FXS Voice Interface Connection

Figure 3-4: FXS analog voice port interface diagram between AP1200 VoIP
gateway and phone, Fax and PBX access lines
AddPac Technology Co., Ltd.
FXS Interfaces can connect directly to standard analog telephones, FAX machines
or similar devices and supplies ring, voltage and dial tone. This interface is an
RJ-11 connector that allows connections to basic telephone service equipment,
keyphones, and PBXes.
