SOLTEK SL-75LIV User Manual

V1.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
T h e
S o u l
O f
C o m p u t e r
T e c h n o l o g y
SL-75LIV
USER MANUAL v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-75LIV and is the answer not in the manual?

Questions and answers

Related Manuals for SOLTEK SL-75LIV

Summary of Contents for SOLTEK SL-75LIV

  • Page 1 T h e S o u l C o m p u t e r T e c h n o l o g y SL-75LIV USER MANUAL v1.0...
  • Page 2 Soltek Computer Inc. has been advised of the possibility of such damages arising from any defect or error in this manual or product.

  • Page 3: Soltek Computer Inc

    SOLTEK AROUND THE WORLD SOLTEK COMPUTER INC. Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei- Hsien, Taiwan, R.O.C. Telephone : 886-2-2642-9060 : 886-2-2642-9065 E-mail : sales@soltek.com.tw Web site : http://www.soltek.com.tw SOUL TECHNOLOGY EUROPE B.V. Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-...

  • Page 4: Table Of Contents

    75LIV C O N T E N T CHAPTER 1 INTRODUCTION ..........8 1-1 MAINBOARD SPECIFICATION ..........9 1-1.1 PROCESSOR ............... 9 1-1.2 CHIPSET ................9 1-1.3 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER 9 1-1.4 INTEGRATED HIGH PERFORMANCE 2D/3D GRAPHICS . 9 CONTROLLER ..............
  • Page 5 2-6 CONNECTORS CONFIGURATIONS ........25 2-6.1 On Board FAN Connector (FAN1, FAN2, FAN3) ....25 2-6.2 WOL1 Wake On LAN ............26 2-6.3 CD-ROM Audio Connector (CD_IN1/CD_IN2) ....26 2-6.4 Complex Header NJP1 ............27 2-6.5 Chassis Panel Connector ..........28 2-6.6 ATX Power Supply Connector ..........
  • Page 6 75LIV 4-6 BIOS SETUP --- CMOS SETUP UTILITY ......... 48 4-6.1 CMOS SETUP UTILITY ............48 4-6.2 STANDARD CMOS SETUP ..........49 4-6.3 ADVANCED BIOS FEATURES ........... 52 4-6.4 ADVANCED CHIPSET FEATURES ........57 4-6.5 INTEGRATED PERIPHERALS ........... 63 4-6.6 POWER MANAGEMENT SETUP ........68 4-6.7 PNP / PCI CONFIGURATION ..........
  • Page 7 ITEMLIST CHECKUP Mainboard Support CD User’s Manual Bundled Bonus Pack CD Bundled Bonus Pack Manual ATA66/100 IDE Cable RS232 Cable FDD Cable...

  • Page 8: Chapter 1 Introduction

    75LIV CHAPTER INTRODUCTION • This chapter briefly introduces the characteristics of this mainboard. It includes the information regarding the chipset, CPU types, built-in functions and layout. Users will have more ideas about mainboards after reading this chapter. This chapter contains the following topics : 1-1 MAINBOARD SPECIFICATION 1-2 MAINBOARD LAYOUT 1-3 CHIPSET DIAGRAM...

  • Page 9: Mainboard Specification

    Chapter 1 Introduction 1-1 MAINBOARD SPECIFICATION 1-1.1 PROCESSOR • Supporting AMD Athlon Thunderbird processors up to 1.5GHz. • Supporting AMD Athlon Duron processors up to 1.2GHz. • Supporting processor VID (voltage ID) and FID (frequency ID) auto detection. • Supporting AMD Athlon processor with 200 and 266MHz Front Side bus.

  • Page 10: 1-1.6 Sound Controller

    75LIV 1-1.6 SOUND CONTROLLER • SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio Controller with Codec onboard. 1-1.7 MULTI-I/O FUNCTION • Two Ultra DMA 33/66/100 Master Mode PCI EIDE ports. • Two UART’s for Complete Serial Ports. • Dedicated IR connector: -- Third serial port dedicated to IR function either through the two complete serial ports or the third dedicated port Infrared-IrDA (HPSIR) and ASK (Amplitude Shift Keyed) IR.

  • Page 11: 1-1.10 Expansion Slots

    Chapter 1 Introduction 1-1.10 EXPANSION SLOTS • Three PCI bus Master slots. • One ISA slot. • Three DIMM slots. 1-1.11 FORM FACTOR • ATX form factor 4-layer PCB. • Mainboard size: 24.5cm x 21.0cm. 1-1.12 OTHERS • Clock generator supporting 1 MHz linear clock setting.

  • Page 12: Motherboard Layout

    75LIV 1-2 MOTHERBOARD LAYOUT --- 75LIV • Default Setting: 100MHz CPU External clock. FAN1 Clock Generator SOCKET 462 VT8361 FAN2 PCI 1 Battery AC'97 Codec PCI 2 WOL1 VT82C PCI 3 686B USB2 Using non-compliant memory with higher bus clock (over-clocking) may severely compromise the reliability of system.

  • Page 13: Chapter 1 Introduction

    Chapter 1 Introduction 1-3 CHIPSET DIAGRAM--- 75LIV • The KLE-133 / VT82C686B chipset is a high performance, cost-effective and energy efficient system controller for the implementation of AGP / PCI / ISA desktop personal computer system based on 64-bit Socket-A (AMD Athlon) processors.
  • Page 14 75LIV MEMO MEMO...

  • Page 15: Chapter 2 Hardware Setup

    Chapter 2 Hardware Setup CHAPTER HARDWARE SETUP ATTENTION !!! 1. Please refer to your processor installation or other documentation attached to your CPU for more detailed installing instruction. 2. Installing a heat sink and cooling fan is necessary for proper heat dissipation from your CPU. Incorrect installation may result in overheating and damage of your CPU.

  • Page 16: Cpu Installation

    75LIV 2-1 CPU INSTALLATION WARNING !!! • Make sure that +5V DCV and +3.3 DCV capabilities of your power supply are suitable for the processor. • Any attempt to operate the AMD Athlon or Duron processor without a suitable cooling Fan will damage processor and other component. Pull out the lever from the socket, and then raise the lever up to a 90-degree angle.

  • Page 17: Memory Installation

    Chapter 2 Hardware Setup 2-2 MEMORY INSTALLATION WARNING!!! • Make sure to unplug your power supply before adding or removing memory modules or other system components. Failure to do so may cause severe damage to both your mainboard and expansion cards. •...

  • Page 18: Hdd/Fdd Installation

    75LIV 2-3 HDD/FDD INSTALLATION • To install HDD (Hard Disk Drive), you may connect the cable’s blue connector to the mainboard’s primary (IDE1) or secondary (IDE2) connector, and then connect the gray connector to your slave device and the black connector to your master device.
  • Page 19 Chapter 2 Hardware Setup • To install FDD (Floppy Disk Drive), you may connect the end with single connector to the board , and connect the other end with two plugs to the floppy drives. FAN1 Clock Generator SOCKET 462 VT8361 FAN2 PCI 1...

  • Page 20: Switch Setting For Cpu Frequency And Voltage

    75LIV 2-4 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE 2-4.1 Information On AMD Socket 462 Processor • On the AMD Socket 462 Processor, you can find a codified identification marking which is to provide useful information about the CPU. The marking is interpreted as below: XXXXXXXXXXX XXXXXXXXXXXX...

  • Page 21: 2-4.2 Cpu External Frequency Setting (By Sw1)

    Chapter 2 Hardware Setup 2-4.2 CPU External Frequency Setting (By SW1) CPU EXTERNAL FREQUENCY FREQUENCY FREQUENCY 100MHz 33.3MHz 200MHz (Default) 34.3MHz 206MHz 103MHz 35.0MHz 210MHz 105MHz 36.7MHz 220MHz 110MHz 112MHz 37.3MHz 224MHz 38.3MHz 230MHz 115MHz 120MHz 40.0MHz 240MHz 31.0MHz 248MHz 124MHz 133.3MHz 33.3MHz...

  • Page 22: 2-4.3 Processor Core Voltage Select (By Sw2 Dip1-Dip6)

    75LIV 2-4.3 Processor Core Voltage Select (By SW2 DIP1-DIP6) • DIP1-DIP6 SW2 allow you to adjust processor core voltage manually. We recommend to leave SW2 DIP1 at default, the default means the correct processor core voltage is generated according to VID of CPU. SW2 DIP2 ~ DIP6 SETTING SW2 DIP1 0.0v...

  • Page 23: 2-4.4 Frequency Ratio Select (By Sw3 Dip1-Dip4)

    Chapter 2 Hardware Setup 2-4.4 Frequency Ratio Select (By SW3 DIP1-DIP4) • The AMD Athlon and Duron processors provides four Frequency ID signals (DIP1-DIP4) (FID) for the system controller to indicate the SYSTCLK multiplier at which the processor core operates. Normally, multiplier (or bus ratio) is detected automatically.

  • Page 24: Jumper Setting For Devices On Board

    75LIV 2-5 JUMPER SETTING FOR DEVICES ON BOARD • The following diagrams show the locations of jumper blocks on the mainboard. CAUTION • Do not remove the jumper when power is on. Always make sure the power is off before changing any jumpers. Otherwise, mainboard could be damaged..

  • Page 25: Connectors Configurations

    Chapter 2 Hardware Setup 2-6 CONNECTORS CONFIGURATIONS • This section lists out all connectors configurations for users’ reference. 2-6.1 On Board FAN Connector (FAN1, FAN2, FAN3) FAN1 Clock On Board FAN Connector Generator (FAN1): SOCKET 462 On Board FAN Connector (FAN2): On Board FAN Connector VT8361...

  • Page 26: 2-6.2 Wol1 Wake On Lan

    75LIV 2-6.2 WOL1 Wake On LAN FAN1 Clock Generator +5V standby SOCKET 462 Wake On LAN: VT8361 FAN2 Connect the Wake On PCI 1 LAN signal from LAN Battery AC'97 Codec WOL1 card to WOL1 PCI 2 WOL1 VT82C PCI 3 686B USB2 This connector is connected to the LAN card with a Wake On LAN output.

  • Page 27: 2-6.4 Complex Header Njp1

    Chapter 2 Hardware Setup 2-6.4 Complex Header NJP1 • This complex Header consists of 8 connectors providing various supports: NJP1 NO CONNECTION NO CONNECTION SUSPEND LED NO CONNECTION SUSPEND LED SIGNAL POWER SWITCH ATX POWER SWITCH NO CONNECTION NO CONNECTION NO CONNECTION POWER LED NO CONNECTION...

  • Page 28: 2-6.5 Chassis Panel Connector

    75LIV 6. Reset Switch Connector: CONNECTION: Connected to the case-mounted “Reset Switch”. FUNCTION: To supply power to “Reset Switch” and support system reboot function. 7. Speaker Connector: CONNECTION: Connected to the case-mounted Speaker. FUNCTION: To supply power to the case-mounted Speaker. 2-6.5 Chassis Panel Connector A : PS/2 MOUSE PORT B : USB 0 PORT...

  • Page 29: 2-6.6 Atx Power Supply Connector

    Chapter 2 Hardware Setup 2-6.6 ATX Power Supply Connector • This connector connects to an ATX power supply. The plug from the power supply should only be inserted to ATX Power connector in a specific orientation. Find the proper orientation and push it down firmly to make sure that all pins are aligned.

  • Page 30: 2-6.8 Serial Ports

    75LIV 2-6.8 Serial Ports • One serial port COM 1 is ready for a mouse or other serial devices. A second serial port is available in the form of a 9-pin Header (COM2) to provide connection to a second serial device by an RS232 cable. FAN1 COM 2 Header Clock...

  • Page 31: 2-6.9 Usb2 Header

    Chapter 2 Hardware Setup 2-6.9 USB2 Header • This header is for connecting the additional USB cable to provide you two additional USB ports. User can order the additional USB cable from your mainboard dealer and vender. Additional USB Cable (Optional) red wire Black Black...

  • Page 32: Irq Description

    75LIV 2-7 IRQ DESCRIPTION Function Description Priority IRQ 0 System Timer IRQ 1 Keyboard Controller IRQ 2 Programmable Interrupt IRQ 3 Serial Port (COM 2) IRQ 4 Serial Port (COM 1) IRQ 5 IRQ 6 Floppy Disk Controller IRQ 7 Parallel Port (LPT1) IRQ 8 Real Time Clock (RTC)
  • Page 33 Chapter 2 Hardware Setup MEMO MEMO...

  • Page 34: Chapter 3 Software Setup

    75LIV CHAPTER SOFTWARE SETUP ABOUT SUPPORT CD • In Support CD, it contains most informations for user’s requirement, such as Acrobat Reader, BIOS, User’s full version Manual, Driver, Hardware Monitor (if mainboard supports this function), Patch, and Utilities etc. User can browse the CD and get further details in regard of our mainboard.

  • Page 35: Via Chipset Driver Installation (4-In-1 Driver)

    Chapter 3 Software Setup 3-1 VIA CHIPSET DRIVER INSTALLATION (4-IN-1 DRIVER) • Please put the Support CD • When a welcome window provided in your mainboard appears on the screen, package into the CD-ROM users should choose “Install drive. Driver”. •...
  • Page 36 75LIV • Press select the checkbox as below: Bus Master PCI IDE Driver AGP VxD Driver VIA Chipset Function’s Registry IRQ Routing Miniport Driver Next Note : For user who is upgrading VIA Drivers, we recommend to install the 4-in-1 as it will automatically detect and update the necessary drivers. •...
  • Page 37 Chapter 3 Software Setup • Select “Install VIA AGP Vx Next D” in turbo mode and press Next button to continue. • Select “Install VIA IRQ Next Routing Miniport Driver” checkbox, then click the “Next” button to continue. • After all these setup pro- Finish cedures have finished, lease restart your computer by...

  • Page 38: Onboard Vga Driver Installation

    75LIV 3-2 ONBOARD VGA DRIVER INSTALLATION • We provide a simple process for user to install VGA driver. Whichever Microsoft Windows operating system user adopts, they have similar installation below. 3-2.1 Install KLE133 VGA Driver For Windows 95/98/SE • Please put the Support CD •...

  • Page 39: 3-2.3 Install Kle133 Vga Driver For Windows Me

    Chapter 3 Software Setup 3-2.3 Install KLE133 VGA Driver For Windows ME • Please put the Support CD • When a welcome window provided in your mainboard appears on the screen, package into the CD-ROM users should choose “Install drive. Driver”.

  • Page 40: Ac'97 Audio Codec Installation

    75LIV 3-3 AC’97 AUDIO CODEC INSTALLATION • Please put the Support CD • When a welcome window provided in your mainboard appears on the screen, package into the CD-ROM users should choose “Install drive. Driver”. • Click on the “VIA Chipset •...
  • Page 41 Chapter 3 Software Setup MEMO MEMO...

  • Page 42: Chapter 4 Bios Setup

    75LIV CHAPTER BIOS SETUP THE BIOS • BIOS stands for Basic Input and Output System. It is sometimes called ROM BIOS because it is stored in a Read-Only Memory(ROM) chip on the mainboard. BIOS is the first program to run when you turn on your computer.

  • Page 43: What Is Bios Setup

    Chapter 4 BIOS Setup 4-1 WHAT IS BIOS SETUP • BIOS setup is an interactive BIOS program that you need to run when: 1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.) 2. Modifying the behavior of your computer. (For example: changing the system time or date, or turning special features on or off etc.) 3.

  • Page 44: 4-5.1 Before Upgrading Bios

    75LIV • The upgrade utility can be loaded on a floppy diskette and used to provide the capability to save, verify, and update the system BIOS. The upgrade utility can be run from a hard disk drive or a network drive. 4-5.1 Before Upgrading BIOS •...
  • Page 45 Chapter 4 BIOS Setup Step 4. Type awdflash *.bin /sn/py/cc and then press <Enter> to run BIOS upgrade program. (*.bin depends on your mainboard model and version code. Instead of typing “*”, you should type specific file name for your specific mainboard).
  • Page 46 75LIV Figure 1 : Award Flash Memory Writer Start Screen Figure 2 : Award Flash Memory Writer Start Screen...
  • Page 47 Chapter 4 BIOS Setup The parameters of AWDFLASH.EXE /sn: No original BIOS backup /py: Program flash memory /cc: Clear CMOS and update data auto matically after programming /r : Reset system after programming NOTE: User can type AWDFLASH /? to get further details about parameters. Wrong usage of parameter will damage the BIOS information, so that we strongly recommend user to leave parameters alone unless you realize their function.

  • Page 48: Bios Setup

    75LIV 4-6 BIOS SETUP --- CMOS SETUP UTILITY 4-6.1 CMOS SETUP UTILITY • This mainboard comes with the AWARD BIOS from AWARD Software Inc. Enter the CMOS Setup Utility Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 49: 4-6.2 Standard Cmos Setup

    Chapter 4 BIOS Setup 4-6.2 STANDARD CMOS SETUP • Standard CMOS Setup records some basic system hardware configuration and sets the system clock and error handling. You only need to modify the configuration values of this option if you want to change your system hardware configuration or when the data stored in the CMOS memory gets lost or damaged.
  • Page 50 75LIV Date (mm:dd:yy) The BIOS determines the day of the week from the other date information. This field is for information only. Press the left or right arrow key to move to the desired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the de- sired value into the field.
  • Page 51 Chapter 4 BIOS Setup Drive A / Drive B Select this field to the type(s) of floppy disk drive(s) installed in your system. The choices are: 360KB, 5.25in; 1.2MB, 5.25in; 720KB, 3.5in; 1.44MB, 3.5in; 2.88MB, 3.5in; None. Video Select the type of primary video subsystem in your computer.

  • Page 52: 4-6.3 Advanced Bios Features

    75LIV 4-6.3 ADVANCED BIOS FEATURES • ADVANCED BIOS FEATURES improves your system performance or sets up system features according to your preference. Run the ADVANCED BIOS FEATURES as follows: 1. Choose “ADVANCED BIOS FEATURES” from the Main Menu and a screen with a list of options will appear: 2.
  • Page 53 Chapter 4 BIOS Setup CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced BIOS Features Item Help Virus Warning Disabled Menu Level CPU Internal Cache Enabled External Cache Enabled CPU L2 Cache ECC Checking Enabled Quick Power On Self Test Enabled First Boot Device Floppy...
  • Page 54 75LIV Virus Warning When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an antivirus program. Keep in mind that this feature protects only the boot sector, not the entire hard drive.
  • Page 55 Chapter 4 BIOS Setup Boot Up Floppy Seek When enabled, the BIOS tests (seeks) floppy drives to determine whether they have 40 or 80 tracks. Only 360-KB floppy drives have 40 tracks; drives with 270KB, 1.2MB, and 1.44MB capacity all have 80 tracks.
  • Page 56 75LIV Security Option If you have set a password, select whether the password is required every time the System boots, or only when you enter setup. The choices: system; setup. OS Select For DRAM > Select OS2 only if you are running OS/2 operating 64MB system with greater than 64MB of RAM on your system.

  • Page 57: 4-6.4 Advanced Chipset Features

    Chapter 4 BIOS Setup 4-6.4 ADVANCED CHIPSET FEATURES • ADVANCED CHIPSET FEATURES is used to modify the values of chipset buffers. These buffers control the system options. Run the ADVANCED CHIPSET FEATURES as follows: 1. Choose “ADVANCED CHIPSET FEATURES” from the Main Menu and a list of option will appear: 2.
  • Page 58 75LIV CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced Chipset Features Item Help DRAM Timing By SPD Enabled DRAM Clock 133M Menu Level SDRAM Cycle Length Bank Interleave Disabled DRAM Drive Strength Auto DRAM Drive Value Memory Hole Disabled PCI Master Pipeline Req Enabled...
  • Page 59 Chapter 4 BIOS Setup DRAM Timing by SPD When this item Enabled, DRAM Timing is set by SPD SPD (Serial Presence Detect) is located on the memory modules, BIOS reads information coded in SPD during system boot up. DRAM Clock The value represents the performance parameters of the installed memory chips (DRAM).
  • Page 60 75LIV P2C/C2P Concurrency This item allows you to enable/disable the PCI to CPU, CPU to PCI concurrency. The choices: Enabled; Disabled. Fast R-W Turn Around This item controls the DRAM timing. It allows you to enable / disable the fast read / write turn around. The choices: Enabled;...
  • Page 61 Chapter 4 BIOS Setup AGP Fast Write This item will enable the AGP model into fast write mode. If your graphics card does not support this function, please do not enable this function. OnChip USB/USB2 This should be enabled if our system has a USB installed on the system board and you wish to use it.
  • Page 62 75LIV PCI Master 0 WS Write When Enabled, writes to the PCI bus are executed with zero wait states. The choices: Enabled; Disabled. Memory Parity/ECC This item enabled to detect the memory parity and Check Error Checking & Correcting. The choices: Enabled; Disabled. PCI Delay Transaction Leave this field at default PCI #2 Access #1 Retry Leave this field at default AGP Master 1 ws write Leave this field at default...

  • Page 63: 4-6.5 Integrated Peripherals

    Chapter 4 BIOS Setup 4-6.5 INTEGRATED PERIPHERALS • INTEGRATED PERIPHERALS option allows you to get some information inside your system when it is working. Run the INTEGRATED PERIPHERALS as follows: 1. Choose “INTEGRATED PERIPHERALS” from the Main Menu and a list of options will appear: 2.
  • Page 64 75LIV CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Integrated Peripherals Item Help On-Chip IDE Channel0 Enabled On-Chip IDE Channel1 Enabled Menu Level IDE Prefetch Mode Enabled Primary Master PIO Auto Primary Slave PIO Auto Secondary Master PIO Auto Secondary Slave PIO Auto Primary Master UDMA...
  • Page 65 Chapter 4 BIOS Setup On-Chip IDE channel The chipset contains a PCI IDE interface with support from two IDE channels. Select Enabled to activate the first and/or the second IDE interface. Select Disabled to inactivate an interface if you install a primary and/or second add-on IDE interface.
  • Page 66 75LIV Onboard FDC Select Enabled if your system has a floppy drive Controller controller (FDC) installing in the system board and you want to use it. If you install add-in FDC or the system has no floppy drive, select Disabled in this field.
  • Page 67 Chapter 4 BIOS Setup ECP Mode Use DMA Select a DMA channel for the port. Parallel Port EPP Type Select EPP port type 1.7 or 1.9 The choice: EPP1.7, 1.9. Onboard Legacy Audio This field controls the onboard audio. • Sound Blaster •...

  • Page 68: 4-6.6 Power Management Setup

    75LIV 4-6.6 POWER MANAGEMENT SETUP • POWER MANAGEMENT SETUP allows you to set the system’s power saving functions. Run the POWER MANAGEMENT SETUP as follows: 1. Choose “POWER MANAGEMENT SETUP” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Power Management Setup ACPI Function...
  • Page 69 Chapter 4 BIOS Setup ACPI Function Select Enabled only if your computer’s operating system supports the Advanced Configuration and Power Interface (ACPI) specification. Power Management • When this option is chosen, the following item appears for user’s configuration. CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Power Management Power Management User Define...
  • Page 70 75LIV * HDD Power Down When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active. * Doze Mode When enabled and after the set time of system inactivity, the CPU clock will run at slower speed while all other devices still operate at full speed.
  • Page 71 Chapter 4 BIOS Setup Video Off Method This determines the manner by which the monitor is blanked. This selection will cause the system to turn off the vertical V/H SYNC + and horizontal synchronization ports and write blanks to Blank the video buffer.
  • Page 72 75LIV Wake Up Events • When this option is chosen, the following item appears for user’s configuration. CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Wake Up Events Item Help LPT & COM LPT/COM Menu Level HDD & FDD PCI Master Wake Up On LAN/Ring Disabled...
  • Page 73 Chapter 4 BIOS Setup * Wake Up On LAN/ An input signal on the serial Ring Indicator (RI) line Ring (in other words, an incoming call on the modem) awakens the system from a soft off state. The choices: Enabled; Disabled. * RTC Alarm Resume When Enabled, you can set the data and time at which the RTC (Real Time Clock) alarm awakens the system from suspend mode.
  • Page 74 75LIV...

  • Page 75: 4-6.7 Pnp / Pci Configuration

    Chapter 4 BIOS Setup 4-6.7 PNP / PCI CONFIGURATION • PNP/PCI CONFIGURATION allows you to modify the system’s power saving functions. Run the PNP/PCI CONFIGURATION as follows: 1. Choose “PNP/PCI CONFIGURATION” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software PnP/PCI Configurations PNP OS Installed...
  • Page 76 75LIV PNP OS Installed Select Yes if the system operating environment is Plug-and-Play aware (e.g., Windows95). NOTE: BIOS will automatically disable all PnP resources except the boot device card when you select Yes on Non-PnP operating system. Reset Configuration Normally, you leave this Disabled. Select Enabled Data to reset Extended System Configuration Data (ESCD), when you exit Setup if you have installed...
  • Page 77 Chapter 4 BIOS Setup DMA Resources Press Enter. Please refer to the list below: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software DMA Resources DMA-0 assigned to PCI/ISA PnP Item Help DMA-1 assigned to PCI/ISA PnP Menu Level DMA-3 assigned to PCI/ISA PnP DMA-5 assigned to PCI/ISA PnP...

  • Page 78: 4-6.8 Smartdoc Anti-Burn Shield

    75LIV 4-6.8 SMARTDOC ANTI-BURN SHIELD • This section helps you to get more information about your system including CPU temperature, FAN speed and voltage. It is recommended that you contact with your mainboard supplier to get proper values about the setting of the CPU temperature.
  • Page 79 Chapter 4 BIOS Setup CPUFan Warning This feature prevents the misfunction of the CPU Speed cooling fan. When CPU cooling fan speed lower than value you selected in this field, the BIOS will send out sequence of beeps sound or send out a warning message “Your CPU FAN speed is too slow”.

  • Page 80: 4-6.9 Frequency/Voltage Control

    75LIV 4-6.9 FREQUENCY/VOLTAGE CONTROL Run the “FREQUENCY/VOLTAGE CONTROL” as following: 1. Choose “FREQUENCY/VOLTAGE CONTROL” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Frequency Control Item Help Redstorm Overclocking Tech Press Enter Auto Detect DIMM/PCI Clk...
  • Page 81 Chapter 4 BIOS Setup RedStorm Press “Enter” to execute this function, by which BIOS Overclocking Tech will detect1 CPU Frequency, until the unacceptable one is reached. BIOS will then stop and reboot automatically with the optimal CPU Frequency. If system does not reboot after Frequency detection, user should reboot system manually.

  • Page 82: 4-6.10 Load Optimized Defaults

    75LIV 4-6.10 LOAD OPTIMIZED DEFAULTS • When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y/N) ? N ” “Y” is for “Yes”, and “N” is for “No”. Pressing “Y”...

  • Page 83: 4-6.11 Set Supervisor / User Password

    Chapter 4 BIOS Setup 4-6.11 SET SUPERVISOR / USER PASSWORD • These two options allow you to set your system passwords. Normally, the supervisor has a higher priority to change the CMOS setup option than the users. The way to set up the passwords for both Supervisor and Users are as follows: 1.

  • Page 84: 4-6.12 Save & Exit Setup

    75LIV 4-6.12 SAVE & EXIT SETUP • SAVE & EXIT SETUP allows you to save all modifications you have specified into the CMOS memory. Highlight this option on the Main Menu and the following message appears: “ SAVE to CMOS and EXIT (Y/N) ? Y “ “Y”...
  • Page 85 Chapter 4 BIOS Setup MEMO MEMO...

  • Page 86: Appendices

    75LIV APPENDICES APPENDIX-1 TECHNICAL TERMS APPENDIX-2 IDENTIFYING BIOS VERSION/ BIOS PART NUMBER APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER...

  • Page 87: Appendix-1 Technical Terms

    Appendix APPENDIX-1 TECHNICAL TERMS Technical Terms Introduction Tech Term Meaning Accelerated Graphic Port Audio Modem Riser Advanced Communication Riser Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface DIMM Dual Inline Memory Module DRAM...

  • Page 88: Appendix-2 Identifying Bios Version And Bios Part Number

    75LIV APPENDIX-2 IDENTIFYING BIOS VERSION AND BIOS PART NUMBER • When you boot up your computer, you may see a screen which shows your computer is phoenixnet™ enabled. Please see Picture-1 below for an illustration. • When the screen shows up press “Tab” key for BIOS information. Picture-1...
  • Page 89 Appendix • See Picture-2 below for BIOS version and BIOS part number identification. Picture-2 BIOS VERSION example: REV T2.1 BIOS ID STRING example: 6A69RSNCC...

  • Page 90: Appendix-3 Identifying Mainboard Model Number

    75LIV APPENDIX-3 IDENTIFYING MAINBOARD MODEL NUMBER • Usually the mainboard model number is labeled on the side of ISA or PCI slot. Please see the picture below for an illustration: MAINBOARD MODEL NUMBER example: SL-65KV2 MAINBOARD SERIAL NUMBER example: 0012000T005679...
  • Page 91 Appendix MEMO MEMO...
