VoiceFinder AP1200 VoIP Gateway Installation Guide Version 1.0
Figure 3-3: Network connection diagram between AP1200 VoIP Gateway and
local LAN network
AddPac Technology Co., Ltd.
In case of IP share mode, connect PC directly to the LAN1 Interface. In case of
NAT/PAT, connect a local HUB. For the detailed configuration, refer to Operation
Manual or Quick Operation Manual.
Use a crose cable to connect a user PC
Use a direct cable to connect a HUB.
30
-
-
