SOLTEK SL-75DRV-X User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

R
T h e
S o u l
O f
C o m p u t e r
T e c h n o l o g y
SL-75DRV/75DRV-X
USER MANUAL v1.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-75DRV-X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOLTEK SL-75DRV-X

Summary of Contents for SOLTEK SL-75DRV-X

  • Page 1 T h e S o u l C o m p u t e r T e c h n o l o g y SL-75DRV/75DRV-X USER MANUAL v1.4...
  • Page 2 Soltek Computer Inc. has been advised of the possibility of such damages arising from any defect or error in this manual or product.

  • Page 3: Soltek Computer Inc

    SOLTEK AROUND THE WORLD SOLTEK COMPUTER INC. Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei- Hsien, Taiwan, R.O.C. Telephone : 886-2-2642-9060 : 886-2-2642-9065 E-mail : sales@soltek.com.tw Web site : http://www.soltek.com.tw SOUL TECHNOLOGY EUROPE B.V. Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-...

  • Page 4: Table Of Contents

    75DRV/75DRV-X CONTENT CHAPTER 1 INTRODUCTION ..........9 1-1 MAINBOARD SPECIFICATION ..........10 1-1.1 PROCESSOR ................. 10 1-1.2 CHIPSET ..................10 1-1.3 AWARD BIOS V6.0 SUPPORTING ..........10 1-1.4 SOUND CONTROLLER ..............10 1-1.5 POWER MANAGEMENT ..............10 1-1.6 FULL FEATURED ACCELERATED GRAPHICS PORTS (AGP) CONTROLLER ................
  • Page 5 2-4 HDD/FDD INSTALLATION ............22 2-5 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE 24 2-5.1 Information On AMD Socket 462 Processor (Model4, 5 Products) . 24 2-5.2 Information On AMD Socket 462 Processor (Model6, 7 Products) . 25 2-5.3 Frequency Ratio Select (By SW1 DIP1-DIP5) ........ 26 2-5.4 Processor Core Voltage Select (By SW2 DIP1-DIP6) .....
  • Page 6 75DRV/75DRV-X CHAPTER 3 SOFTWARE SETUP ......... 44 3-1 VIA CHIPSET DRIVER INSTALLATION (4-IN-1 DRIVER) ..45 3-2 HARDWARE MONITOR INSTALLATION ........ 48 3-3 AC’97 AUDIO CODEC DRIVER INSTALLATION ....50 CHAPTER 4 BIOS SETUP ............. 52 4-1 WHAT IS BIOS SETUP ............53 4-2 HOW TO RUN BIOS SETUP ...........
  • Page 7 APPENDICES ................. 94 APPENDIX-1 TECHNICAL TERMS ..........95 APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS .... 96 PART NUMBER ............. 96 APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER ..98...

  • Page 8: Item List Checkup

    75DRV/75DRV-X ITEM LIST CHECKUP Mainboard ==== Support CD ==== User’s Manual ==== Bundled Bonus Pack CD ==== Bundled Bonus Pack Manual ==== Temperature Sensor Cable ==== ATA66/100 IDE Cable ==== RS232 Cable FDD Cable...

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction CHAPTER INTRODUCTION • This chapter briefly introduces the characteristics of the mainboards. It includes the information regarding the chipset, CPU types, built-in functions and layout. Users will have more ideas about mainboards after reading this chapter. This chapter contains the following topics : 1-1 MAINBOARD SPECIFICATION 1-2 MAINBOARD LAYOUT 1-3 CHIPSET DIAGRAM...

  • Page 10: Mainboard Specification

    75DRV/75DRV-X 1-1 MAINBOARD SPECIFICATION 1-1.1 PROCESSOR • Supporting AMD Athlon Thunderbird processor up to 1.5GHz or above. • Supporting AMD Athlon Duron processor up to 1.2GHz or above. • Supporting 200MHz & 266MHz FSB bus. • Supporting Processor VID(voltage ID) and FID(Frequency ID) auto detection.

  • Page 11: 1-1.6 Full Featured Accelerated Graphics Ports (Agp)

    Chapter 1 Introduction 1-1.6 FULL FEATURED ACCELERATED GRAPHICS PORTS (AGP) CONTROLLER • AGP v2.0 compliant. • Supports Side Band Addressing(SBA) mode (non-multiplexed address / data). • Supporting 66MHz 1x, 2x, and 4x modes for AD and SBA signaling. 1-1.7 MULTI-I/O FUNCTION •...

  • Page 12: 1-1.10 Form Factor

    75DRV/75DRV-X 1-1.10 FORM FACTOR • ATX form factor, 4- layer PCB. • Mainboard size 22.0cm x 30.5cm. 1-1.11 HARDWARE MONITOR • Programmable control, status to provide, monitoring and alarm for flexible desktop management (software include). • 5 positive voltage statuses monitoring. •...

  • Page 13: Mainboard Layout

    Chapter 1 Introduction 1-2 MAINBOARD LAYOUT 1-2.1 Mainboard Layout --- 75DRV 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 VT8366 AGP PRO 4X FDC1 AC'97 Codec PCI 1 IDE1 PCI 2 IDE2 JCD_IN1 LPC I/O Controller...

  • Page 14: 1-2.2 Mainboard Layout

    75DRV/75DRV-X 1-2.2 Mainboard Layout --- 75DRV-X 6 5 4 3 2 1 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 VT8366 AGP PRO 4X FDC1 AC'97 Codec PCI 1 IDE1 PCI 2 IDE2 JCD_IN1 LPC I/O Controller PCI 3 Battery TECH VT8233...

  • Page 15: Chipset Diagram

    Chapter 1 Introduction 1-3 CHIPSET DIAGRAM--- 75DRV/75DRV-X • The VT8366 and VT8233 chipset is a high performance, cost-effective and energy efficient system controller for the implementation of AGP / PCI / ISA desktop personal computer system based on 64-bit Socket-A (AMD Athlon) processors.
  • Page 16 75DRV/75DRV-X MEMO MEMO...

  • Page 17: Chapter 2 Hardware Setup

    Chapter 2 Hardware Setup CHAPTER HARDWARE SETUP ATTENTION !!! 1. Please refer to your processor installation or other documentation attached to your CPU for detailed in- stalling instruction. 2. Installing a heat sink and cooling fan is necessary for proper heat dissipation from your CPU. Incorrect installation may result in overheating and damage of your CPU.

  • Page 18: Cpu Installation

    75DRV/75DRV-X 2-1 CPU INSTALLATION WARNING !!! • Make sure that +5V DCV and +3.3 DCV capabilities of your power supply are suitable for the processor. • Any attempt to operate the AMD Athlon or Duron processor without a suitable cooling Fan will damage processor and other component. Pull out the lever from the socket, and then raise the le- ver up to a 90-degree angle.

  • Page 19: Memory Installation

    Chapter 2 Hardware Setup 2-2 MEMORY INSTALLATION WARNING!!! • Make sure to unplug your power supply before adding or removing memory modules or other system components. Failure to do so may cause severe damage to both your mainboard and expansion cards. •...
  • Page 20 75DRV/75DRV-X 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 VT8366 AGP PRO 4X N O T I C E : W h e n L E D FDC1 AC'97 “ZD1” is on, meaning that Codec PCI 1 IDE1...

  • Page 21: Accelerated Graphics Port(Agp) Pro Installation

    Chapter 2 Hardware Setup 2-3 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION • The AGP Pro connector is an extension of the existing AGP connector and it is compatible with existing AGP cards. AGP Accelerator AGP Pro slot blockader Accelerated Graphics Port (AGP) Pro Slot Rib(inside slot) 20-pin bay Rib(inside slot) 28-pin bay...

  • Page 22: Hdd/Fdd Installation

    75DRV/75DRV-X 2-4 HDD/FDD INSTALLATION • To install HDD (Hard Disk Drive), you may connect the cable’s blue con- nector to the mainboard’s primary (IDE1) or secondary (IDE2) connector, and then connect the gray connector to your slave device and the black connector to your master device.
  • Page 23 Chapter 2 Hardware Setup • To install FDD (Floppy Disk Drive), you may connect the single end to the board , and connect two plugs on the other end to the floppy drives. 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A...

  • Page 24: Switch Setting For Cpu Frequency And Voltage

    75DRV/75DRV-X 2-5 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE 2-5.1 Information On AMD Socket 462 Processor (Model4, 5 Products) • On the AMD Socket 462 Processor, you can find a codified identification marking which is to provide useful information about the CPU. The marking is interpreted as below.

  • Page 25: 2-5.2 Information On Amd Socket 462 Processor (Model6, 7 Products)

    Chapter 2 Hardware Setup 2-5.2 Information On AMD Socket 462 Processor (Model6, 7 Products) XXXXXXXXXXX XXXXXXXXXXXX XXXXXXX XXXXXXXXX XXXXXXXXXXX XXXX AMD XXXX A HD 1533 A N S 3 C 4 5 6 7 8 Family/Architecture: A= AMD Athlon™Model 4 Processor Architure. D= AMD Duron™...

  • Page 26: 2-5.3 Frequency Ratio Select (By Sw1 Dip1-Dip5)

    75DRV/75DRV-X 2-5.3 Frequency Ratio Select (By SW1 DIP1-DIP5) • The AMD Athlon and Duron processors provides four Frequency ID signals (FID) for the system controller to indicate the SYSTCLK multiplier at which the processor core operates. Normally, multiplier (or bus ratio) is detected automatically.

  • Page 27: 2-5.4 Processor Core Voltage Select (By Sw2 Dip1-Dip6)

    Chapter 2 Hardware Setup 2-5.4 Processor Core Voltage Select (By SW2 DIP1-DIP6) • DIP1-DIP6 SW2 allow you to adjust processor core voltage manually. We recommend to leave SW2 DIP1 at default, the default means the correct processor core voltage is generated according to VID of CPU. SW2 DIP2 ~ DIP6 SETTING SW2 DIP1 6 5 4 3 2 1...

  • Page 28: 2-5.5 Cpu External Frequency Setting (By Sw3)

    75DRV/75DRV-X 2-5.5 CPU External Frequency Setting (By SW3) CPU EXTERNAL CLOCK PCI CLOCK FSB CLOCK 100MHz 33.3MHz 200MHz (Default) 120MHz 30.0MHz 240MHz 133.3MHz 33.3MHz 266MHz 140MHz 35.0MHz 280MHz 150MHz 37.5MHz 300MHz IMPORTANT: • Do figure out the correct processor type by processor’s OPN (Ordering Part Numbers).

  • Page 29: Jumper Setting For Devices On Board

    Chapter 2 Hardware Setup 2-6 JUMPER SETTING FOR DEVICES ON BOARD • The following diagrams show the location for jumper blocks on the mainboard. CAUTION !! • Do not remove the jumper when power is on. Always make sure the power is off before changing any jumpers.

  • Page 30: 2-6.2 Jp17 Power Lost Resume

    75DRV/75DRV-X 2-6.2 JP17 Power Lost Resume 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 VT8366 Power Lost Resume: AGP PRO 4X FDC1 AC'97 Normal Codec PCI 1 JP17 IDE1 (default) PCI 2 IDE2 JCD_IN1 LPC I/O...

  • Page 31: 2-6.4 Jbat1 For Clear Cmos Data

    Chapter 2 Hardware Setup 2-6.4 JBAT1 For Clear CMOS Data A battery must be used to retain the mainboard configuration in CMOS RAM. 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 VT8366 JBAT1 For Clear CMOS Data: AGP PRO 4X FDC1...

  • Page 32: Connectors Configurations

    75DRV/75DRV-X 2-7 CONNECTORS CONFIGURATIONS • This section lists out all connectors configurations for users’ reference. 2-7.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) On Board FAN Connector (FAN 1: 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 On Board FAN Connector...

  • Page 33: 2-7.2 Wol1 Wake On Lan

    Chapter 2 Hardware Setup 2-7.2 WOL1 Wake On LAN 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 +5V standby VT8366 Wake On LAN: AGP PRO 4X FDC1 AC'97 Codec PCI 1 IDE1 Connect the Wake PCI 2 IDE2...

  • Page 34: 2-7.4 Thermal Sensor Connector (Rt2)

    75DRV/75DRV-X 2-7.4 Thermal Sensor Connector (RT2) 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A Thermal Sensor Connector (RT2): SSF1 VT8366 AGP PRO 4X FDC1 AC'97 Codec PCI 1 IDE1 PCI 2 IDE2 JCD_IN1 LPC I/O Controller PCI 3...

  • Page 35: 2-7.5 Complex Header Con1

    Chapter 2 Hardware Setup 2-7.5 Complex Header CON1 • This complex Header consists of 9 connectors providing various supports: CON1 15 15 SUSPEND LED SMI SIGNAL SUSPEND LED SIGNAL POWER SWITCH ATX POWER SWITCH NO CONNECTION NO CONNECTION NO CONNECTION POWER LED NO CONNECTION NO CONNECTION...

  • Page 36: 2-7.6 Atx Power Supply Connector

    75DRV/75DRV-X 6. Power LED Connector: CONNECTION: Connected to System Power LED. FUNCTION: To supply power to “System Power LED”. 7. Reset Switch Connector: CONNECTION: Connected to the case-mounted “Reset Switch”. FUNCTION: To supply power to “Reset Switch” and support system reboot function.

  • Page 37: 2-7.7 Chassis Panel Connector

    Chapter 2 Hardware Setup 2-7.7 Chassis Panel Connector A : PS/2 MOUSE PORT B : USB 0 PORT C : LPT1 PORT D : GAME/MIDI PORT E : PS/2 KEYBOARD PORT F : USB 1 PORT G : COM 1 PORT H : COM 2 PORT : LINE OUT / SPEAKER OUT PORT J : LINE IN...

  • Page 38: 2-7.8 Smart Card Reader Connector (Scr1)

    75DRV/75DRV-X 2-7.8 Smart Card Reader Connector (SCR1) • The connector “SCR1” allows you to use Smart Card Reader. It is compliant with Personal Computer Smart Card (PC/SC) working group standard and smart card (ISO 7816) protocols. 6 5 4 3 2 1 5 4 3 2 1 FAN2 FAN1...

  • Page 39: 2-7.9 Communication And Networking Riser Slot (Cnr)

    Chapter 2 Hardware Setup 2-7.9 Communication And Networking Riser Slot (CNR) • This connector allows you to use network, modem or audio riser cards. 5 4 3 2 1 6 5 4 3 2 1 FAN2 FAN1 SOCKET A SSF1 VT8366 AGP PRO 4X FDC1...

  • Page 40: 2-7.10 Usb Header (Usb2/Usb3 Header)

    75DRV/75DRV-X 2-7.10 USB Header (USB2/USB3 Header) • This header is for connecting the additional USB cable to provides you additional two USB ports. User can order the additional USB cable from your mainboard dealer and vender. Additional USB Cable (Optional) red wire Black Black...

  • Page 41: Voice Diagnostic Function For 75Drv-X Only

    Chapter 2 Hardware Setup 2-8 VOICE DIAGNOSTIC FUNCTION FOR 75DRV-X ONLY • A Voice Diagnostic Function is incorporated in “Advanced BIOS Features” of the “Award BIOS Setup” as “VD-Tech II Function”. With this function enabled in “Advanced BIOS Features”, it will voice out the problems or conflicts whenever user configures the components or boots up the PC system.

  • Page 42: 2-8.1 Jp10 Vd-Tech Ii Language Select

    75DRV/75DRV-X 2-8.1 JP10 VD-Tech II Language Select With “VD-Tech II Function” enabled in “Advanced BIOS Features” of Award BIOS Setup, you can choose either Chinese or English as the language of the VD-Tech II Function. 6 5 4 3 2 1 5 4 3 2 1 FAN2 FAN1...
  • Page 43 Chapter 2 Hardware Setup MEMO MEMO...

  • Page 44: Chapter 3 Software Setup

    75DRV/75DRV-X CHAPTER SOFTWARE SETUP ABOUT SUPPORT CD • In Support CD, it contains most informations for user’s requirement, such as Acrobat Reader, BIOS, User’s full version Manual, Driver, Hardware Monitor (if mainboard supports this function), Patch, and Utilities etc. User can browse the CD and get further details in regard of our mainboard.

  • Page 45: Via Chipset Driver Installation (4-In-1 Driver)

    Chapter 3 Software Setup 3-1 VIA CHIPSET DRIVER INSTALLATION (4-IN-1 DRIVER) • When a welcome window • Please put the Support CD appears on the screen, provided in your mainboard users should choose “Install package into the CD-ROM Driver”. drive. •...
  • Page 46 75DRV/75DRV-X • Press select the checkbox as below: Bus Master PCI IDE Driver AGP VxD Driver VIA Chipset Function’s Registry IRQ Routing Miniport Driver Next Note: For user who are upgrading VIA Drivers, we recommend to install the 4-in-1 as it will automatically detect and update the necessary drivers. •...
  • Page 47 Chapter 3 Software Setup • Select “Install VIA AGP VxD” Next in turbo mode and press Next button to continue. • Select “Install VIA IRQ Next Routing Miniport Driver” checkbox, then click the “Next” button to continue. • After all these setup proce- Finish dures have finished, please restart your computer by...

  • Page 48: Hardware Monitor Installation

    75DRV/75DRV-X 3-2 HARDWARE MONITOR INSTALLATION • Please put the Support CD • When a welcome window provided in your mainboard appears on the screen, package into the CD-ROM users should choose “Install drive. Driver”. • Click on the “Hardware • Click on the “VIA Chipset Monitor Utility”.
  • Page 49 Chapter 3 Software Setup • Click on the “OK” button. • The following screen shows the ITE SMARTGUARDIAM, which shows the information about system temperatures, voltages and Fan speed. You can also change some Value settings for your system to optimize its performance.

  • Page 50: Ac'97 Audio Codec Driver Installation

    75DRV/75DRV-X 3-3 AC’97 AUDIO CODEC DRIVER INSTALLATION • Please put the Support CD • When a welcome window provided in your mainboard appears on the screen, package into the CD-ROM users should choose “Install drive. Driver”. • Click on the “VIA Chipset •...
  • Page 51 Chapter 3 Software Setup MEMO MEMO...

  • Page 52: Chapter 4 Bios Setup

    75DRV/75DRV-X CHAPTER BIOS SETUP THE BIOS • BIOS stands for Basic Input and Output System. It is sometimes called ROM BIOS because it is stored in a Read-Only Memory(ROM) chip on the mainboard. BIOS is the first program to run when you turn on your computer.

  • Page 53: What Is Bios Setup

    Chapter 4 BIOS Setup 4-1 WHAT IS BIOS SETUP • BIOS setup is an interactive BIOS program that you need to run when: 1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.) 2. Modifying the behavior of your computer. (For example: changing the system time or date, or turning special features on or off etc.) 3.

  • Page 54: 4-5.1 Before Upgrading Bios

    75DRV/75DRV-X • The upgrade utility can be loaded on a floppy diskette and used to provides the capability to save, verify, and update the system BIOS. The upgrade utility can be run from a hard disk drive or a network drive. 4-5.1 BEFORE UPGRADING BIOS •...
  • Page 55 Chapter 4 BIOS Setup Step 4. Type awdflash *.bin /sn/py/cc and then press <Enter> to run BIOS upgrade program. (*.bin depends on your mainboard model and version code. Instead of typing “*”, you should type specific file name for your specific mainboard). Step 5.
  • Page 56 75DRV/75DRV-X Award Flash Memory Writer Start Screen Award Flash Memory Writer Complete Screen...
  • Page 57 Chapter 4 BIOS Setup The parameters of AWDFLASH.EXE /sn: No original BIOS backup /py: Program flash memory /cc: Clear CMOS data (and update data automatically) after pro- gramming NOTE: Users can type AWDFLASH /? to get further details about the parameters.

  • Page 58: Bios Setup

    75DRV/75DRV-X 4-6 BIOS SETUP --- CMOS SETUP UTILITY 4-6.1 CMOS SETUP UTILITY • This mainboard comes with the AWARD BIOS from AWARD Software Inc. Enter the CMOS Setup Utility Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 59: 4-6.2 Standard Cmos Setup

    Chapter 4 BIOS Setup 4-6.2 STANDARD CMOS SETUP • Standard CMOS Setup records some basic system hardware configuration and sets the system clock and error handling. You only need to modify the configuration values of this option if you want to change your system hard- ware configuration or when the data stored in the CMOS memory gets lost or damaged.
  • Page 60 75DRV/75DRV-X Date (mm:dd:yy) The BIOS determines the day of the week from the other date information. This field is for information only. Press the left or right arrow key to move to the desired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the desired value into the field.
  • Page 61 Chapter 4 BIOS Setup Drive A / Drive B Select this field to the type(s) of floppy disk drive(s) installed in your system. The choices are: 360KB, 5.25in; 1.2MB, 5.25in; 720KB, 3.5in; 1.44MB, 3.5in; 2.88MB, 3.5in; None. Video Select the type of primary video subsystem in your computer.

  • Page 62: 4-6.3 Advanced Bios Features

    75DRV/75DRV-X 4-6.3 ADVANCED BIOS FEATURES • ADVANCED BIOS FEATURES improves your system performance or sets up system features according to your preference. Run the ADVANCED BIOS FEATURES as follows: 1. Choose “ADVANCED BIOS FEATURES” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced BIOS Features...
  • Page 63 Chapter 4 BIOS Setup 2. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys. An explanation of the <F> keys follows: <F1>: “Help” gives options available for each item. <F5>: Get the previous values.
  • Page 64 75DRV/75DRV-X CPU L2 Cache ECC When you select Enabled, it will speed up memory Checking checking when the external cache contains ECC SRAMs. The choices: Enabled; Disabled. Quick Power On Self Select Enabled to reduce the amount of time required to Test run the power-on self-test (POST).
  • Page 65 Chapter 4 BIOS Setup Typematic Rate Setting When Disabled, the following two items (Typematic Rate and Typematic Delay) are irrelevant. Keystroke repeats at a rate determined by the keyboard controller in your system. When Enabled, you can select a typematic rate and typematic delay.

  • Page 66: 4-6.4 Advanced Chipset Features

    75DRV/75DRV-X 4-6.4 ADVANCED CHIPSET FEATURES • ADVANCED CHIPSET FEATURES is used to modify the values of chipset buffers. These buffers control the system options. Run the ADVANCED CHIPSET FEATURES as follows: 1. Choose “ADVANCED CHIPSET FEATURES” from the Main Menu and a list of option will appear: 2.
  • Page 67 Chapter 4 BIOS Setup DRAM CLOCK/DRIVE CONTROL CMOS Setup Utility - Copyright (C) 1984-2001 Award Software DRAM Clock/Drive Control Item Help Current FSB Frequency 100MHz Menu Level 100MHz DRAM Clock DRAM Timing By SPD SDRAM Cycle Length Bank Interleave Disabled DRAM Command Rate 1T Command :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help...
  • Page 68 75DRV/75DRV-X * DRAM Command The choices: Disabled; 2 Bank; 4 Bank. Rate AGP & P2P BRIDGE CONTROL CMOS Setup Utility - Copyright (C) 1984-2001 Award Software AGP & P2P Bridge Control Item Help AGP Aperture Size Menu Level AGP Mode Auto AGP Driving Control AGP Driving Value...
  • Page 69 Chapter 4 BIOS Setup * AGP Driving Value This item allows you to adjust the AGP driving force. The choice: Min=0000 ~ Max=00FF. * AGP Fast Write This item will enable the AGP model into fast write mode. If your graphics card does not support this function, please do not enable this function.
  • Page 70 75DRV/75DRV-X * PCI1 Post Write Leave this field at default. * PCI2 Post Write Leave this field at default. * PCI Delay Transac- Leave this field at default. tion Memory Hole In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory space below 16MB.

  • Page 71: 4-6.5 Integrated Peripherals

    Chapter 4 BIOS Setup 4-6.5 INTEGRATED PERIPHERALS • INTEGRATED PERIPHERALS option allows you to get some information inside your system when it is working. Run the INTEGRATED PERIPHERALS as follows: 1. Choose “INTEGRATED PERIPHERALS” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Integrated Peripherals...

  • Page 72: Via Onchip Ide Device

    75DRV/75DRV-X VIA ONCHIP IDE DEVICE CMOS Setup Utility - Copyright (C) 1984-2001 Award Software VIA OnChip IDE Device Item Help OnChip IDE Channel0 Enabled OnChip IDE Channel1 Enabled Menu Level IDE Prefetch Mode Enabled Primary Master PIO Auto Primary Slave PIO Auto Secondary Master PIO Auto...

  • Page 73: Via Onchip Pci Device

    Chapter 4 BIOS Setup * Primary Ultra DMA33/66/100 implementation is possible only Master / Slave UDMA if your IDE hard drive supports it, if the operating Secondary environment includes a DMA drive, and if your sys- Master / Slave UDMA tem software both support Ultra DMA33/66/100.
  • Page 74 75DRV/75DRV-X VIA SUPERIO DEVICE CMOS Setup Utility - Copyright (C) 1984-2001 Award Software VIA SuperIO Device Item Help Onboard FDC Controller Enabled Onboard Serial Port 1 3F8/IRQ4 Menu Level Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal UR2 Duplex Mode Half Onboard Parallel Port 378/IRQ7...
  • Page 75 Chapter 4 BIOS Setup * UR2 Duplex Mode This item allows you to select the IR half / full duplex function. The choices: Half; Full. * Onboard Parallel Port This item allows you to determine onboard parallel port controller I/O address setting. The choices: 378H/IRQ7;...
  • Page 76 75DRV/75DRV-X USB Keyboard Sup- Select Enabled if your system contains a Universal port Serial Bus (USB) controller and you have a USB keyboard. IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/write per sector the...

  • Page 77: 4-6.6 Power Management Setup

    Chapter 4 BIOS Setup 4-6.6 POWER MANAGEMENT SETUP • POWER MANAGEMENT SETUP allows you to set the system’s power saving functions. Run the POWER MANAGEMENT SETUP as follows: 1. Choose “POWER MANAGEMENT SETUP” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Power Management Setup Item Help...
  • Page 78 75DRV/75DRV-X ACPI Function Select Enabled only if your computer’s operating system supports the Advanced Configuration and Power Interface (ACPI) specification. Currently, Windows NT 5.0 support ACPI. ACPI Suspend Type This item allows you to select the ACPI suspend type. You can select S3(STR) for suspending to DRAM or S1(POS) for power on suspend under Windows 98 ACPI mode.
  • Page 79 Chapter 4 BIOS Setup Monitor will remain on during power saving Always On modes. Monitor blanked when the systems enters the Suspend -->Off Suspend mode. Monitor blanked when the system enters either All Modes -->Off Suspend or Standby modes. Video Off Method This determines the manner by which the monitor is blanked.
  • Page 80 75DRV/75DRV-X IRQ/EVENT ACTIVITY DETECT CMOS Setup Utility - Copyright (C) 1984-2001 Award Software IRQ/Event Activity Detect Item Help Disabled USB Resume from S3 Menu Level LPT/COM LPT & COM HDD & FDD PCI Master Disabled PowerOn by PCI Card Disabled Wake Up On LAN/Ring Disabled RTC Alarm Resume...
  • Page 81 Chapter 4 BIOS Setup * PowerOn by PCI Card This item allows system wake up by PCI Device. * Wake Up On LAN/ An input signal on the serial Ring Indicator (RI) line Ring (in other words, an incoming call on the modem) awakens the system from a soft off state.
  • Page 82 75DRV/75DRV-X * IRQ ACTIVITY MONITORING CMOS Setup Utility - Copyright (C) 1984-2001 Award Software IRQ Activity Monitoring Primary INTR Item Help IRQ-3 (COM2) Enabled Menu Level IRQ-4 (COM1) Enabled IRQ-5 (LPT2) Enabled IRQ-6 (Floppy Disk) Enabled IRQ-7 (LPT1) Enabled IRQ-8 (RTC Alarm) Disabled IRQ-9 (IRQ2 Redir) Disabled...

  • Page 83: 4-6.7 Pnp / Pci Configuration

    Chapter 4 BIOS Setup 4-6.7 PNP / PCI CONFIGURATION • PNP/PCI CONFIGURATION allows you to modify the system’s power saving functions. Run the PNP/PCI CONFIGURATION as follows: 1. Choose “PNP/PCI CONFIGURATION” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software PnP/PCI Configurations Item Help...
  • Page 84 75DRV/75DRV-X PNP OS Installed Select Yes if the system operating environment is Plug-and-Play aware (e.g., Windows95). NOTE: BIOS will automatically disable all PnP resources except the boot device card when you select Yes on Non-PnP operating system. Reset Configuration Normally, you leave this Disabled. Select Enabled Data to reset Extended System Configuration Data (ESCD), when you exit Setup if you have installed...
  • Page 85 Chapter 4 BIOS Setup PCI SLOT1/5, 2, 3, 4 These options allow you to assign an IRQ for each IRQ Assigned PCI SLOT and this is a useful function when you want to clear the IRQ conflict for a specific device. The options are available : Auto;...

  • Page 86: 4-6.8 Smartdoc Anti-Burn Shield

    75DRV/75DRV-X 4-6.8 SMARTDOC ANTI-BURN SHIELD • This section helps you to get more information about your system including CPU temperature, FAN speed and voltage. It is recommended that you contact with your mainboard supplier to get proper values about the setting of the CPU temperature.
  • Page 87 Chapter 4 BIOS Setup Shutdown Tempera- This feature prevents your CPU from damage by ture over heat. If the CPU’s temperature is higher than “CPU warning temperature” that you select in this field, the BIOS will shut down your system within 3 seconds.

  • Page 88: 4-6.9 Frequency/Voltage Control

    75DRV/75DRV-X 4-6.9 FREQUENCY/VOLTAGE CONTROL Run the “FREQUENCY/VOLTAGE CONTROL” as following: 1. Choose “FREQUENCY/VOLTAGE CONTROL” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Frequency/Voltage Control Press Enter Item Help Red Storm Overclocking Default...
  • Page 89 Chapter 4 BIOS Setup Redstorm Please press <Enter> to start RED STORM OVER- Overclocking CLOCKING TECH, this option helps user an easy Tech way to overclocking, it will increase CPU external clock automatically, when CPU external clock in- creasing to unacceptable value, BIOS will restart your system, then running at acceptable CPU ex- ternal clock.
  • Page 90 75DRV/75DRV-X Use CPU Linear If users would like to adjust CPU clock, this items Freq must be “Linear”. The choices: Default; Linear. CPU Clock These items allows users to adjust CPU frequency. 3. Press <ESC> to return to the Main Menu when you finish setting up all items.

  • Page 91: 4-6.10 Load Optimized Defaults

    Chapter 4 BIOS Setup 4-6.10 LOAD OPTIMIZED DEFAULTS • When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y / N) ? N ” Pressing “Y” loads the BIOS default values that are factor settings for opti- mal performance of system operations.

  • Page 92: 4-6.12 Save & Exit Setup

    75DRV/75DRV-X 7. Move the cursor to Save & Exit Setup to save the option you have just configured; otherwise the old password will still be there the next time you turn your system on. 8. Press <Enter> to exit to the Main Menu. NOTE: If you forget or lose the password, the only way to access the system is to clear the CMOS RAM.
  • Page 93 Chapter 4 BIOS Setup MEMO MEMO...

  • Page 94: Appendices

    75DRV75DRV-X APPENDICES APPENDIX-1 TECHNICAL TERMS APPENDIX-2 IDENTIFYING BIOS VERSION/ BIOS PART NUMBER APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER...

  • Page 95: Appendix-1 Technical Terms

    APPENDIX APPENDIX-1 TECHNICAL TERMS Technical Terms Introduction Tech Term Meaning Accelerated Graphic Port Audio Modem Riser Advanced Communication Riser Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface DIMM Dual Inline Memory Module DRAM...

  • Page 96: Appendix-2 Identifying Bios Version And Bios

    75DRV75DRV-X APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS PART NUMBER • When you boot up your computer, you may see a screen which shows your computer is phoenixnet™ enabled. Please see Picture-1 below for an illustration. • When the screen shows up press “Tab” key for BIOS information. Picture-1...
  • Page 97 APPENDIX • See Picture-2 below for BIOS version and BIOS part number identification. Picture-2 BIOS VERSION example: REV T2.1 BIOS ID STRING example: 6A69RSNCC...

  • Page 98: Appendix-3 Identifying Mainboard Model Number

    75DRV75DRV-X APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER • Usually the mainboard model number is labeled on the side of ISA side of slot or PCI slot. Please see the picture below as an illustration: MAINBOARD MODEL NUMBER example: SL-65KV2 MAINBOARD SERIAL NUMBER example: 0012000T005679...
  • Page 99 APPENDIX...
