The following Table 1-2 explains the rear side panel interface of AP1200 VoIP gateway.

Table 1-2: The interfaces and explanation of the rear panel of AP1200 Gateway

FXS (0/0 ~ 1/3)

Table 1-3: The interfaces of VoiceFInder AP1200 VoIP Gateways

Model
AP1200
Type A
AP1200
Type B
AddPac Technology Co., Ltd.
Interface
POWER
DC 5V 4A Power adapter terminal and a power switch.
1-port FXO voice interface.
FXO
extension line of PBX. (1 x RJ11)
4 or 8-port FXS voice interface. Can be connected to analog
phones and FAX machines. (8 x RJ11)
LAN0
10/100Mbps Ethernet Port for WAN interface (RJ45)
LAN1
10/100Mbps Ethernet Port for LAN interface (RJ45)
Console
RS-232C serial port for system management (RJ45)
WAN
1 x 10/100Mbps
1 x 10/100Mbps
Explanation
LAN FXS
1 x 10/100Mbps
1 x 10/100Mbps
Can be connected to the
FXO Console
8 1
4 1
-
1
1
18
-
