile networker. It integrates Wi-Fi and Bluetooth for wireless data. With the help of these radios, the mobile computer keeps users online all the time. In this chapter, you will learn how these radios can work for you. 3.

  • Page 79: Use Wi-Fi

    9700 Mobile Computer (CE) Reference Manual 3.1. USE WI-FI The mobile computer is capable of Wi-Fi, a wireless networking technology making use of an access point, also known as “hotspot”, to connect to a wireless local area network. To use Wi-Fi, the mobile computer has to connect to a hotspot. Some hotspots are open for connection while others request a key to authenticate access.
  • Page 80 Chapter 3 Radios Note: Wi-Fi power settings under Wireless Manager will be kept through suspension and warm boot/cold boot. After the mobile computer resumes from suspension or restarts, Wi-Fi power status will be maintained and the mobile computer will attempt to reconnect the previous connection.

  • Page 81: Launch Scu

    9700 Mobile Computer (CE) Reference Manual 3.1.2. LAUNCH SCU Wi-Fi settings can be adjusted with Summit Client Utility. Within this application are three tabbed pages which allow users to select the access point for connection, create profiles for better management, perform diagnostics on connectivity, and fine-tune property settings to meet their individual requirements.

  • Page 82: Status Tabbed Page

    Chapter 3 Radios 3.1.3. STATUS TABBED PAGE The Status tabbed page provides basic information on WLAN connection and Bluetooth status. Wi-Fi settings can be configured on Configuration Tabbed Page. Wi-Fi status Bluetooth status (service coming soon) Note: SCU does not currently support viewing or configuring Bluetooth settings.

  • Page 83: Configuration Tabbed Page

    9700 Mobile Computer (CE) Reference Manual 3.1.4. CONFIGURATION TABBED PAGE TURN ON/OFF WI-FI MODULE Select the Wi-Fi checkbox to turn on Wi-Fi. Deselect it to shut down Wi-Fi. Turn on Wi-Fi module Note: SCU does not allow configuration of Bluetooth settings. To establish and manage...
  • Page 84 Chapter 3 Radios ACTIVE PROFILE A profile is a set of parameters that define the manner which a device associates to a wireless LAN (WLAN) infrastructure. A profile contains information including the System Set Identifier (SSID, the "name" of the WLAN infrastructure), means of data encryption, authentication type, and security credentials.
  • Page 85 9700 Mobile Computer (CE) Reference Manual CREATE WI-FI PROFILE To create a Wi-Fi Profile: 1) Open SCU as described in Launch SCU. 2) Tap the Configuration tab to show the Configuration tabbed page. 3) Tap Scan to view a list of access points that are broadcasting their SSIDs. You may sort the list by tapping the column headers.
  • Page 86 Chapter 3 Radios 5) A profile settings page opens showing detailed radio settings. Tap each item and adjust its Value to suit your needs. 6) When finished fine-tuning all settings, tap Commit to save the profile. 7) Tap OK on the title bar to close the Profile Settings page and return to Configuration settings.
  • Page 87 9700 Mobile Computer (CE) Reference Manual MANAGE WI-FI PROFILE To manage your profiles: 1) Open SCU’s Configuration tabbed page as described in Create Wi-Fi Profile. 2) Tap Manage Profiles to open the Profile settings page. Item Description Profile When SCU is first launched, “Default” is the active profile. Unless it is modified, this profile does not specify an SSID, EAP type or encryption method.
  • Page 88 Chapter 3 Radios Tap New and enter a unique name for the profile. Configure the Radio settings, Encryption, EAP Type, and other settings for this new profile. The name for each profile must be unique You can define up to 20 profiles Delete Select a profile from the drop-down menu and tap Delete.
  • Page 89 9700 Mobile Computer (CE) Reference Manual Radio After selecting a profile in the Profile drop-down bar, configure radio settings in the Settings scrollable menu below. Property Description Profile Name Tap to rename the selected profile. Up to 32 characters allowed.
  • Page 90 Chapter 3 Radios Maximum In Max Power Savings (Max PSP) mode, the access point buffers incoming messages for the radio, which wakes up periodically and connects to the access point to see if any buffered messages are waiting. The radio requests buffered messages and then goes back to sleep.
  • Page 91 9700 Mobile Computer (CE) Reference Manual Ad Hoc When selected, Summit radio associates to another station radio that is in ad hoc mode and has the same SSID and, if configured, static WEP key. Default: ABG rates full Auth Type 802.11 authentication type used when associating to an AP.
  • Page 92 Chapter 3 Radios Password (up to 32 characters) PAC Filename (up to 32 characters): You may create a protected access credential (PAC) for each client device. When creating a PAC manually, you must store it in the directory identified in Certs Path on the Globals settings page.
  • Page 93 9700 Mobile Computer (CE) Reference Manual Commit After making any changes on the Profile tabbed page, the Commit button must be tapped in order for the settings to take effect.
  • Page 94 Chapter 3 Radios MANAGE GLOBAL SETTINGS Global settings include radio and security settings that apply to all profiles in SCU. To open the Global settings page: 1) Open SCU’s Configuration tabbed page as described in Create Wi-Fi Profile. 2) Tap Manage Profiles to open the Profile settings page. 3) Tap the Globals tab to open the Global settings page.
  • Page 95 9700 Mobile Computer (CE) Reference Manual 1, 7, 13 For ETSI and TELEC radios only Custom Indicates the system registry has been edited to include a value other than those available in the drop-down value Default: Full DFS Channels Indicates whether to support 5 GHz (802.11a) channels where dynamic frequency selection (DFS) is required.
  • Page 96 Chapter 3 Radios Auth Server Type of authentication server being used for EAP authentication. Value: Type 1 Cisco Secure ACS or another server that uses PEAPv1 PEAP with EAP-MSCHAPV2 (PEAP-MSCHAP) Type 2 A different authentication server, such as Juniper Networks Steel Belted RADIUS, that uses PEAPv0 for PEAP-MSCHAP Default: Type 1 TTLS Inner Method...
  • Page 97 9700 Mobile Computer (CE) Reference Manual Admin Password Auth Timeout (s) Specifies how long it will wait for an EAP authentication request to succeed or fail. If authentication credentials are specified in the active profile and the authentication times out, then association will fail. If authentication credentials are not specified in the active profile and the authentication times out, then the user will be required to enter credentials again.

  • Page 98: Diagnostics Tabbed Page

    Chapter 3 Radios 3.1.5. DIAGNOSTICS TABBED PAGE Perform diagnostic tests to troubleshoot connection issues when necessary. To open the Diagnostics page: 1) Open SCU as described in Launch SCU. 2) Tap the Diagnostics tab to show the Diagnostics page. Diagnostics status for Wi-Fi and Bluetooth shows, along with on-screen buttons to open Advanced settings and view software version information.
  • Page 99 9700 Mobile Computer (CE) Reference Manual ADVANCED DIAGNOSTICS To access Advanced diagnostics settings: 1) Open Diagnostics Tabbed Page. 2) Tap the Advanced button to open advanced diagnostics settings. CHECK STATUS To check diagnostics status, select Status in the drop-down bar.
  • Page 100 Chapter 3 Radios USE PING TOOLS To perform ping tests, select Ping Tools in the drop-down bar. Select Ping Tools to diagnose the connection Device IP address AP Name Item Description Destination Enter the address to ping. Ping Payload The amount of data to be transmitted on a ping. Value: 32, 64, 128, 256, 512, 1024 Default: 32 (bytes) Ping Delay...
  • Page 101 9700 Mobile Computer (CE) Reference Manual When an active ping is initiated, the screen displays a ping indicator that blinks in green (for a successful ping) or red (for an unsuccessful ping). The ping indicator is hidden when the screen is switched to a tab other than Diags or Status...
  • Page 102 Chapter 3 Radios Reconnect Disable and enable the radio, apply or re-apply the current profile, attempt to associate and authenticate to the wireless network, and log all activity in the output area at the bottom.
  • Page 103 9700 Mobile Computer (CE) Reference Manual USE DEBUG TOOLS To check debug settings, select Debug in the drop-down bar. Select Debug to check debug settings Item Description Driver Debug Select whether to debug the WLAN driver, and the output mode for driver debug.
  • Page 104 Chapter 3 Radios SOFTWARE VERSION INFORMATION To check software version information: 1) Open Diagnostics Tabbed Page. 2) Tap the About button to view information about SCU version, device driver, and software developer.

  • Page 105: Use Bluetooth

    9700 Mobile Computer (CE) Reference Manual 3.2. USE BLUETOOTH The mobile computer is Bluetooth-enabled to synchronize data with other devices such as PCs, car hands-free kits, headsets, printers, PDAs, and cell phones. Class II Bluetooth devices enable wireless connections over a short distance of around 10 meters.
  • Page 106 Chapter 3 Radios Device ID tabbed page opens. Change device name to make the mobile computer more recognizable. 3) Enter a name of your choice. 4) Tap OK on the title bar to apply the change.

  • Page 107: Turn On/Off Bluetooth

    9700 Mobile Computer (CE) Reference Manual 3.2.3. TURN ON/OFF BLUETOOTH To turn on/off Bluetooth power: 1) Tap Start | Settings | Control Panel | Wireless Manager Wireless Manager opens. 2) Make sure the Bluetooth label is turned “on” If the Bluetooth label is turned “off”, tap the “Off” icon to switch on Bluetooth power.

  • Page 108: Set Bluetooth Visibility

    Chapter 3 Radios 3.2.4. SET BLUETOOTH VISIBILITY By opening or closing Bluetooth visibility, you can control whether or not other Bluetooth devices can discover the mobile computer. To set Bluetooth visibility on the mobile computer: 1) Tap the Bluetooth icon on the taskbar and select Setting in the pop-up menu.

  • Page 109: Launch Bt Connect

    9700 Mobile Computer (CE) Reference Manual 3.2.5. LAUNCH BT CONNECT BT Connect is a connection tool for establishing Bluetooth partnerships. To launch BT Connect: 1) Tap the Bluetooth icon on the taskbar and select Maximized in the pop-up menu. BT Connect launches with a menu bar on top and a blank field for searching devices.

  • Page 110: Search For Bluetooth Devices

    Chapter 3 Radios 3.2.6. SEARCH FOR BLUETOOTH DEVICES To search for a Bluetooth device to connect to: 1) Tap Device to discover Bluetooth devices nearby. Wait for a few seconds for the mobile computer to list all the discovered devices. 2) If the device that you wish to connect to is not listed, make sure its Bluetooth status is set as discoverable.

  • Page 111: Pair Bluetooth Devices

    9700 Mobile Computer (CE) Reference Manual 3.2.7. PAIR BLUETOOTH DEVICES IDENTIFY BLUETOOTH DEVICE To check the identity of a Bluetooth device: 1) Open BT-Connect page as described in Launch BT Connect. 2) In the device list, tap and hold a device until a pop-up menu appears.
  • Page 112 Chapter 3 Radios PAIR If authentication is enabled on the Bluetooth device, pairing will be required to connect to that device. Pairing can be done by using a pin code to ensure secure Bluetooth connection. 1) In the device list, tap and hold the device to pair with. Select Pair in the pop-up menu. 2) Enter a pin code in the pop-up window that appears.
  • Page 113 9700 Mobile Computer (CE) Reference Manual Once the mobile computer and the remote Bluetooth device are paired, a lock icon will be displayed next to the device. 4) Double-tap the device to find out which Bluetooth services are available. 5) Tap and hold a desired Bluetooth service to take further actions.
  • Page 114 Chapter 3 Radios UNPAIR To unpair a Bluetooth device: 1) In the device list, tap and hold the device to unpair. A pop-up menu will appear. 2) Select Unpair in the pop-up menu.

  • Page 115: Bluetooth Data Transfer

    9700 Mobile Computer (CE) Reference Manual 3.2.8. BLUETOOTH DATA TRANSFER After the mobile computer is paired to a remote Bluetooth Device, it is ready to begin Bluetooth data communication. FILE TRANSFER To exchange files via file transfer (FTP) service: 1) On the Device page, double-tap the paired Bluetooth device.
  • Page 116 Chapter 3 Radios 4) Select an object to transfer to the paired Bluetooth device. On the remote Bluetooth device, the object will be stored under the directory specified on Service page | FTP Transfer | Change Local Path. 5) To store a transferred file to the specified local path on the mobile computer, tap and hold a file and select Get File in the pop-up menu.
  • Page 117 9700 Mobile Computer (CE) Reference Manual OBJECT PUSH To use object push (OPP) service to send an object to a remote Bluetooth device: 1) On the Device page, double-tap the paired Bluetooth device to open a page showing its available services.
  • Page 118 Chapter 3 Radios 3) Select an object to transfer to the paired Bluetooth device. Wait for a few moments while the file transfers to the remote Bluetooth device. 4) On the remote Bluetooth device, the object will be stored under the directory specified on Service page | Object Push | Change Local Path.
  • Page 119 9700 Mobile Computer (CE) Reference Manual PAN SERVICE To use personal area network (PAN) service shared by the Bluetooth device to connect to the Internet: 1) On the Device page, double-tap the paired Bluetooth device to open a page showing its available services.
  • Page 120 Chapter 3 Radios SERIAL PORT SERVICE To use Serial Port Service: 1) On the Service page, check if the Bluetooth virtual COM port is occupied by the local SPP service (i.e. whether a green connection icon is present). If so, tap and hold the service and select Unload in the pop-up menu.
  • Page 121 9700 Mobile Computer (CE) Reference Manual 2) On the Device tab, double-tap the paired device to open a page showing the available services for that device. 3) Tap and hold Serial Port Service and select Connect in the pop-up menu.
  • Page 122 Chapter 3 Radios 4) By default, the mobile computer uses COM6 as the Bluetooth SPP COM port. Tap OK in the pop-up window to confirm. 5) A connection icon appears to indicate that serial port service is now active.
  • Page 123 9700 Mobile Computer (CE) Reference Manual BLUETOOTH ACTIVESYNC To create ActiveSync connection between your PC and mobile computer via Bluetooth, first you will need to configure Bluetooth settings on your PC. 1) On your PC, configure necessary Bluetooth settings, such as turn Bluetooth discovery on, allow other Bluetooth devices to connect to the PC, and add a COM port for incoming connection.
  • Page 124 Chapter 3 Radios 3) On the mobile computer, make sure Serial Port Service is enabled in BT Manager. 4) On the Device page, double-tap your PC to view its available services. 5) Tap and hold Serial Port Services and select ActiveSync via BT in the pop-up menu. The mobile computer then connects to your PC via ActiveSync.

  • Page 125: Re-Connection

    9700 Mobile Computer (CE) Reference Manual 3.2.9. RE-CONNECTION By default, BT-Connect will automatically re-connect to the previous services the next time the mobile computer goes through a Bluetooth power cycle. The preferred devices and services will also be reflected on the Preference tabbed page of Manager.

  • Page 126: Preferred Services

    Chapter 3 Radios 3.2.10. PREFERRED SERVICES On the Device tabbed page in BT-Connect, double-tap the preferred device to view its available Bluetooth service(s). Example Service Status Settings in BT-Manager The service is re-connected ( ). Last Connection = Y (on the Preference Tab) The service is available for re-connection.

  • Page 127: Manage Local Services

    9700 Mobile Computer (CE) Reference Manual 3.2.11. MANAGE LOCAL SERVICES LOAD/UNLOAD SERVICE You may select to load or unload a certain service. When a service is unloaded, it will become unavailable to paired Bluetooth devices. When it is re-loaded, it will become available once more.
  • Page 128 Chapter 3 Radios CHANGE LOCAL PATH For File Transfer and Object Push services, you may change the path for file exchange. 1) On the Service page, tap and hold an item to open a pop-up menu. Select Change Local Path in the pop-up menu and enter an inbox storage path. 2) Tap OK to confirm the change.

  • Page 129: Bt Manager

    9700 Mobile Computer (CE) Reference Manual 3.2.12. BT MANAGER Advanced Bluetooth settings regarding Bluetooth reconnection, Bluetooth inquiry time and more can be adjusted using BT Manager. 1) Tap Start | Settings | Control Panel | BT Manager Tap the Bluetooth icon on the Wireless Manager settings page.
  • Page 130 Chapter 3 Radios GENERAL TAB This page sets whether to allow reconnection of Bluetooth services and auto-inquiry of Bluetooth devices. Tap to restore default settings Tap to save changes Setting Description Allow to resume last service Select to automatically re-connect to all previous Bluetooth services after the mobile computer resumes from warm boot/cold boot, or goes through a Bluetooth power cycle.
  • Page 131 9700 Mobile Computer (CE) Reference Manual PREFERENCE TAB BT Manager helps sort out preference for all remote services which were previously connected/disconnected. Select a desired service type from the drop-down menu: Headset/Handsfree Others (FTP, OPP, and DUN) MANAGING BLUETOOTH SERVICES...
  • Page 132 Chapter 3 Radios CONFIGURING CONNECTION SETTINGS Change the connection preference for a specific service by enabling (selecting Y) or disabling (selecting N) the last two columns, Last Connection and Auto Inquiry. If you select Y for Last Connection or Auto Inquiry, “Allow to resume last service” and “Auto Inquiry”...
  • Page 133 9700 Mobile Computer (CE) Reference Manual SAVING PREFERENCE CHANGES After making changes to preference settings, tap Apply. A warning dialog will show reminding that for the settings to take effect, you will need to restart Bluetooth power. Proceed to perform a Bluetooth power cycle as in Turn On/Off Bluetooth.
  • Page 134 Chapter 3 Radios ABOUT TAB This page delivers version and copyright information about the software.
  • Page 135 9700 Mobile Computer (CE) Reference Manual...

  • Page 136: Manage Mobile Computer

    Chapter 4 MANAGE MOBILE COMPUTER This chapter guides you to the system settings featured by the OS. Access these settings to define how the mobile computer looks, sounds, stores/secures your data, manages the applications, or exchanges data with your networks or other devices. This chapter also includes the process for updating the OS image.

  • Page 137: Control Panel

    9700 Mobile Computer (CE) Reference Manual 4.1. CONTROL PANEL To access control panel settings: Tap Start | Settings | Control Panel to display a window listing all the programs installed on the mobile computer. Icon Description BACKLIGHT SETTING Sets screen and keypad timeout and brightness. Four tabs are featured – Brightness, Battery Power, External Power, and Profile.
  • Page 138 Chapter 4 Manage Mobile Computer Turn on keypad backlight when a button is Checked pressed External Power Sets the screen backlight timeout on external power and whether to trigger screen/keypad light up upon pressing a key. Option Default Settings Turn off LCD backlight if device is not used Checked;...
  • Page 139 9700 Mobile Computer (CE) Reference Manual Calibration. HF RFID CONFIGURATION Configures the RFID reader and displays test scan results. See Use HF RFID Configuration. INPUT PANEL Select an input method and tap Options to make further adjustments. Set whether to allow applications change input panel state.
  • Page 140 Chapter 4 Manage Mobile Computer POWER Displays battery level and sets up power plans. Two tabs are featured – Battery and Power Off. Tabbed Page Description Battery Delivers a summary of battery level for main & backup batteries, and also denotes the main battery level percentage. Schemes Sets a power scheme to switch the mobile computer to suspend after a specified amount of time.
  • Page 141 9700 Mobile Computer (CE) Reference Manual STORAGE INFORMATION Provides storage status of the internal storage (which is divided into System files and User data) and external storage on the mobile computer. Label Description System Shows total size and available size of storage under the System directory.
  • Page 142 Chapter 4 Manage Mobile Computer Keypad 0: None 3: Numeric (30-key) 4: Numeric & Function (38-key) 5: Alphanumeric (53-key) 6: Alphanumeric (53-key) 7: Alphanumeric (53-key) 0: None 3: QVGA Touch panel 0: None 1: 3.5” QVGA Transflective TERMINAL SERVER CLIENT Logs onto a Windows Terminal Server or a remote computer through remote desktop connection.
  • Page 143 9700 Mobile Computer (CE) Reference Manual VOLUME & SOUNDS Volume tab: Adjusts system sounds and volume for events, applications, notifications and stylus movements. Sounds tab: Changes event sounds to meet your preferences and save them as schemes. WIRELESS MANAGER Enables/disables Bluetooth, Wi-Fi and cellular data power status.

  • Page 144: Connection Settings

    Chapter 4 Manage Mobile Computer 4.2. CONNECTION SETTINGS To access connection settings: Tap Start | Settings | Control Panel | Network and Dial-up Connections. Tap Start | Settings | Network and Dial-up Connections. Icon Description MAKE NEW CONNECTION Tap to create a new connection which is not listed. USB SERIAL Sets serial profile for USB connection to a PC via ActiveSync.
  • Page 145 9700 Mobile Computer (CE) Reference Manual The taskbar items deliver the following functions: Button Description Tap this button to open the Connection menu. The available options depend on the connection you select. Tap this button to toggle on/off the connection you select. This can be used for Enable/Disable or Connect/Disconnect.

  • Page 146: Taskbar And Start Menu Settings

    Chapter 4 Manage Mobile Computer 4.3. TASKBAR AND START MENU SETTINGS To access taskbar and Start Menu settings: Tap Start | Settings | Taskbar and Start Menu. Tabbed page Setting Description General Always on top Select to keep the taskbar at the top of the screen, even when an application is open.
  • Page 147 9700 Mobile Computer (CE) Reference Manual...

  • Page 148: Specifications

    SPECIFICATIONS PLATFORM, PROCESSOR & MEMORY Operating System & CPU OS Version Microsoft Windows Embedded Compact 7.0 TI OMAP4430 1GHz Processor Memory 512MB DDR SDRAM Flash 4GB Flash ROM Expansion Slot One expansion slot, supports MicroSDHC up to 32GB COMMUNICATIONS & DATA CAPTURE Communications USB Host/Client USB 2.0...

  • Page 149: Electrical Characteristics

    9700 Mobile Computer (CE) Reference Manual ELECTRICAL CHARACTERISTICS Batteries Main Battery Pack Standard capacity battery: 3.7V, 3300 mAh Large capacity battery: 3.7V, 5400 mAh Rechargeable Li-ion battery Charging time: approximately 4 hours for standard battery / 6 hours for large capacity battery Backup Battery 3.6V, 15 mAh...

  • Page 150: Physical Characteristics

    Specifications PHYSICAL CHARACTERISTICS Color Tap Screen Display Display 3.5” Transflective TFT-LCD, 65K colors, sunlight readable Resolution QVGA 240 (W) x 320 (H) Keypad Layout Numeric keypad (30-key), Numeric & Function keypad (38-key), or Alphanumeric keypad (53-key) Backlight White LED backlight for display and keypad Notifications Status LED Three LEDs for showing scanning good read, radio connection...

  • Page 151: Environmental Characteristics

    IP65 per applicable IEC 60529 sealing specs Electrostatic Discharge ± 15 kV air discharge, ± 8 kV contact discharge Note: CipherLab will not be held responsible for the mobile computer’s malfunction incurred by the operation outside operating temperature range. PROGRAMMING SUPPORT Development Environment &...

  • Page 152: Accessories

    Specifications Third-party software SOTI MobiControl for remote device control Naurtech CETerm – Terminal emulator (3270, 5250, VT) and industrial web browser SYSDEV Kalipso ACCESSORIES Accessory Options Snap-on Charging and Communication Cable (USB or RS-232) Charging & Communication Cradle Pistol Grip Snap-on Car Charger 4-Slot Battery Charger 4-Slot Terminal Cradle...

Table of Contents
