Page 1 Windows Embedded Compact 6.0 Mobile Computer 9700 Version 1.00...
Page 2: Disclaimer
The information contained in this document, including all pictures, illustrations and software, is the proprietary information of CIPHERLAB CO., LTD. and its respective legal owners; it is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties, with all rights reserved.
Page 3: Safety Notices
SAFETY NOTICES FOR HAND-HELD PRODUCT WITH RF FUNCTIONS This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. FOR CANADA This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled "Digital...
Page 4: Safety Precautions
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. The use of any batteries or charging devices which are not originally sold or manufactured by CipherLab will void your warranty and may cause damage to human body or the product itself.
Page 5 DECLARATION OF CONFORMITY...
Page 6: Release Notes
RELEASE NOTES Version Date Notes 1.00 Jun 20, 2014 Initial release...
Page 7: Table Of Contents
CONTENTS PREFACE ....................- 2 - Copyright.................... - 2 - Disclaimer................... - 2 - Trademark Recognition ................- 2 - Contact ....................- 2 - Safety Notices..................- 3 - For Hand-held Product with RF Functions ..........- 3 - For Canada ..................- 3 - For United States................
Page 8 5.7.3. Insert SD Card ..............42 5.8. Direct Data Communication ............43 5.8.1. Use Snap-on Cable ..............43 5.8.2. Use Cradle................44 5.8.3. Syncing Tools ............... 45 5.8.4. Sync Partnership ..............45 5.8.5. USB Sync ................. 46 5.8.6. Disconnect USB ActiveSync ............47 5.8.7.
Page 9 4.2.7. Pair Bluetooth Devices ............124 4.2.8. Bluetooth Data Transfer ............128 4.2.9. Re-Connection ..............138 4.2.10. Preferred Services ..............139 4.2.11. Manage Local Services ............140 4.2.12. BT Manager ................142 MORE APPLICATIONS................. 149 5.1. Button Assignment ..............150 5.1.1. Launch Button Assignment ............150 5.1.2. Redefine Keys ..............151 5.1.3.
Page 10 LASER (SE1524) ..................221 Symbology Settings .................221 Miscellaneous ..................226 2D IMAGER (SE4500DL)................227 Symbology Settings .................227 1D Symbologies ..................227 2D Symbologies ..................234 Miscellaneous ..................235 2D IMAGER (EX25) ..................237 Symbology Settings .................237 1D Symbologies ..................237 2D Symbologies ..................243 Miscellaneous ..................244 PHYSICAL KEYPAD REFERENCE TABLE ............
Page 11: Introduction
Dedicated to data capture, the mobile computer has essential 1D (laser) reader or 2D imager. Rated with IP65, the rugged 9700 is light-weighted and easy to cradle in your hand, and will be your good help on field works.
Page 12: Features
9700 Mobile Computer (CE) Reference Manual FEATURES Rugged yet smoothened outlined, with hand strap for secure hold IP65-rated tough form to survive drop, shock, heat, cold, and impervious to moisture/dust Windows CE 6.0 OS, TI OMAP3730 1GHz CPU 512MB SDRAM to run application programs...
Page 13: Use Mobile Computer
Chapter 1 USE MOBILE COMPUTER Before the mobile computer takes part in your work, get to know it first. This chapter includes the basic features of the mobile computer including the power supply, memory, and the units that bridge users with the mobile computer. This chapter helps you set the mobile computer to work at the earliest.
Page 14: Take A Tour
9700 Mobile Computer (CE) Reference Manual 1.1. TAKE A TOUR This section shows the major components on the mobile computer and inside battery chamber. You will also learn how to power on/off the mobile computer and how the mobile computer gives information about its status.
Page 15: Before Initial Use
Chapter 1 Use Mobile Computer 1.1.2. BEFORE INITIAL USE Prior to using the mobile computer for the first time, we recommend applying the protective film over the LCD. This will prevent scratching the touchscreen during daily usage, and also help enhance the durability of the touchscreen. To apply the LCD protective film: 1) Upon delivery, the touchscreen of the mobile computer is covered with a thin transparent film.
Page 16: Power On/Off Mobile Computer
The mobile computer powers on. 1.2.1. POWER MENU The 9700 mobile computer features a power menu. This menu allows you to select whether you would like to power off the mobile computer, enter suspension, or enter sleeping mode for main battery replacement.
Page 17 Chapter 1 Use Mobile Computer Select this option to warm boot (restart) the mobile computer. This Warm Boot will close all applications and tasks currently running. All unsaved data will be lost. Select this option if you will not be using the mobile computer in a Power Off while and would like to power it off.
Page 18: Notifications
Config Notification Settings page. To set the good read LED via API deployment, see the (Right) 9700 Programming Guide for details. SPEAKER The mobile computer has a speaker on the back for audio signaling and playback. The speaker sounds for system events, application warnings, on-screen item selection and physical keypad stroke.
Page 19 Same as the speaker and LED light, the vibrator also works for good barcode reading. Enable/disable vibration and set its duration on the Reader Config Notification Settings page. Alternatively, program the vibrator through API deployment to have it vibrate when a successful reading occurs. See the 9700 Programming Guide for details.
Page 20: Battery
Reference Manual 1.4. BATTERY The 9700 mobile computer is fed by two batteries, main battery pack and backup battery. The main battery is removable and replaceable from the battery chamber while the backup battery is mounted on the main board inside the mobile computer.
Page 21: Install/Remove Main Battery
Chapter 1 Use Mobile Computer 1.4.1. INSTALL/REMOVE MAIN BATTERY Follow the steps below to install the main battery: 1) The handstrap is installed over the battery chamber. You do not need to remove the handstrap to install the battery; simply lift up the handstrap to allow enough space to insert the battery.
Page 22: Charge Batteries
9700 Mobile Computer (CE) Reference Manual 1.4.2. CHARGE BATTERIES Due to shipment, it is likely that the main battery and backup battery won’t be fully charged when you receive the package. Before setting the mobile computer to work, charge the main battery to full by direct charging via a power adapter (with the help of a Snap-on Charging &...
Page 23 Chapter 1 Use Mobile Computer DIRECT CHARGING USING SNAP-ON CABLE Direct charging of the mobile computer relies on the Snap-on Charging & Communication Cable (hereinafter “snap-on cable”). There is a power jack on the connector of this cable to connect external power. Prior to charging, install the main battery as described in Install/Remove Main Battery.
Page 24 9700 Mobile Computer (CE) Reference Manual DIRECT CHARGING USING CRADLE Direct cradle charging makes use of a Charging & Communication Cradle (hereinafter “cradle”). The cradle is one of the accessories you can opt for. Prior to charging, install main battery as described in Install/Remove Main Battery.
Page 25: Monitor Battery Level
Chapter 1 Use Mobile Computer 1.4.3. MONITOR BATTERY LEVEL The main battery is the only source that feeds the mobile computer to work. It also supplies the backup battery on main board to retain the data stored in DRAM. Hence when main battery level gets low, recharge it or change it as soon as possible.
Page 26 9700 Mobile Computer (CE) Reference Manual BATTERY STATUS ICONS The OS features a couple of icons that deliver main battery status. These icons can be found on the taskbar, which is settled at the bottom of every screen. Battery charging icon...
Page 27 Chapter 1 Use Mobile Computer LOW BATTERY ALERT When main battery level drops below 40%, the mobile computer prompts “Main Battery Low” for a recharge. When further reduced to under 20%, the mobile computer prompts “Main Battery Very low” to solicit your immediate action. Low battery may incur shutdown to the mobile computer and cause DRAM data damage.
Page 28 9700 Mobile Computer (CE) Reference Manual BACKUP BATTERY LEVEL 1) To check backup battery level, tap Start | Settings | Control Panel | Power On Battery tabbed page of Power Properties window, backup battery level is summarized as “Good”, “Low” or “Very Low” under the Power label.
Page 29: Power Management
Chapter 1 Use Mobile Computer LOW BATTERY ALERT When backup battery level drops to “Very Low”, the mobile computer prompts a “Backup Battery Very Low” warning to alert users that backup battery level is almost drained out. Backup battery is rechargeable by the main battery pack or the power adapter. Low backup battery puts DRAM data in great danger.
Page 30: Keypad
9700 Mobile Computer (CE) Reference Manual 1.5. KEYPAD The mobile computer has a physical keypad and a touchscreen to receive user’s input. Among the two, the touchscreen provides more intuitiveness in interacting with the device. This section shows how to input text using physical keypad and on-screen keyboard. To...
Page 31 Chapter 1 Use Mobile Computer NUMERIC KEYPAD (30-KEY) The numeric keypad possesses 30 keys, including the number keys 0-9, and Esc, Ctrl, Space, Backspace, Enter and period key (.). Also featured are function keys F1 to F4. The power key is seated at the lower right corner of the keypad.
Page 32 By default, these two keys input the functions F14 and F15. You may also SEND/END KEY define their new key functions using CipherLab’s Button Assignment.
Page 33 Chapter 1 Use Mobile Computer MODIFIER KEYS The keypads have five different modifier keys integrated on it. The key trigger and recovery methods differ slightly according to keypad type. Keypad Key Location How to enter How to resume Available on keypad 30-key Press Alpha key once more Available on keypad...
Page 34 9700 Mobile Computer (CE) Reference Manual ALPHA KEY The Alpha key is equipped with an LED indicator. When the Alpha key is pressed, the LED will light up in blue to indicate that Alpha key is activated. When Alpha key is pressed once more, the LED will go off and the keypad will return to default input mode.
Page 35 Chapter 1 Use Mobile Computer 38-key Under Shift mode, press number keys 0-9 to enter Shift+0-9 Under Shift mode, press arrow keys to move the cursor up, down, right or left Under Shift mode, press End/Send key to enter Shift+F14/F15 Under Shift mode, press F1 to F10 to enter Shift+F1 to F10 Under Alpha mode, press Shift key to enter Shift mode, and press arrow keys, number keys 0-9, function keys F1 to F10, period key...
Page 36 9700 Mobile Computer (CE) Reference Manual KEYPAD LOCK All three keypads feature a keypad lock mode, which can be triggered by pressing a hot key combination. When the keypad lock mode is triggered, all keys on the keypad will become locked to prevent any accidental pressing of keys.
Page 37 Chapter 1 Use Mobile Computer INPUT MODE ICONS When the Shift key, Alpha key and Function key are pressed, corresponding icons will appear on the taskbar to indicate the current input mode. When the input mode is changed, a corresponding icon will appear on the taskbar Icon Description...
Page 38 9700 Mobile Computer (CE) Reference Manual letter A-Z, followed by lowercase letters a-z Returns to Alpha mode once a key is pressed. 53-key keypad enters one capitalized letter A-Z, followed by lowercase Press Alpha key once more to return to...
Page 39: On-Screen Keyboard
Chapter 1 Use Mobile Computer 1.5.2. ON-SCREEN KEYBOARD The OS provides users with an on-screen keyboard. The on-screen keyboard supports entering a series of diacritics for European languages by tapping a modifier key. The on-screen keyboard auto-opens in some applications when a text input field is selected. In case the on-screen keyboard doesn’t open automatically, tap the keyboard icon the taskbar and select Keyboard to open it.
Page 40 9700 Mobile Computer (CE) Reference Manual MODIFIER KEYS Although the touchscreen is a resistive single-touch type, use of modifier keys, which normally involves hitting two keys, are still available on the on-screen keyboard. On the on-screen keyboard there are four modifier keys, which are seated at the left edge.
Page 41 Chapter 1 Use Mobile Computer key on on-screen keyboard. key becomes color-inverted Then tap a character key. Letter variant “ü” is entered After the letter variant “ü” is entered, the on-screen keyboard restores to normal English alphanumeric layout. Diacritical letters and letter variants are presented both in lowercase and uppercase.
Page 42 9700 Mobile Computer (CE) Reference Manual Lowercase Uppercase OTHER KEYS Description Tab key Navigates among the highlight items in some applications. For text input, it inserts Tab character, which means it moves caret to the next tab stop. Backspace Erases the characters to the left of caret.
Page 43 Chapter 1 Use Mobile Computer CHANGE KEYBOARD ORIENTATION The mobile computer is built-in with a G-sensor and supports screen orientation, which is enabled by default. So when the mobile computer turns sideways or upright, the screen changes its orientation, and on-screen keyboard also readjusts itself to the new orientation. Upright (Portrait Mode) Sideways (Landscape Mode) To disable automatic screen rotation, see...
Page 44: Edit Text
9700 Mobile Computer (CE) Reference Manual 1.5.3. EDIT TEXT On the mobile computer, cut, copy, and paste text within an application or across applications by the menu commands. Some applications don’t support editing some or all of the text they display while others may offer their own way to edit text.
Page 45: Touch Control
Chapter 1 Use Mobile Computer 1.6. TOUCH CONTROL The mobile computer’s LCD is overlaid by a resistive touch panel and thus forms a resistive touchscreen. Since a resistive touchscreen locates the user’s touch by the force applied on it, by operating with the stylus one can apply minimum force to trigger actions from the touchscreen.
Page 46 9700 Mobile Computer (CE) Reference Manual Screen Rotation window opens with three orientation modes to select from and an option to suspend the mobile computer when the screen is facing down. Three screen orientation modes Allows mobile computer to enter suspension when facing down 2) Tap the modes that you wish to enable.
Page 47: Adjust Backlight
Chapter 1 Use Mobile Computer SIGNATURE MODE The signature mode is for combined usage with the CipherLab application Signature. With this mode enabled, the screen will immediately rotate 180° when the front of the mobile computer is tilted outwards, which is convenient for signing by a second party.
Page 48 9700 Mobile Computer (CE) Reference Manual AUTOMATIC BACKLIGHT PROFILES The mobile computer stores three backlight profiles to represent backlight level under different environments. These can be configured according to user’s likings. To set backlight profiles: 1) Tap Start | Settings | Control Panel | Backlight Setting 2) Uncheck Manual backlight setting to enable profile function.
Page 49: Calibration
Chapter 1 Use Mobile Computer 1.6.4. CALIBRATION A resistive touchscreen needs calibration to work accurately after serving for a period of time. Calibration aligns the coordinates of the touch panel and the LCD underneath to improve touch accuracy. To calibrate the touchscreen: 1) Tap Start | Settings | Control Panel | Stylus 2) Tap Calilbration tabbed page.
Page 50: Memory
9700 Mobile Computer (CE) Reference Manual 1.7. MEMORY The mobile computer packs the following memory units to retain data and instructions from users: Internal Storage: Random-access Memory (RAM) and Flash memory 512 MB SDRAM for temporary storage and fast access of active applications. When the main battery pack is absent, SDRAM is fed by backup battery to retain data.
Page 51 Chapter 1 Use Mobile Computer EXTERNAL STORAGE Tap Start | Settings | Control Panel | Storage Information . The Storage Card label shows the available space on the storage card (if no storage card is installed on the mobile computer, the available size will be displayed as 0).
Page 52: Insert Sd Card
9700 Mobile Computer (CE) Reference Manual 1.7.3. INSERT SD CARD Day-to-day use of the mobile computer might cause the available internal storage to run short. Equip the mobile computer with an external memory unit to expand storage capacity. Follow the steps below to install a SD card: 1) Power off the mobile computer.
Page 53: Direct Data Communication
Syncing Tools and subsequent sections to know how to use ActiveSync. Note: The 9700 mobile computer uses COM9 for serial transmission via RS-232. Figure 10: Direct Data Communication Using Snap-on Cable...
Page 54: Use Cradle
9700 Mobile Computer (CE) Reference Manual 1.8.2. USE CRADLE Direct cradle charging makes use of a Charging & Communication Cradle (hereinafter “cradle”). The cradle is one of the accessories you can opt for. Prior to charging, install main battery as described in Install/Remove Main Battery.
Page 55: Syncing Tools
Chapter 1 Use Mobile Computer 1.8.3. SYNCING TOOLS Microsoft’s syncing tools enables users to update or back up the data on their mobile computers to desktop computers. Two syncing tools are featured by Microsoft - ActiveSync and Windows Mobile Device Center (“WMDC”).
Page 56: St Usb Sync
9700 Mobile Computer (CE) Reference Manual 1.8.5. 1 USB SYNC This section will guide you through USB syncing. To connect ActiveSync using USB: 1) Download the right syncing tool as described in Syncing Tools and install it on your PC.
Page 57: Disconnect Usb Activesync
Chapter 1 Use Mobile Computer A “Temporary Relationship” is established between the mobile computer and the PC Note: If you encounter trouble during USB ActiveSync connection, tap Start | Settings | Control Panel | USB Connection and make sure “ActiveSync Serial Mode” is selected.
Page 58: Activesync Actions To Take
9700 Mobile Computer (CE) Reference Manual 1.8.7. ACTIVESYNC ACTIONS TO TAKE Once “Synchronization Relationship” or “Temporary Relationship” is established between two computers, a variety of actions can be taken to enhance resource sharing between them as previously mentioned in Sync Partnership.
Page 59 Chapter 1 Use Mobile Computer 4) Select the application program(s) to install to the mobile computer, and deselect the application program(s) to uninstall from the mobile computer. 5) Press the OK button. ActiveSync proceeds to install programs and/or remove programs to/from the mobile computer.
Page 60 9700 Mobile Computer (CE) Reference Manual 3) On the PC, from ActiveSync’s menu bar, select Tools | Explore Device, or from its toolbar, press Explore button. The mobile computer’s internal storage root directory “Mobile Device” opens presenting a few folders (and files).
Page 61 Chapter 1 Use Mobile Computer REMOVE ITEMS FROM START MENU To remove an added shortcut from Start menu, simply use ActiveSync’s Explore delete the shortcut from My Device\Windows\Programs folder. You can also remove an added shortcut from Start menu directly on the mobile computer. Add Items to Start Menu for more details.
Page 62 9700 Mobile Computer (CE) Reference Manual BACKUP DATA To best protect your work, back up the data on your mobile computer regularly. You may choose to manually back up using ActiveSync to copy & paste the files to your PC.
Page 63: Volume And Audio
Chapter 1 Use Mobile Computer 1.9. VOLUME AND AUDIO 1.9.1. AUDIO PLAYBACK Use a headset for audio playback and hands-free telephone communication. The headset jack (3.5 mm DIA) is built up on one side of the mobile computer and sealed with a hinged rubber.
Page 64 9700 Mobile Computer (CE) Reference Manual...
Page 65: Data Capture
Chapter 2 DATA CAPTURE Although highly converged, the mobile computer is also a dedicated barcode reader. The mobile computer is shipped with either a (laser) 1D reader or 2D imager. A number of symbologies are supported and data about them can be decoded and collected. After data has been collected, the mobile computer can output it locally to applications installed on the mobile computer or to the host computer so data storage, advanced data analysis and more special services can be performed.
Page 66: Configure Reader
The mobile computer is capable of reading printed barcodes. The reader module can be a either a (laser) 1D reader or a 2D imager. The mobile computer is installed with a CipherLab utility Reader Config to configure the scan engine built inside. Use it to create a profile of settings that best suits your needs.
Page 67: General Settings
Chapter 2 Data Capture 2.1.2. GENERAL SETTINGS General Settings is where all reader settings are accessed from except for symbologies settings. Tap the green arrow next to each item to enter the sub-menu for that given item. Tap to enter each General Settings sub-menu The functions under General Settings include:...
Page 68 9700 Mobile Computer (CE) Reference Manual SCANNER PREFERENCES Scanner Preferences page can be entered by tapping the given item on the Reader Config main settings page. The options provided in this page differ according to the type of scan engine (either 1D or 2D) built within the mobile computer.
Page 69 Chapter 2 Data Capture 1D (LASER) READER SETTINGS Setting Description Default Decode Timeout Sets the maximum time for the decoding process during a 3 sec scan. Configurable between 1 sec to 9 sec. Redundancy Level Sets how many successful readings should be done before Level 1 linear barcodes such as Codabar, MSI, and Interleaved 2 of 5 can be decoded.
Page 70 9700 Mobile Computer (CE) Reference Manual 2D IMAGER SETTINGS Setting Description Default Decode Timeout Sets the maximum time for the decoding process during a 3 sec. scan. Configurable between 1 sec to 9 sec. Redundancy Level Sets how many successful readings should be done before...
Page 71 Chapter 2 Data Capture DATA OUTPUT Data Output allows users to set the way to output decoded data. To open Data Output settings page: 1) Open Reader Config as described in Launch Reader Config. Reader Config main menu opens. 2) Tap the arrow next to Data Output. Data Output settings page opens.
Page 72 9700 Mobile Computer (CE) Reference Manual HOW TO OUTPUT After the output destination is set, configure how to output decoded data, i.e. the “format” to present decoded data. Setting Description Default Auto Enter Adds an ENTER character before or after each scanning act.
Page 73 Chapter 2 Data Capture NOTIFICATION SETTINGS Notification Settings enables audible, visible and tactile feedback for scanning good read, which helps notify the user of a successful decoding. To open Notification Settings page: 1) Open Reader Config as described in Launch Reader Config.
Page 74: Symbology
9700 Mobile Computer (CE) Reference Manual 2.1.3. SYMBOLOGY Symbology section sets the symbologies to read, and also enables/disables some feature(s) for a symbology to read, such as: Customize and transmit start/stop characters Verify/transmit check digits Enable/disable addon digits Convert to another symbology...
Page 75 Chapter 2 Data Capture Symbology settings page opens listing all symbologies which can be decoded. 1D Symbologies 2D Symbologies SYMBOLOGY SETTINGS Tap the arrow next to each symbology checkbox to access detailed settings for that symbology.
Page 76 9700 Mobile Computer (CE) Reference Manual GENERAL PREFERENCES For certain symbologies, common settings are grouped together and displayed in a detailed settings page for that barcode family. To open the general settings page for a set of symbologies, tap the arrow next to General Preference.
Page 77: Miscellaneous
Chapter 2 Data Capture 2.1.4. MISCELLANEOUS This section allows enabling code ID transmission for easy identification of the scanned barcode, and enabling picklist mode to enhance decoding accuracy. Miscellaneous Setting Description Default Transmit AIM Code ID Sets whether to include AIM code ID character in the Deselected decoded data.
Page 78: Reader Config Option Menu
9700 Mobile Computer (CE) Reference Manual 2.1.5. READER CONFIG OPTION MENU Reader Config provides an option menu which is accessible on the menu bar of the main settings page. This menu allows you to import/export all settings in a re-usable format, reset all settings back to factory default, view copyright and version information, and exit the application.
Page 79 Chapter 2 Data Capture RESET TO FACTORY DEFAULTS This function restores all settings in the Reader Config application to default. To enable Factory Reset: 1) Open Reader Config as described in Launch Reader Config. Reader Config main menu opens. 2) Tap Menu button on the menu bar to open the option menu. 3) Tap Reset to Factory defaults.
Page 80 9700 Mobile Computer (CE) Reference Manual IMPORT AND EXPORT Reader Config supports saving the settings and exporting them as an .xml file. Previously exported symbology and scanner settings can be imported again on the mobile computer. This can also be used to implement identical Reader Config settings on two or more devices.
Page 81 Chapter 2 Data Capture To export settings: 1) Open Reader Config as described in Launch Reader Config. Reader Config main menu opens. 2) Tap Menu button on the menu bar to open the option menu. 3) Tap Export. An export page opens allowing you to enter and select information about the profile to be saved.
Page 82 9700 Mobile Computer (CE) Reference Manual ABOUT Tap About in the Reader Config option menu to display software version and copyright information. Information about the software...
Page 83: Read Printed Barcodes
Chapter 2 Data Capture 2.2. READ PRINTED BARCODES Aside from output to destinations as per Keyboard Emulation settings, Reader Config provides a Scan Test feature for quick viewing of decoded data. To perform test scanning of barcodes: 1) Open Reader Config as described in Launch Reader Config.
Page 84 9700 Mobile Computer (CE) Reference Manual The decoded data will appear on the page. When finished viewing, tap on the title bar to leave the test scan page. Tap to exit the test scan page To display more information such as barcode type and length, configure the reader as in Data Output.
Page 85: Operating System
Chapter 3 OPERATING SYSTEM The mobile computer is powered by Windows Embedded Compact 6.0, a member of Windows Embedded family. Windows Embedded Compact 6.0 bears much similarity to desktop OS, and users rely only on a few basic gestures such as tap, double-tap and drag to navigate within the OS.
Page 86: Desktop
Chapter 3 Operating System 3.1. DESKTOP Desktop is where all features on the mobile computer are accessed from. Basic operations on the desktop: Tap the Start button to open the Start menu. Double-tap an application icon on the desktop to open it. Tap a blank spot on the desktop to open an option menu for customizing the wallpaper and the items to display.
Page 87: Taskbar
Chapter 3 Operating System 3.1.1. TASKBAR At the bottom of the screen is the taskbar, which is divided into the following sections: Start button: opens Start menu Task button section that shows a button of the current application open on-screen Notification area which displays icons for connection status of the mobile computer, as well as system time A keyboard icon for switching input mode...
Page 88: Start Menu
9700 Mobile Computer (CE) Reference Manual A specific wireless connection has been established successfully. Double-tap the icon to open a dialog to check IP information. Included connections are: Bluetooth PAN 802.11a/b/g/n Indicates the Wi-Fi module is enabled. The more the green bars, the stronger the signal.
Page 89: Customize Desktop And Start Menu
Chapter 3 Operating System 3.1.3. CUSTOMIZE DESKTOP AND START MENU Customize the desktop by changing the background, application shortcuts, and so on. Rearrange the application shortcuts to make the applications that you use most often easy to access. CHANGE BACKGROUND You may change the background of the desktop to a picture of your own choice.
Page 90 9700 Mobile Computer (CE) Reference Manual The selected file will appear on the desktop as the background image. CHANGE APPEARANCE You may change the overall scheme, color of title bars, dialog boxes, menu text, selected items and so on to suit your preferences.
Page 91 Chapter 3 Operating System ADD ITEMS TO DESKTOP ADD APPLICATION SHORTCUTS 1) On the mobile computer, tap My Device on the desktop. 2) Browse to the executable file of the program you would like to create a shortcut for. 3) Tap and hold the file. A pop-up menu will show on the screen. 4) Tap Copy in the pop-up menu.
Page 92 9700 Mobile Computer (CE) Reference Manual A shortcut to the program is added to the Start Menu. REMOVE ITEMS FROM START MENU 1) On the mobile computer, tap My Device on the desktop. 2) Browse to My Device\Windows\Programs. Programs folder opens. All applications available in the Start menu can be found here.
Page 93: Managing Programs
Chapter 3 Operating System 3.2. MANAGING PROGRAMS 3.2.1. LAUNCH PROGRAM 1) Tap Start | Programs to display a menu listing all the programs installed on the mobile computer. Note: Use this menu to launch any programs newly installed on the mobile computer. Alternatively, you may add a shortcut of the program on the desktop.
Page 94: Switch Between Active Tasks
9700 Mobile Computer (CE) Reference Manual Program for connection to a remote computer. SUMMIT CLIENT UTILITY Utility which controls Wi-Fi connection, adjusts settings and performs diagnostic tests. TRANSCRIBER Application for handwriting recognition. WINDOWS EXPLORER Browser for the mobile computer’s internal storage.
Page 95: Install Applications
Chapter 3 Operating System 3.2.4. INSTALL APPLICATIONS As mentioned in Add/Remove Programs, you can download and install an application on your PC first and offload it to the mobile computer later using Microsoft ActiveSync. Alternatively, the OS allows you to install an application right from the mobile computer. Follow the steps below to complete installation: 1) Using your PC, copy the installation file (.CAB) to the mobile computer’s internal storage via ActiveSync.
Page 96 9700 Mobile Computer (CE) Reference Manual 4) When installation is finished, launch it by tapping Start | Programs and locating it in the Programs menu. Alternatively, you may download an application to install from the Internet. See Use Wi-Fi for how to connect the mobile computer to the Internet.
Page 97 Chapter 3 Operating System UNINSTALL APPLICATIONS On the mobile computer, the acquired (non-inherent) applications can be depleted from the OS through manual removal (uninstallation). To uninstall an application: 1) Tap Start | Settings | Control Panel | Remove Programs Remove Programs opens showing the applications downloaded and installed from external sources.
Page 98: Suspend & Reset Mobile Computer
9700 Mobile Computer (CE) Reference Manual 3.3. SUSPEND & RESET MOBILE COMPUTER To save from repeatedly charging and replacing batteries, suspend the mobile computer when you are not actively using it. Suspending (or “turning off”) the mobile computer holds the device from running without cutting off power. It is a “soft-off” state which enables less power consumption, and also a state which the device can quickly awake from since there is no need to restart the OS and applications.
Page 99: Wake Up Mobile Computer
Chapter 3 Operating System 3.3.2. WAKE UP MOBILE COMPUTER “Waking up” refers to restoring the suspended device to its previous working state. The mobile computer can be awoken both manually and automatically. MANUAL AWAKENING Press (without holding) the power button or central scan key to wake up the mobile computer.
Page 100: Restart Mobile Comptuer (Warm Boot)
9700 Mobile Computer (CE) Reference Manual 3.3.3. RESTART MOBILE COMPTUER (WARM BOOT) When the system becomes erroneous and applications fail to respond properly, proceed to restart the mobile computer. After the mobile computer is restarted, DRAM will be initialized, and all data cached in DRAM and any unsaved tasks will be erased. However all user data, system settings and clock/calendar time will be preserved.
Page 101: Radios
Chapter 4 RADIOS The mobile computer is a versatile networker. It integrates Wi-Fi and Bluetooth for wireless data. With the help of these radios, the mobile computer keeps users online all the time. In this chapter, you will learn how these radios can work for you. 4.
Page 102: Use Wi-Fi
9700 Mobile Computer (CE) Reference Manual 4.1. USE WI-FI The mobile computer is capable of Wi-Fi, a wireless networking technology making use of an access point, also known as “hotspot”, to connect to a wireless local area network. To use Wi-Fi, the mobile computer has to connect to a hotspot. Some hotspots are open for connection while others request a key to authenticate access.
Page 103 Chapter 4 Radios Note: Wi-Fi power settings under Wireless Manager will be kept through suspension and warm boot/cold boot. After the mobile computer resumes from suspension or restarts, Wi-Fi power status will be maintained and the mobile computer will attempt to reconnect the previous connection.
Page 104: Launch Scu
9700 Mobile Computer (CE) Reference Manual 4.1.2. LAUNCH SCU Wi-Fi settings can be adjusted with Summit Client Utility. Within this application are three tabbed pages which allow users to select the access point for connection, create profiles for better management, perform diagnostics on connectivity, and fine-tune property settings to meet their individual requirements.
Page 105: Status Tabbed Page
Chapter 4 Radios 4.1.3. STATUS TABBED PAGE The Status tabbed page provides basic information on WLAN connection and Bluetooth status. Wi-Fi settings can be configured on Configuration Tabbed Page. Wi-Fi status Bluetooth status (service coming soon) Note: SCU does not currently support viewing or configuring Bluetooth settings.
Page 106: Configuration Tabbed Page
9700 Mobile Computer (CE) Reference Manual 4.1.4. CONFIGURATION TABBED PAGE TURN ON/OFF WI-FI MODULE Select the Wi-Fi checkbox to turn on Wi-Fi. Deselect it to shut down Wi-Fi. Turn on Wi-Fi module Note: SCU does not allow configuration of Bluetooth settings. To establish and manage...
Page 107 Chapter 4 Radios ACTIVE PROFILE A profile is a set of parameters that define the manner which a device associates to a wireless LAN (WLAN) infrastructure. A profile contains information including the System Set Identifier (SSID, the "name" of the WLAN infrastructure), means of data encryption, authentication type, and security credentials.
Page 108 9700 Mobile Computer (CE) Reference Manual CREATE WI-FI PROFILE To create a Wi-Fi Profile: 1) Open SCU as described in Launch SCU. 2) Tap the Configuration tab to show the Configuration tabbed page. 3) Tap Scan to view a list of access points that are broadcasting their SSIDs. You may sort the list by tapping the column headers.
Page 109 Chapter 4 Radios 5) A profile settings page opens showing detailed radio settings. Tap each item and adjust its Value to suit your needs. 6) When finished fine-tuning all settings, tap Commit to save the profile. 7) Tap OK on the title bar to close the Profile Settings page and return to Configuration settings.
Page 110 9700 Mobile Computer (CE) Reference Manual MANAGE WI-FI PROFILE To manage your profiles: 1) Open SCU’s Configuration tabbed page as described in Create Wi-Fi Profile. 2) Tap Manage Profiles to open the Profile settings page. Item Description Profile When SCU is first launched, “Default” is the active profile. Unless it is modified, this profile does not specify an SSID, EAP type or encryption method.
Page 111 Chapter 4 Radios Tap New and enter a unique name for the profile. Configure the Radio settings, Encryption, EAP Type, and other settings for this new profile. The name for each profile must be unique You can define up to 20 profiles Delete Select a profile from the drop-down menu and tap Delete.
Page 112 9700 Mobile Computer (CE) Reference Manual Radio After selecting a profile in the Profile drop-down bar, configure radio settings in the Settings scrollable menu below. Property Description Profile Name Tap to rename the selected profile. Up to 32 characters allowed.
Page 113 Chapter 4 Radios Maximum In Max Power Savings (Max PSP) mode, the access point buffers incoming messages for the radio, which wakes up periodically and connects to the access point to see if any buffered messages are waiting. The radio requests buffered messages and then goes back to sleep.
Page 114 9700 Mobile Computer (CE) Reference Manual Ad Hoc When selected, Summit radio associates to another station radio that is in ad hoc mode and has the same SSID and, if configured, static WEP key. Default: ABG rates full Auth Type 802.11 authentication type used when associating to an AP.
Page 115 Chapter 4 Radios Password (up to 32 characters) PAC Filename (up to 32 characters): You may create a protected access credential (PAC) for each client device. When creating a PAC manually, you must store it in the directory identified in Certs Path on the Globals settings page.
Page 116 9700 Mobile Computer (CE) Reference Manual Commit After making any changes on the Profile tabbed page, the Commit button must be tapped in order for the settings to take effect.
Page 117 Chapter 4 Radios MANAGE GLOBAL SETTINGS Global settings include radio and security settings that apply to all profiles in SCU. To open the Global settings page: 1) Open SCU’s Configuration tabbed page as described in Create Wi-Fi Profile. 2) Tap Manage Profiles to open the Profile settings page. 3) Tap the Globals tab to open the Global settings page.
Page 118 9700 Mobile Computer (CE) Reference Manual 1, 7, 13 For ETSI and TELEC radios only Custom Indicates the system registry has been edited to include a value other than those available in the drop-down value Default: Full DFS Channels Indicates whether to support 5 GHz (802.11a) channels where dynamic frequency selection (DFS) is required.
Page 119 Chapter 4 Radios Auth Server Type of authentication server being used for EAP authentication. Value: Type 1 Cisco Secure ACS or another server that uses PEAPv1 PEAP with EAP-MSCHAPV2 (PEAP-MSCHAP) Type 2 A different authentication server, such as Juniper Networks Steel Belted RADIUS, that uses PEAPv0 for PEAP-MSCHAP Default: Type 1 TTLS Inner Method...
Page 120 9700 Mobile Computer (CE) Reference Manual Admin Password Auth Timeout (s) Specifies how long it will wait for an EAP authentication request to succeed or fail. If authentication credentials are specified in the active profile and the authentication times out, then association will fail. If authentication credentials are not specified in the active profile and the authentication times out, then the user will be required to enter credentials again.
Page 121: Diagnostics Tabbed Page
Chapter 4 Radios 4.1.5. DIAGNOSTICS TABBED PAGE Perform diagnostic tests to troubleshoot connection issues when necessary. To open the Diagnostics page: 1) Open SCU as described in Launch SCU. 2) Tap the Diagnostics tab to show the Diagnostics page. Diagnostics status for Wi-Fi and Bluetooth shows, along with on-screen buttons to open Advanced settings and view software version information.
Page 122 9700 Mobile Computer (CE) Reference Manual ADVANCED DIAGNOSTICS To access Advanced diagnostics settings: 1) Open Diagnostics Tabbed Page. 2) Tap the Advanced button to open advanced diagnostics settings. CHECK STATUS To check diagnostics status, select Status in the drop-down bar.
Page 123 Chapter 4 Radios USE PING TOOLS To perform ping tests, select Ping Tools in the drop-down bar. Select Ping Tools to diagnose the connection Device IP address AP Name Item Description Destination Enter the address to ping. Ping Payload The amount of data to be transmitted on a ping. Value: 32, 64, 128, 256, 512, 1024 Default: 32 (bytes) Ping Delay...
Page 124 9700 Mobile Computer (CE) Reference Manual When an active ping is initiated, the screen displays a ping indicator that blinks in green (for a successful ping) or red (for an unsuccessful ping). The ping indicator is hidden when the screen is switched to a tab other than Diags or Status.
Page 125 Chapter 4 Radios Reconnect Disable and enable the radio, apply or re-apply the current profile, attempt to associate and authenticate to the wireless network, and log all activity in the output area at the bottom.
Page 126 9700 Mobile Computer (CE) Reference Manual USE DEBUG TOOLS To check debug settings, select Debug in the drop-down bar. Select Debug to check debug settings Item Description Driver Debug Select whether to debug the WLAN driver, and the output mode for driver debug.
Page 127 Chapter 4 Radios SOFTWARE VERSION INFORMATION To check software version information: 1) Open Diagnostics Tabbed Page. 2) Tap the About button to view information about SCU version, device driver, and software developer.
Page 128: Use Bluetooth
9700 Mobile Computer (CE) Reference Manual 4.2. USE BLUETOOTH The mobile computer is Bluetooth-enabled to synchronize data with other devices such as PCs, car hands-free kits, headsets, printers, PDAs, and cell phones. Class II Bluetooth devices enable wireless connections over a short distance of around 10 meters.
Page 129 Chapter 4 Radios Device ID tabbed page opens. Change device name to make the mobile computer more recognizable. 3) Enter a name of your choice. 4) Tap OK on the title bar to apply the change.
Page 130: Turn On/Off Bluetooth
9700 Mobile Computer (CE) Reference Manual 4.2.3. TURN ON/OFF BLUETOOTH To turn on/off Bluetooth power: 1) Tap Start | Settings | Control Panel | Wireless Manager Wireless Manager opens. 2) Make sure the Bluetooth label is turned “on” If the Bluetooth label is turned “off”, tap the “Off” icon to switch on Bluetooth power.
Page 131: Set Bluetooth Visibility
Chapter 4 Radios 4.2.4. SET BLUETOOTH VISIBILITY By opening or closing Bluetooth visibility, you can control whether or not other Bluetooth devices can discover the mobile computer. To set Bluetooth visibility on the mobile computer: 1) Tap the Bluetooth icon on the taskbar and select Setting in the pop-up menu.
Page 132: Launch Bt Connect
9700 Mobile Computer (CE) Reference Manual 4.2.5. LAUNCH BT CONNECT BT Connect is a connection tool for establishing Bluetooth partnerships. To launch BT Connect: 1) Tap the Bluetooth icon on the taskbar and select Maximized in the pop-up menu. BT Connect launches with a menu bar on top and a blank field for searching devices.
Page 133: Search For Bluetooth Devices
Chapter 4 Radios 4.2.6. SEARCH FOR BLUETOOTH DEVICES To search for a Bluetooth device to connect to: 1) Tap Device to discover Bluetooth devices nearby. Wait for a few seconds for the mobile computer to list all the discovered devices. 2) If the device that you wish to connect to is not listed, make sure its Bluetooth status is set as discoverable.
Page 134: Pair Bluetooth Devices
9700 Mobile Computer (CE) Reference Manual 4.2.7. PAIR BLUETOOTH DEVICES IDENTIFY BLUETOOTH DEVICE To check the identity of a Bluetooth device: 1) Open BT-Connect page as described in Launch BT Connect. 2) In the device list, tap and hold a device until a pop-up menu appears.
Page 135 Chapter 4 Radios PAIR If authentication is enabled on the Bluetooth device, pairing will be required to connect to that device. Pairing can be done by using a pin code to ensure secure Bluetooth connection. 1) In the device list, tap and hold the device to pair with. Select Pair in the pop-up menu. 2) Enter a pin code in the pop-up window that appears.
Page 136 9700 Mobile Computer (CE) Reference Manual Once the mobile computer and the remote Bluetooth device are paired, a lock icon will be displayed next to the device. 4) Double-tap the device to find out which Bluetooth services are available. 5) Tap and hold a desired Bluetooth service to take further actions.
Page 137 Chapter 4 Radios UNPAIR To unpair a Bluetooth device: 1) In the device list, tap and hold the device to unpair. A pop-up menu will appear. 2) Select Unpair in the pop-up menu.
Page 138: Bluetooth Data Transfer
9700 Mobile Computer (CE) Reference Manual 4.2.8. BLUETOOTH DATA TRANSFER After the mobile computer is paired to a remote Bluetooth Device, it is ready to begin Bluetooth data communication. FILE TRANSFER To exchange files via file transfer (FTP) service: 1) On the Device page, double-tap the paired Bluetooth device.
Page 139 Chapter 4 Radios 4) Select an object to transfer to the paired Bluetooth device. On the remote Bluetooth device, the object will be stored under the directory specified on Service page | FTP Transfer | Change Local Path. 5) To store a transferred file to the specified local path on the mobile computer, tap and hold a file and select Get File in the pop-up menu.
Page 140 9700 Mobile Computer (CE) Reference Manual OBJECT PUSH To use object push (OPP) service to send an object to a remote Bluetooth device: 1) On the Device page, double-tap the paired Bluetooth device to open a page showing its available services.
Page 141 Chapter 4 Radios 3) Select an object to transfer to the paired Bluetooth device. Wait for a few moments while the file transfers to the remote Bluetooth device. 4) On the remote Bluetooth device, the object will be stored under the directory specified on Service page | Object Push | Change Local Path.
Page 142 9700 Mobile Computer (CE) Reference Manual PAN SERVICE To use personal area network (PAN) service shared by the Bluetooth device to connect to the Internet: 1) On the Device page, double-tap the paired Bluetooth device to open a page showing its available services.
Page 143 Chapter 4 Radios SERIAL PORT SERVICE To use Serial Port Service: 1) On the Service page, check if the Bluetooth virtual COM port is occupied by the local SPP service (i.e. whether a green connection icon is present). If so, tap and hold the service and select Unload in the pop-up menu.
Page 144 9700 Mobile Computer (CE) Reference Manual 2) On the Device tab, double-tap the paired device to open a page showing the available services for that device. 3) Tap and hold Serial Port Service and select Connect in the pop-up menu.
Page 145 Chapter 4 Radios 4) By default, the mobile computer uses COM6 as the Bluetooth SPP COM port. Tap OK in the pop-up window to confirm. 5) A connection icon appears to indicate that serial port service is now active.
Page 146 9700 Mobile Computer (CE) Reference Manual BLUETOOTH ACTIVESYNC To create ActiveSync connection between your PC and mobile computer via Bluetooth, first you will need to configure Bluetooth settings on your PC. 1) On your PC, configure necessary Bluetooth settings, such as turn Bluetooth discovery on, allow other Bluetooth devices to connect to the PC, and add a COM port for incoming connection.
Page 147 Chapter 4 Radios 3) On the mobile computer, make sure Serial Port Service is enabled in BT Manager. 4) On the Device page, double-tap your PC to view its available services. 5) Tap and hold Serial Port Services and select ActiveSync via BT in the pop-up menu. The mobile computer then connects to your PC via ActiveSync.
Page 148: Re-Connection
9700 Mobile Computer (CE) Reference Manual 4.2.9. RE-CONNECTION By default, BT-Connect will automatically re-connect to the previous services the next time the mobile computer goes through a Bluetooth power cycle. The preferred devices and services will also be reflected on the Preference tabbed page of Manager.
Page 149: Preferred Services
Chapter 4 Radios 4.2.10. PREFERRED SERVICES On the Device tabbed page in BT-Connect, double-tap the preferred device to view its available Bluetooth service(s). Example Service Status Settings in BT-Manager The service is re-connected ( ). Last Connection = Y (on the Preference Tab) The service is available for re-connection.
Page 150: Manage Local Services
9700 Mobile Computer (CE) Reference Manual 4.2.11. MANAGE LOCAL SERVICES LOAD/UNLOAD SERVICE You may select to load or unload a certain service. When a service is unloaded, it will become unavailable to paired Bluetooth devices. When it is re-loaded, it will become available once more.
Page 151 Chapter 4 Radios CHANGE LOCAL PATH For File Transfer and Object Push services, you may change the path for file exchange. 1) On the Service page, tap and hold an item to open a pop-up menu. Select Change Local Path in the pop-up menu and enter an inbox storage path. 2) Tap OK to confirm the change.
Page 152: Bt Manager
9700 Mobile Computer (CE) Reference Manual 4.2.12. BT MANAGER Advanced Bluetooth settings regarding Bluetooth reconnection, Bluetooth inquiry time and more can be adjusted using BT Manager. 1) Tap Start | Settings | Control Panel | BT Manager Tap the Bluetooth icon on the Wireless Manager settings page.
Page 153 Chapter 4 Radios GENERAL TAB This page sets whether to allow reconnection of Bluetooth services and auto-inquiry of Bluetooth devices. Tap to restore default settings Tap to save changes Setting Description Allow to resume last service Select to automatically re-connect to all previous Bluetooth services after the mobile computer resumes from warm boot/cold boot, or goes through a Bluetooth power cycle.
Page 154 9700 Mobile Computer (CE) Reference Manual PREFERENCE TAB BT Manager helps sort out preference for all remote services which were previously connected/disconnected. Select a desired service type from the drop-down menu: Headset/Handsfree Others (FTP, OPP, and DUN) MANAGING BLUETOOTH SERVICES...
Page 155 Chapter 4 Radios CONFIGURING CONNECTION SETTINGS Change the connection preference for a specific service by enabling (selecting Y) or disabling (selecting N) the last two columns, Last Connection and Auto Inquiry. If you select Y for Last Connection or Auto Inquiry, “Allow to resume last service” and “Auto Inquiry”...
Page 156 9700 Mobile Computer (CE) Reference Manual SAVING PREFERENCE CHANGES After making changes to preference settings, tap Apply. A warning dialog will show reminding that for the settings to take effect, you will need to restart Bluetooth power. Proceed to perform a Bluetooth power cycle as in Turn On/Off Bluetooth.
Page 157 Chapter 4 Radios ABOUT TAB This page delivers version and copyright information about the software.
Page 158 9700 Mobile Computer (CE) Reference Manual...
Page 159: More Applications
Chapter 5 MORE APPLICATIONS Aside from the dedicated Reader Configuration which empowers the mobile computer’s with a specialty in data capture as mentioned in Data Capture, more manufacturer-developed applications are preinstalled to strengthen user’s system management and make the mobile computer more eligible. These applications include: Applications Description...
Page 160: Button Assignment
9700 Mobile Computer (CE) Reference Manual 5.1. BUTTON ASSIGNMENT Button Assignment can re-define the functions of physical keys so that they trigger different actions. Settings made to one or more keys can be saved as a profile, allowing users to switch conveniently in between different sets of settings.
Page 161: Redefine Keys
Chapter 5 More Applications 5.1.2. REDEFINE KEYS To assign a new function for a re-definable key: 1) Launch Button Assignment as described in Launch Button Assignment. 2) Scroll to the button you would like to re-define, and tap twice on the icon or text. Settings page for that button will open showing four options to set button function.
Page 162 9700 Mobile Computer (CE) Reference Manual DISABLE/ENABLE KEY FUNCTION The last column in the Device Setting list gives an overview of key status. Users can disable or enable a key by giving a single tap on this column. By disabling keys, keys are “locked”...
Page 163: Main Menu
Chapter 5 More Applications 5.1.3. MAIN MENU When the main menu button is tapped, an option menu opens providing the following functions: Item Description User Profile Displays the existing profiles (not including default settings), and a toolbar to manage profiles: Toolbar icon Description Applies the selected profile.
Page 164 9700 Mobile Computer (CE) Reference Manual MANAGE PROFILES CREATE PROFILE To create a new profile: 1) Load factory default settings, or read current settings from device first. 2) Modify the settings directly according to your needs, then tap to open a page where you can enter a name for the new profile.
Page 165 Chapter 5 More Applications Browse to the profile and tap to have it imported Select the profile you wish to export, then tap to enter export settings. Specify the location and file type for the profile to export Enter a name for the profile to export Note: The All Folders directory refers to all folders under My Device\My Documents.
Page 166 9700 Mobile Computer (CE) Reference Manual READ/WRITE SETTINGS Use Read from device and Write to device to read the current settings on the device, or write the newly changed settings to the device in order for them to take effect. See...
Page 167: Keypad Modes
Chapter 5 More Applications 5.1.4. KEYPAD MODES The 30-key numeric keypad and 38-key numeric & function keypad provide two different modes for Button Assignment, normal mode and function mode. To enable function mode, simply press the Function Key. On the 53-key alphanumeric keypad, only normal mode is available. 30-KEY KEYPAD Special Options Button...
Page 168 9700 Mobile Computer (CE) Reference Manual F1-24 [3] Number User Define [4] Number [5] Number Increase Backlight Brightness [6] Number Volume Up [7] Number [8] Number Decrease Backlight Brightness [9] Number Volume Down [0] Number...
Page 169 Chapter 5 More Applications 38-KEY KEYPAD Special Options Button Normal mode Function mode Key Options (Normal mode) Answer Call / Send End (Call) Start Home Scan Push to Talk Left Left Scan Push to Talk Right Right Scan Push to Talk Down Page Up Left...
Page 170 9700 Mobile Computer (CE) Reference Manual Increase Backlight Brightness Volume Up Decrease Backlight Brightness Volume Down...
Page 171 Chapter 5 More Applications 53-KEY KEYPAD Button Normal mode Key Options Special Options Answer Call / Send End (Call) Start Home Scan Push to Talk Left Left Scan Push to Talk Right Right Scan Push to Talk Down Page Up Left Page Down Volume Down...
Page 172 9700 Mobile Computer (CE) Reference Manual Keys 1, 2, 3.….9, Note: The scan key and side trigger keys (left/right scan key) can be assigned as the Push to Talk trigger key under normal mode.
Page 173: Signature Utility
Chapter 5 More Applications 5.2. SIGNATURE UTILITY Signature utility captures, views and edits signature files. 5.2.1. INSTALL SIGNATURE UTILITY INSTALL WITH .CAB FILE 1) Insert the product CD into your CD-ROM. 2) Connect the mobile computer to your PC via ActiceSync. 3) Obtain the Signature utility installation file (.CAB) and copy it to the mobile computer.
Page 174 9700 Mobile Computer (CE) Reference Manual INSTALL WITH .EXE FILE 1) Insert the product CD into your CD-ROM. 2) Connect the mobile computer to your PC via ActiceSync. 3) On your PC, double-click the Signature utility executable file (.EXE) to begin the...
Page 175 Chapter 5 More Applications 4) On the mobile computer, Signature utility will start to install. When completed, it will be listed under Start menu | Programs...
Page 176: Launch Signature Utility
9700 Mobile Computer (CE) Reference Manual 5.2.2. LAUNCH SIGNATURE UTILITY To launch Signature utility: 1) Tap Start | Programs | Signature Signature utility opens showing a toolbar along the top and a signing area within its window. Toolbar Signing area TOOLBAR &...
Page 177: Capture Signature
Chapter 5 More Applications 5.2.3. CAPTURE SIGNATURE To capture a signature: 1) Launch Signature utility as described in Launch Signature Utility. Signature utility launches. 2) Use the stylus to sign a name in the signing area. Put your name in the signing area 3) Tap icon to save the signature as an image in BMP, JPG or Locus format.
Page 178: View Or Edit Existing Signatures
9700 Mobile Computer (CE) Reference Manual 5.2.4. VIEW OR EDIT EXISTING SIGNATURES To view the existing signature(s) on the storage of the mobile computer: 1) Launch Signature utility as described in Launch Signature Utility. Signature utility launches. 2) Tap icon on toolbar.
Page 179: Preferences
Chapter 5 More Applications 5.2.5. PREFERENCES The utility supports preferences settings which change the utility’s behaviors when it is used. Users are able to change the size and color of the signing pen stroke, and customize the background color of the signing area. To access the utility’s preferences settings: 1) Launch Signature utility as described in Launch Signature...
Page 180: Backup Utility
Reference Manual 5.3. BACKUP UTILITY CipherLab’s Backup Utility performs backup and restoration, a process of copying files and putting them back to system. They are very important for a computer or database once it is rendered unusable by any software or hardware error.
Page 181: Registry Backup And Restoration
Chapter 5 More Applications 5.3.2. REGISTRY BACKUP AND RESTORATION The registry is a database of the information about system configuration and application settings that form the basis of operating system. You may back up and restore the system registry to keep the mobile computer at a stable condition. REGISTRY BACKUP You may use registry backup to reserve the system configuration and application settings at a checkpoint when the condition is stable, which can come to rescue when the system...
Page 182 9700 Mobile Computer (CE) Reference Manual Registry backup is completed within a few seconds. Tap to close the window. Warning: Whenever changes are made to the system configurations and settings, remember to perform registry backup again to update the system registry.
Page 183 Chapter 5 More Applications 3) Tap to proceed, or tap to cancel. The mobile computer proceeds to restore the registry. When completed, a dialog pops up confirming that system reboot (warm boot) must be performed for the changes to take effect. 4) Tap to reboot the mobile computer.
Page 184: Device Data Backup And Restoration
9700 Mobile Computer (CE) Reference Manual 5.3.3. DEVICE DATA BACKUP AND RESTORATION DEVICE DATA BACKUP The Backup tabbed page can be applied for backup of system files and user data. To back up system file(s): 1) Launch Backup Utility as described in Launch Backup Utility.
Page 185 Chapter 5 More Applications 4) The file system is revealed as a tree-like structure in hierarchical order. Each plus sign (+) is a node to expand an item or sub-item. Each item comes with a check box for selection. Select the items you would like to back up. File system is revealed If the items “Machine Registry”...
Page 186 9700 Mobile Computer (CE) Reference Manual 6) Tap Start to proceed. Backup utility proceeds to generate a backup file for system data. Results are displayed on the screen. Click to view a Closes the backup process report of the backup 7) Tap OK to finish and quit backup, or tap Report to view the details of the generation.
Page 187 Chapter 5 More Applications DEVICE DATA RESTORATION You may restore system files and user data as long as any backup file is found in the storage, whether internal or external. To restore device data: 1) Launch Backup Utility as described in Launch Backup Utility.
Page 188 9700 Mobile Computer (CE) Reference Manual Estimation of required storage Starts restoration by Quits restoration putting the selected backup file back to system 4) Tap the bottom-left Start button. Restoration begins, and the selected backup file is placed back to the system.
Page 189: Push To Talk
Chapter 5 More Applications 5.4. PUSH TO TALK CipherLab Push to Talk is a walkie-talkie service that allows users of an active talk group to communicate with all other members of the group instantaneously with a simple push of a button.
Page 190: Communicate With Group Members
9700 Mobile Computer (CE) Reference Manual 5.4.2. COMMUNICATE WITH GROUP MEMBERS Push to Talk functions through group communication, meaning that when an audio transmission is initiated on one device, all other devices in that group will receive the audio message. Groups are established by Wi-Fi connection under a specific subnetwork (subnet).
Page 191 Chapter 5 More Applications “Transmitting” status indicates the device is in transmit mode When tapped and held, PUSH button turns red When finished transmitting the audio message, let go of the PUSH button. The button will return to gray and the mobile computer will switch back to voice reception mode.
Page 192 9700 Mobile Computer (CE) Reference Manual RECEIVING AUDIO CONTENT To receive audio content from group members: 1) Have all devices you would like to communicate with connect to a specific (or several specific) access point(s) as described in . Make sure these access points belong Use Wi-Fi to the same subnet.
Page 193 Chapter 5 More Applications MANAGING MEMBER LIST The Member List will show all other devices (not including the device under operation) that have connected to the wireless subnet and are currently running the Push to Talk application. OPEN MEMBER LIST 1) Launch Push to Talk as described in Launch Push to Talk.
Page 194 9700 Mobile Computer (CE) Reference Manual VOICE RECEPTION MODE When Push to Talk is opened, devices will be in voice reception mode and are ready to receive audio content. The status bar before the device name appears in green. Green indicates a device is in voice...
Page 195 Chapter 5 More Applications DEVICE DISCONNECTED When one or more of the devices in the group is disconnected, the status bar before the device name will change to gray. The Member List label will be updated to reflect the remaining number of connected devices. When this occurs, check the Wi-Fi connection status on that specific device, make sure the mobile computer is powered on and not in suspension, and the Push to Talk application is currently running.
Page 196 9700 Mobile Computer (CE) Reference Manual...
Page 197: Manage Mobile Computer
Chapter 6 MANAGE MOBILE COMPUTER This chapter guides you to the system settings featured by the OS. Access these settings to define how the mobile computer looks, sounds, stores/secures your data, manages the applications, or exchanges data with your networks or other devices. This chapter also includes the process for updating the OS image.
Page 198: Update Os Image
OS image upgrade helps optimize the mobile computer’s performance and functionality. The upgrade relies on CipherLab’s OS Update Tool, a utility to run on your PC to get the job done. This utility brings the upgrades of OS image and splash (booting logo) to the mobile computer.
Page 199: Control Panel
Chapter 6 Manage Mobile Computer 6.2. CONTROL PANEL To access control panel settings: Tap Start | Settings | Control Panel to display a window listing all the programs installed on the mobile computer. Icon Description BACKLIGHT SETTING Sets screen and keypad timeout and brightness. Four tabs are featured – Brightness, Battery Power, External Power, and Profile.
Page 200 9700 Mobile Computer (CE) Reference Manual pressed External Power Sets the screen backlight timeout on external power and whether to trigger screen/keypad light up upon pressing a key. Option Default Settings Turn off LCD backlight if device is not used Checked;...
Page 201 Chapter 6 Manage Mobile Computer warn that one of these ports must be changed. DATE/TIME Sets RTC time, calendar and time zone. Note: RTC time can be reserved for approximately 60 days on the mobile computer after the main battery pack has been removed. DIALING Dials up the connection and configure settings for modem communication.
Page 202 9700 Mobile Computer (CE) Reference Manual Tabbed Page Description PC Connection Select to connect the mobile computer with your PC through USB serial connection or. Changing connections settings may affect communications with your PC. COM Port Select whether to allow the physical UART to act as a COM port, and specify the COM port to map to.
Page 203 Chapter 6 Manage Mobile Computer among three tabs: Tabbed Page Description Status Displays AP information, device IP, connection status and signal strength. Configuration Disables/Enables radio and switches the active profile. Also opens profile settings and global settings. Diagnostics Performs diagnostic tests to check connection, and shows information about SCU version.
Page 204 9700 Mobile Computer (CE) Reference Manual Digit Pair Hardware Code Barcode 0: None: Reader 1: Laser 2: Laser 3: 2D imager 4: Long range laser 5: 2D imager 7: Extra long range 2D imager 9: Extra long range laser Bluetooth...
Page 205 Chapter 6 Manage Mobile Computer TIME SYNC SNTP tabbed page: Synchronizes the mobile computer’s time with an NTP server either automatically or manually. Users can also select the time period for auto-sychronization. Synchronized time will be written to RTC and system time will be updated.
Page 206 9700 Mobile Computer (CE) Reference Manual VOLUME & SOUNDS Volume tab: Adjusts system sounds and volume for events, applications, notifications and stylus movements. Sounds tab: Changes event sounds to meet your preferences and save them as schemes. WIRELESS MANAGER Enables/disables Bluetooth and Wi-Fi power status.
Page 207: Connection Settings
Chapter 6 Manage Mobile Computer 6.3. CONNECTION SETTINGS To access connection settings: Tap Start | Settings | Control Panel | Network and Dial-up Connections. Tap Start | Settings | Network and Dial-up Connections. Icon Description MAKE NEW CONNECTION Tap to create a new connection which is not listed. USB SERIAL Sets serial profile for USB connection to a PC via ActiveSync.
Page 208 9700 Mobile Computer (CE) Reference Manual The taskbar items deliver the following functions: Button Description Tap this button to open the Connection menu. The available options depend on the connection you select. Tap this button to toggle on/off the connection you select. This can be used for Enable/Disable or Connect/Disconnect.
Page 209: Taskbar And Start Menu Settings
Chapter 6 Manage Mobile Computer 6.4. TASKBAR AND START MENU SETTINGS To access taskbar and Start Menu settings: Tap Start | Settings | Taskbar and Start Menu. Tabbed page Setting Description General Always on top Select to keep the taskbar at the top of the screen, even when an application is open.
Page 210 9700 Mobile Computer (CE) Reference Manual...
Page 211: Specifications
SPECIFICATIONS PLATFORM, PROCESSOR & MEMORY Operating System & CPU OS Version Microsoft Windows Embedded Compact 6.0 TI OMAP3730 1GHz Processor Memory 512MB DDR SDRAM Flash 4GB Flash ROM Expansion Slot One expansion slot, supports MicroSDHC up to 32GB COMMUNICATIONS & DATA CAPTURE Communications USB Host/Client USB 2.0...
Page 212: Electrical Characteristics
9700 Mobile Computer (CE) Reference Manual ELECTRICAL CHARACTERISTICS Batteries Main Battery Pack Standard capacity battery: 3.7V, 3600 mAh Large capacity battery: 3.7V, 5400 mAh Rechargeable Li-ion battery Charging time: approximately 4 hours for standard battery / 6 hours for large capacity battery Backup Battery 3.6V, 15 mAh...
Page 213: Physical Characteristics
Specifications PHYSICAL CHARACTERISTICS Color Tap Screen Display Display 3.5” Transflective TFT-LCD, 65K colors, sunlight readable Resolution QVGA 240 (W) x 320 (H) Keypad Layout Numeric keypad (30-key), Numeric & Function keypad (38-key), or Alphanumeric keypad (53-key) Backlight White LED backlight for display and keypad Notifications Status LED Three LEDs for showing scanning good read, radio connection...
Page 214: Environmental Characteristics
IP65 per applicable IEC 60529 sealing specs Electrostatic Discharge ± 15 kV air discharge, ± 8 kV direct/indirect contact discharge Note: CipherLab will not be held responsible for the mobile computer’s malfunction incurred by the operation outside operating temperature range. PROGRAMMING SUPPORT Development Environment &...
Page 215: Accessories
Specifications MIRROR Browser for web application Terminal Emulation Third-party software SOTI MobiControl for remote device control Naurtech CETerm – Terminal emulator (3270, 5250, VT) and industrial web browser SYSDEV Kalipso ACCESSORIES Accessory Options Snap-on Charging and Communication Cable (USB or RS-232) Charging &...
Page 216 9700 Mobile Computer (CE) Reference Manual...
Page 217: Scan Engine Settings
Appendix I SCAN ENGINE SETTINGS 9700 Series Mobile Computer supports the following reader types. Reader availability depends on the hardware integrated on the mobile computer. Scan Engine Laser SE955 Extra Long Range Laser SE1524 2D Imager SE4500 SE4500 + PL4507...
Page 218: Symbologies Supported
9700 Mobile Computer (CE) Reference Manual SYMBOLOGIES SUPPORTED Depending on the scan engine integrated on the mobile computer, supported symbologies will differ as listed below. Laser LR Laser LR 2D Codabar 　　　　 Code 11 　　　...
Page 219 Scan Engine Settings Japan Postal 　　　　 Netherlands KIX Code 　　　　 US Postnet 　　　　 US Planet 　　　　 UK Postal 　　　　 EAN/UPC EAN-8 　　　　 EAN-8 Extend 　...
Page 220 9700 Mobile Computer (CE) Reference Manual...
Page 221: Laser (Se955)
Appendix II LASER (SE955) The tables below list the symbology settings for the 1D laser scan engine (SE955). SYMBOLOGY SETTINGS Symbology Description Default CODABAR CodaBar Codabar Checkbox to enable Codabar decoding. Enable Length option Sets the length of the Codabar symbols to decode. Max / Min Length One Fixed length (Length 1)
Page 222 9700 Mobile Computer (CE) Reference Manual Code 39 Code 39 Checkbox to enable Code 39 decoding. Enable Trioptic Code 39 Selects whether to decode Trioptic Code 39. Disable Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges.
Page 223 Appendix II Laser (SE955) Length option Sets the length of the Code 39 symbols to decode. Max / Min Length One Fixed length (Length 1) (4-55) Two Fixed lengths (Length 1>Length 2) Max / Min Length (range: 0-55; Length 1<Length 2) Any Length Interleaved 25 Interleaved 25...
Page 224 9700 Mobile Computer (CE) Reference Manual Convert to UPC/EAN This only applies to GS1 DataBar-14 and GS1 DataBar Disable Limited barcodes not decoded as part of a Composite barcode. Convert to EAN-13 Strips the leading “010” from barcodes. The barcode must be composed of a leading “01” as the application identifier (AI) and a first digit of zero.
Page 225 Appendix II Laser (SE955) UPC-A UPC-A Checkbox to enable UPC-A decoding. Enable Preamble Decide whether include UPC-A/UPC-E/UPC-E1 Transmit preamble System Character (and Country Code) in the data System being transmitted. Character No transmit: transmits none of the above Transmit System Character: transmits system number only Transmit Sys.
Page 226: Miscellaneous
9700 Mobile Computer (CE) Reference Manual EAN Addon Option Decide whether to decode EAN-8, EAN-13 with addons Ignore Addon (including Addon 2 and 5). Ignore Addon Decode only with addons Auto-discriminate EAN Addon Redundancy When “Auto-discriminate” is applied, decide the number of times of supplementary decoding the same barcode to count as a valid read.
Page 227: Aim Code Id - Code Characters
Appendix II Laser (SE955) AIM CODE ID – CODE CHARACTERS Code Character Code Type Code 39, Code 39 Full ASCII, Code 32 Code 128, Coupon (Code 128 portion) Data Matrix UPC/EAN, Coupon (UPC portion) GS1 DataBar (RSS) Codabar Code 93 Code 11 Interleaved 25 PDF417, Macro PDF417, Micro PDF417...
Page 228 9700 Mobile Computer (CE) Reference Manual Modulo 10 check digit verified and transmitted. Modulo 10 check digit verified but not transmitted. Industrial Always transmit 0. (Discrete 25) UPC/EAN Standard data packet in full EAN country code format, which is 13 digits for UPC-A and UPC-E (not including addons).
Page 229 Appendix II Laser (SE955) Scan engine is set for Basic Channel operation (no escape character transmission protocol). Data characters 92 not doubled. When decoders are set to this mode, unbuffered Macro symbols and symbols requiring the decoder to convey ECI escape sequences cannot be transmitted.
Page 230 9700 Mobile Computer (CE) Reference Manual...
Page 231: Laser (Se1524)
Appendix III LASER (SE1524) The tables below list the symbology settings for the 1D extra long range laser scan engine (SE1524). SYMBOLOGY SETTINGS Symbology Description Default CODABAR CodaBar Codabar Checkbox to enable Codabar decoding. Enable Length option Sets the length of the Codabar symbols to decode. Max / Min Length One Fixed length (Length 1)
Page 232 9700 Mobile Computer (CE) Reference Manual Support Full ASCII Selects whether to enable Code 39 Full ASCII decoding. Disable Characters are paired to encode the full ASCII character set. Length option Sets the length of the Code 39 symbols to decode.
Page 233 Appendix III Laser (SE1524) Transmit Check Digit Decide whether to include the check digit in the data being Disable transmitted. Convert To EAN-13 Convert a 14-character Interleaved 25 barcode into EAN-13 Disable if the following requirements are met: The barcode must have a leading 0 and a valid EAN-13 check digit.
Page 234 9700 Mobile Computer (CE) Reference Manual Algorithm When two check digits are set for verification, two choices Double are available for the pair of check digits. Modulo 10 Modulo10 / Modulo11 Double Modulo 10 UPC/EAN EAN-8 EAN-8 Checkbox to enable EAN-8 decoding.
Page 235 Appendix III Laser (SE1524) UPC-E1 UPC-E1 Checkbox to enable UPC-E1 decoding. Disable Preamble Decide whether include UPC-A/UPC-E/UPC-E1 Transmit preamble System Character (and Country Code) in the data System being transmitted. Character No transmit: transmits none of the above Transmit System Character: transmits system number only Transmit Sys.
Page 236: Miscellaneous
9700 Mobile Computer (CE) Reference Manual UPC Security Level Sets the security level to ensure decoding accuracy Level 0 considering the printed quality of the barcodes such as Code 128, Code 93, and UPC/EAN. The higher the level is, the more security is ensured.
Page 237: Imager (Se4500Dl)
Appendix IV 2D IMAGER (SE4500DL) The tables below list the symbology settings for the 2D imager (SE4500DL). SYMBOLOGY SETTINGS 1D SYMBOLOGIES Symbology Description Default CODABAR CodaBar Codabar Checkbox to enable Codabar decoding. Enable Length option Sets the length of the Codabar symbols to decode. Max / Min Length One Fixed length (Length 1)
Page 238 9700 Mobile Computer (CE) Reference Manual CODE 39 Code 39 Code 39 Checkbox to enable Code 39 decoding. Enable Trioptic Code 39 Selects whether to decode Trioptic Code 39. Disable Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges.
Page 239 Appendix IV 2D Imager (SE4500DL) Concatenation Sets whether to enable decoding ISBT-128 by performing Disable concatenation of ISBT data Disable: Does not perform concatenation Enable: Performs concatenation ISBT-128 barcodes. Auto-discriminate: Auto-discriminates between ISBT-128 barcodes which require concatenation and those which do not need concatenation. Redundancy Sets redundancy between 2-20.
Page 240 9700 Mobile Computer (CE) Reference Manual Verify Check Digit Select whether to verify the check digit, which is the last Disable character of the barcode. If the check digit is incorrect, the barcode will not be accepted. Transmit Check Digit...
Page 241 Appendix IV 2D Imager (SE4500DL) Convert to UPC/EAN This only applies to GS1 DataBar-14 and GS1 DataBar Disable Limited barcodes not decoded as part of a Composite barcode. Convert to EAN-13 Strips the leading “010” from barcodes. The barcode must be composed of a leading “01” as the application identifier (AI) and a first digit of zero.
Page 242 9700 Mobile Computer (CE) Reference Manual Netherlands KIX Code Enable Netherlands KIX Checkbox to enable Netherlands KIX Code decoding. Enable Code US Postnet Enable US Postnet Checkbox to enable US Postnet decoding. Enable US Planet Enable US Planet Checkbox to enable US Planet decoding.
Page 243 Appendix IV 2D Imager (SE4500DL) Preamble Decide whether include UPC-A/UPC-E/UPC-E1 Transmit preamble System Character (and Country Code) in the data System being transmitted. Character No transmit: transmits none of the above Transmit System Character: transmits system number only Transmit Sys. Character and Country Code: transmits system number and country code Convert to UPC-A The UPC-E barcode will be expanded into UPC-A format, and...
Page 244: Symbologies
9700 Mobile Computer (CE) Reference Manual UPC Addon Redundancy When “Auto-discriminate” is applied, decide the number of times of supplementary decoding the same barcode to count as a valid read. Configurable between 2 and 30. 2D SYMBOLOGIES Symbology Description Default...
Page 245: Miscellaneous
Appendix IV 2D Imager (SE4500DL) Maxicode MicroPDF417 MicroPDF417 Selects whether to enable MicroPDF417 decoding. Disable Code 128 Emulation Transmit data from certain Micro PDF 417 barcodes as if it Disable was encoded in Code 128 barcodes. Transmit AIM code ID character in Miscellaneous options must be enabled first.
Page 246 9700 Mobile Computer (CE) Reference Manual...
Page 247: Imager (Ex25)
Appendix V 2D IMAGER (EX25) The tables below list the symbology settings for the extra long range 2D imager (EX25). SYMBOLOGY SETTINGS 1D SYMBOLOGIES Symbology Description Default CODABAR CodaBar Codabar Checkbox to enable Codabar decoding. Enable Length option Sets the length of the Codabar symbols to decode. Max / Min Length One Fixed length (Length 1)
Page 248 9700 Mobile Computer (CE) Reference Manual CODE 39 Code 39 Code 39 Checkbox to enable Code 39 decoding. Enable Trioptic Code 39 Selects whether to decode Trioptic Code 39. Disable Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges.
Page 249 Appendix V 2D Imager (EX25) Length option Sets the length of the Code 39 symbols to decode. Max / Min Length One Fixed length (Length 1) (4-55) Two Fixed lengths (Length 1>Length 2) Max / Min Length (range: 0-55; Length 1<Length 2) Any Length Interleaved 25 Interleaved 25...
Page 250 9700 Mobile Computer (CE) Reference Manual UPC Composite Mode UPC barcodes can be "linked" with a 2D barcode during UPC Always transmission as if they were one barcode. Linked UPC Never Linked Transmit UPC barcodes regardless of whether a 2D barcode is detected.
Page 251 Appendix V 2D Imager (EX25) Algorithm Double When two check digits are set for verification, two choices Modulo 10 are available for the pair of check digits. Modulo10 / Modulo11 Double Modulo 10 POSTAL CODE Australian Postal Enable Australian Checkbox to enable Australian Postal decoding. Enable Postal Japan Postal...
Page 252 9700 Mobile Computer (CE) Reference Manual Preamble Decide whether include UPC-A/UPC-E/UPC-E1 Transmit preamble System Character (and Country Code) in the data System being transmitted. Character No transmit: transmits none of the above Transmit System Character: transmits system number only Transmit Sys. Character and Country Code: transmits...
Page 253: Symbologies
Appendix V 2D Imager (EX25) 2D SYMBOLOGIES Symbology Description Default Aztec Aztec Selects whether to enable Aztec decoding. Enable Aztec Inverse Decide whether to decode Aztec Inverse. Regular only Regular only Decode regular Aztec barcodes only. Inverse only Decode inverse Aztec barcodes only. Inverse Auto-detect Decode both regular and inverse Aztec barcodes.
Page 254: Miscellaneous
9700 Mobile Computer (CE) Reference Manual Code 128 Emulation Transmit data from certain Micro PDF 417 barcodes as if it Disable was encoded in Code 128 barcodes. Transmit AIM code ID character in Miscellaneous options must be enabled first. When applied, the MicroPDF417 barcodes are transmitted...
Page 255: Physical Keypad Reference Table
Appendix VI PHYSICAL KEYPAD REFERENCE TABLE NUMERIC KEYPAD (30 KEYS) Numeric keypad layout: USING ALPHA, SHIFT & FN KEYS ] Mode Mode α α Normal [Fn] Mode Mode press press press press press press press press Backlight Increase Volume Up Backlight Decrease Volume...
Page 256 9700 Mobile Computer (CE) Reference Manual Right Right Right Highlight Right Enter Enter Enter Enter Enter Keypad Backspace Backspace Backspace Backspace Lock Shift Shift Space Space Space Space Windows Ctrl Ctrl Ctrl Ctrl Green Shift+F1 Shift+F2 Shift+F3 Shift+F4 Note: Although keys 0-9 allow up to four presses to input different values, the function of Ctrl and Alt can only be delivered to the value entered at the first press of each key.
Page 257: Numeric & Function Keypad (38 Keys)
Appendix VI Physical Keypad Reference Table NUMERIC & FUNCTION KEYPAD (38 KEYS) Numeric and Function keypad layout: USING ALPHA, SHIFT & FN KEYS Normal Mode ] Mode Mode Mode ] Mode α α Shift+1 Shift+2 Shift+3 Shift+4 Shift+5 Shift+6 Shift+7 Shift+8 Shift+9 Shift+0...
Page 258 9700 Mobile Computer (CE) Reference Manual Shift+F4 Shift+F5 Backlight Shift+F6 Increase Shift+F7 Volume Up Shift+F8 Backlight Shift+F9 Decrease Shift+F10 Volume Down Shift Shift Shift Shift Shift...
Page 259: Alphanumeric Keypad (53 Keys)
Appendix VI Physical Keypad Reference Table ALPHANUMERIC KEYPAD (53 KEYS) Alphanumeric keypad layout: USING ALPHA, SHIFT & FN KEYS Mode [α] Mode [Ctrl] Mode Normal Shift+1 Ctrl+1 Shift+2 Ctrl+2 Shift+3 Ctrl+3 Shift+4 Ctrl+4 Shift+5 Ctrl+5 Shift+6 Ctrl+6 Shift+7 Ctrl+7 Shift+8 Ctrl+8 Shift+9 Ctrl+9...
Page 260 9700 Mobile Computer (CE) Reference Manual Shift Shift Shift Green Shift+F14 Shift+F15 , (COMMA) Ctrl+a . (PERIOD) Ctrl+b 0xDE Ctrl+c Backlight Increase Ctrl+d 0xDB Ctrl+e 0xDD Ctrl+f 0xDC Ctrl+g Volume Up Ctrl+h Backlight Decrease Ctrl+i 0xC0 Ctrl+j VK_F12 Ctrl+k VK_F11...
