VoiceFinder AP1200 VoIP Gateway Installation Guide Version 1.0

Cable Specification

This Appendix provides information about the Pinout specifications of the following
cables used with VoiceFinder AP1200 Gateway.
[Console Port Signal & Pinout]
In order to connect the gateway console port with the Terminal Emulating PC, the
RJ-45 to DB9 (Female DTE Connector) cable is used. The transferred signal and
Pinout specifications are enlisted in the following table.

Table 4-1: The transferred signal and Pinout specification

Gateway Console
AddPac Technology Co., Ltd.
Console Port Signal and Pinout (RJ-45 to DB9)
Ethernet Cable Assemble (RJ-45 to RJ-45) Pinout
(DTE)
Signal
RTS
DTR
TxD
GND
GND
RxD
DSR
CTS
RJ-45
RJ-45 Pin
1
2
3
4
5
6
7
8
Console Device
DB-9
DB-9 Pin
8
6
2
5
5
3
4
7
(PC)
Signal
CTS
DSR
RxD
GND
GND
TxD
DTR
RTS
43
- -
