VoiceFinder AP1200 VoIP Gateway Installation Guide Version 1.0
Chapter 1. VoiceFinder AP1200 VoIP Gateway
Overview
Introduction to VoiceFinder AP1200 Gateway
VoiceFinder AP1200 VoIP Gateway is a standards-based communication device
supporting 2-port 10/100Mbps Fast Ethernet that deliver true, next-generation Voice
over IP (VoIP) service to SOHO and residences worldwide by connecting Local Area
Networks or Wide Area Network.
The below is the network diagram using VoiceFinder AP1200 Gateway.
Figure 1-1: The network diagram using VoiceFinder AP1200 Gateway
It supports static RIP v1/v2, OSPF v2 standard routing protocols, IEEE Spanning Tree
Bridging function and it can be used for routing of both small and large-scale networks.
As a supplementary service, VoiceFinder AP1200 Gateway provides Packet Filtering
and Firewall function using Access List method.
network from outside networks using source and destination IP address access list
information at the Network Layer (IP Layer) and at the Transport Layer (TCP/UDP
Layer).
Also, using DHCP (Dynamic Host Configuration Protocol), this equipment can assign
AddPac Technology Co., Ltd.
It restricts access to the local
10
-
-
