9700 Mobile Computer (WEH)
Keypad Fn key
30-key
38-key
53-key Not
available
Note: Function mode can coexist with Alpha mode. When both modes are active, the
dominant mode depends on the last pressed key. If you press Alpha key and then
press Function key, Function mode will be the effective for the next pressed key.
KEYPAD LOCK
All three keypads feature a keypad lock mode, which can be triggered by pressing a hot key
combination. When the keypad lock mode is triggered, all keys on the keypad will become
locked to prevent any accidental pressing of keys. A keypad lock icon
the title bar to indicate keys are currently locked.
To release the keypad lock mode, press the keypad lock hot key combination again. The
input mode on the mobile computer will return to default state.
To trigger or release keypad lock mode:
On the 30-key keypad, press the Function key followed by the backspace key

On the 38-key keypad, press the Function key followed by the backspace key

On the 53-key keypad, press the Shift key followed by the backspace key

Note: Under keypad lock mode, the only available keys aside from the keypad lock button
itself are the power key and scan keys.
26
Key Function

Under Function mode, press number keys 1-4 and function keys F1-F4 to
enter function keys F5-F12
 Under Function mode, press other number keys to adjust volume, touch
screen backlight or enter a hyphen (-)
 Under Function mode, press arrow keys to deliver Home, End, Page Up,
Page Down
 Under Function mode, press Ctrl key to activate Alt key
 Under Function mode, press Backspace to lock the keypad
 Under Function mode, press space key to open the Start screen
 Under Function mode, press number keys 1-4 and function keys F1-F4 to
enter function keys F11-F14
 Under Function mode, press other Fn keys to adjust volume, touch screen
backlight

Under Function mode, press arrow keys to deliver Home, End, Page Up,
Page Down
 Under Function mode, press Ctrl key to activate Alt key

Under Function mode, press Backspace to lock the keypad
 Under Function mode, press space key to open the Start screen
None
Reference Manual
will appear on
