9700 Mobile Computer (WEH)
Advanced tab
page
DOMAIN ENROLL
Connects to a SCMDM (System Center Mobile Device Manager) server with an
enrollment ID and password. SCMDM enables the management of multiple mobile
computers.
USB TO PC
Enables/disables RNDIS (Remote Network Driver Interface Specification). Open
USB to PC and deselect Enable advanced network functionality to disable RNDIS
and enable PPP.
Note deselecting Enable advanced network functionality will disable USB Internet
Sharing.
170
needed.

Manage existing connections
Edits
Internet.
My Work Creates mobile data connection to an internal
Network network (intranet) or a VPN. For enterprise network
to access Internet, proxy server setting which is
usually required is supported.
 Add a new modem connection
Creates a mobile data connection to internal
network (intranet) or VPN. Request network
administrator for the information needed.

Add a new VPN server connection
Sets up a VPN connection. Request your VPN
administrator for the details required.
After a VPN is set up, Add a new VPN server
connection changes to Edit my VPN servers.
 Set up my proxy server
Sets up the proxy server by which an enterprise
network connects to Internet.
After a proxy server is set up, Set up my proxy
server changes to Edit my proxy server.
 Manage existing connections
Edits existing mobile data connection to internal
network (intranet) or
network
information.
Featured settings are:
Setting Description
Select Networks Sets which network to auto use when accessing
Internet or a private network.
Dialing Rules... Sets where you are dialing from so you don't have
to create a new connection on a different location.
Exceptions... Enters the address of the intranet to access in
case it includes a period.
existing mobile data
VPN. Request your
administrator
Reference Manual
connection to
for the related
