FXO Voice Interface Connection

Figure 3-5: FXO analog voice port interface diagram between AP1200 VoIP

gateway and PBX or PSTN

AddPac Technology Co., Ltd.

FXO interface is an RJ-11 connector that allows an analog connection to be

directed at the public switched telephone network's (PSTN's) central office or to a

station interface on a PBX. The FXO sits on the PSTN switch end of the

connection. It plugs directly into the line side of PSTN switch so PSTN switch

thinks the FXO interface is a telephone.
