2-6.2 WOL1 Wake On LAN

1 3
FAN1
SOCKET A
RT1
VT8366A
AGP 4X
PCI 1
AC'97 1 4
JCD_IN1 PCI 2
Codec
PCI 3
LPC I/O
PCI 4
Controller
1 3
PCI 5
WOL1
PCI 6
CNR1
This connector connects to a LAN card with a Wake On LAN output. The
connector powers up the system when it receives a wake-up packet or
signal through the LAN card.
This feature requires that Wake On LAN feature is enabled in the BIOS
setting called "Power Management Setup" and that your system must
be on ATX power supply with at least

2-6.3 CD-ROM Audio Connector (JCD_IN1)

1 3
FAN1
SOCKET A
RT1
VT8366A
AGP 4X
PCI 1
AC'97 1 4 JCD_IN1
PCI 2
Codec
PCI 3
LPC I/O
PCI 4
Controller
1 3
PCI 5
WOL1
PCI 6
CNR1
VIA
VIA
VT8233
1 3
JBAT1
SCR1
16 16
1 3
1 1 FAN4
USB2 USB3
VIA
VIA
VT8233
1 3
JBAT1
SCR1
16 16
1 3
FAN4
1 1
USB2 USB3
31
Chapter 2 Hardware Setup
GND
+5V
Standby
WOL1: Wake On LAN
Connect the Wake On
LAN signal from LAN
card to WOL1
720mA / +5V standby power.
1 4
JCD_IN1
JCD_IN1: CD ROM Audio Connector
PIN NO.
PIN 1
Channel
PIN 2
PIN 3
PIN 4
Channel
PME
WOL1
CD1
Left
GND
GND
Right
