SOLTEK SL-75ERV User Manual

Mainboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

R
T h e
S o u l
O f
C o m p u t e r
T e c h n o l o g y
Mainboard
SL-75ERV
User Manual V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-75ERV and is the answer not in the manual?

Questions and answers

Related Manuals for SOLTEK SL-75ERV

Summary of Contents for SOLTEK SL-75ERV

  • Page 1 T h e S o u l C o m p u t e r T e c h n o l o g y Mainboard SL-75ERV User Manual V1.1...
  • Page 2 Every effort has been made to ensure that the information in this manual is accurate. Soltek Computer Inc. is not responsible for printing or clerical errors. Information in this document is subject to change without notice and does not represent a commitment on the part of Soltek Computer Inc.

  • Page 3: Soltek Computer Inc

    SOLTEK AROUND THE WORLD SOLTEK COMPUTER INC. Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei- Hsien, Taiwan, R.O.C. Telephone : 886-2-2642-9060 : 886-2-2642-9065 E-mail : sales@soltek.com.tw Web site : http://www.soltek.com.tw SOUL TECHNOLOGY EUROPE B.V. Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-...

  • Page 4: Table Of Contents

    75ERV CONTENT Chaper 1 Introduction ............. 8 1-1 Mainboard Specification ............9 1-1.1 Processor ..................9 1-1.2 Chipset ....................9 1-1.3 AWARD BIOS V6.0 Supporting ............9 1-1.4 Sound Controller ................9 1-1.5 Power Management ................9 1-1.6 Full Featured Accelerated Graphics Ports (AGP) Controller ... 10 1-1.7 Multi-I/O Function ................
  • Page 5 Content 2-5.2 JBAT1 For Clear CMOS Data ............26 2-6 Connectors Configurations ............27 2-6.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) ....27 2-6.2 WOL1 Wake On LAN ..............28 2-6.3 CD-ROM Audio Connector (JCD_IN1) ..........28 2-6.4 Complex Header CON1 ..............29 2-6.5 ATX Power Supply Connector ............
  • Page 6 75ERV 4-6.4 Advanced Chipset Features ............57 4-6.5 Integrated Peripherals ..............62 4-6.6 Power Management Setup .............. 68 4-6.7 PNP / PCI Configuration ..............74 4-6.8 SmartDOC Anti-Burn Shield ............77 4-6.9 Frequency/Voltage Control .............. 79 4-6.10 Load Optimized Defaults ............... 81 4-6.11 Set Supervisor / User Password ...........

  • Page 7: Item List Checkup

    Content ITEM LIST CHECKUP Mainboard ==== Support CD ==== User’s Manual ==== Bundled Bonus Pack CD ==== Bundled Bonus Pack Manual ==== Temperature Sensor Cable (Optional) ==== ATA66/100/133 IDE Cable ==== RS232 Cable FDD Cable...

  • Page 8: Chaper 1 Introduction

    75ERV Chaper Introduction • This chapter briefly introduces the characteristics of the mainboards. It includes the information regarding the chipset, CPU types, built-in functions and layout. Users will have more ideas about mainboards after reading this chapter. This chapter contains the following topics : 1-1 Mainboard Specification 1-2 Mainboard Layout 1-3 Chipset Diagram...

  • Page 9: Mainboard Specification

    Chapter 1 Introduction 1-1 Mainboard Specification 1-1.1 Processor • Supporting AMD Athlon™ Thunderbird processor up to 1.5GHz or above. • Supporting AMD Duron™ processor up to 1.2GHz or above. • Supporting 200MHz & 266MHz FSB bus. • Supporting Processor VID(voltage ID) and FID(Frequency ID) auto detection.

  • Page 10: 1-1.6 Full Featured Accelerated Graphics Ports (Agp) Controller

    75ERV 1-1.6 Full Featured Accelerated Graphics Ports (AGP) Controller • AGP v2.0 compliant. • Supports Side Band Addressing(SBA) mode (non-multiplexed address / data). • Supporting 66MHz 1x, 2x, and 4x modes for AD and SBA signaling. 1-1.7 Multi-I/O Function • Two UltraDMA-33/66/100/133 Master Mode PCI EIDE ports. •...

  • Page 11: 1-1.10 Form Factor

    Chapter 1 Introduction 1-1.10 Form Factor • ATX form factor, 4- layer PCB. • Mainboard size 22.0cm x 30.5cm. 1-1.11 Hareware Monitoring • Programmable control, status to provide, monitoring and alarm for flexible desktop management (software include). • 5 positive voltage statuses monitoring. •...

  • Page 12: Mainboard Layout

    75ERV 1-2 Mainboard Layout FAN1 SOCKET A VT8366A AGP 4X PCI 1 AC'97 JCD_IN1 PCI 2 Codec PCI 3 VT8233A JBAT1 LPC I/O PCI 4 Controller PCI 5 WOL1 PCI 6 CNR1 FAN4 USB3 Using non-compliant memory with higher bus clock (over clocking) may severely compromise the integrity of system.

  • Page 13: Chipset Diagram

    Chapter 1 Introduction 1-3 Chipset Diagram • The VT8366A and VT8233A chipset is a high performance, cost-effective and energy efficient system controller for the implementation of AGP / PCI / ISA desktop personal computer system based on 64-bit Socket-A (AMD Athlon) processors. SYSCLK, SYSCLK# Athlon INTR, NMI, SM#, STPCLK#,...
  • Page 14 75ERV MEMO MEMO...

  • Page 15: Chaper 2 Hardware Setup

    Chapter 2 Hardware Setup Chaper Hardware Setup ATTENTION !!! 1. Please refer to your processor installation or other documentation attached to your CPU for detailed in- stalling instruction. 2. Installing a heat sink and cooling fan is necessary for proper heat dissipation from your CPU. Incorrect installation may result in overheating and damage of your CPU.

  • Page 16: Cpu Installation

    75ERV 2-1 CPU Installation WARNING !!! • Make sure that +5V DCV and +3.3 DCV capabilities of your power supply are suitable for the processor. • Any attempt to operate the AMD Athlon or Duron processor without a suitable cooling Fan will damage processor and other component. Pull out the lever from the socket, and then raise the lever up to a 90-degree angle.

  • Page 17: Memory Installation

    Chapter 2 Hardware Setup 2-2 Memory Installation WARNING!!! • Make sure to unplug your power supply before adding or removing memory modules or other system components. Failure to do so may cause severe damage to both your mainboard and expansion cards. •...
  • Page 18 75ERV FAN1 SOCKET A VT8366A NOTICE: When LED “ZD1” is on, meaning that 2.5V is AGP 4X operating and flowing into DIMM slots, please do not PCI 1 add or remove memory AC'97 JCD_IN1 PCI 2 Codec modules . PCI 3 VT8233A JBAT1 LPC I/O...

  • Page 19: Hdd/Fdd Installation

    Chapter 2 Hardware Setup 2-3 HDD/FDD Installation • To install HDD (Hard Disk Drive), you may connect the cable’s blue con- nector to the mainboard’s primary (IDE1) or secondary (IDE2) connector, and then connect the gray connector to your slave device and the black connector to your master device.
  • Page 20 75ERV • To install FDD (Floppy Disk Drive), you may connect the single end to the board , and connect two plugs on the other end to the floppy drives. FAN1 SOCKET A VT8366A AGP 4X PCI 1 AC'97 JCD_IN1 PCI 2 Codec PCI 3...

  • Page 21: Switch Setting For Cpu Frequency And Voltage

    Chapter 2 Hardware Setup 2-4 Switch Setting For CPU Frequency And Voltage 2-4.1 Information On AMD Socket 462 Processor (Model 4, 5 Products) • On the AMD Socket 462 Processor, you can find a codified identification marking which is to provide useful information about the CPU. The marking is interpreted as below.

  • Page 22: 2-4.2 Information On Amd Socket 462 Processor (Model 6, 7 Products)

    75ERV 2-4.2 Information On AMD Socket 462 Processor (Model 6, 7 Products) XXXXXXXXXXX XXXXXXXXXXXX XXXXXXX XXXXXXXXX XXXXXXXXXXX XXXX AMD XXXX A HD 1533 HD 1533 A N S 3 C N S 3 C 4 5 6 7 8 Family/Architecture: A= AMD Athlon™XP Processor Model 6 Architecture.

  • Page 23: 2-4.3 Processor Core Voltage Select (By Sw1 Dip1-Dip6)

    Chapter 2 Hardware Setup 2-4.3 Processor Core Voltage Select (By SW1 DIP1-DIP6) • DIP1-DIP6 SW1 allow you to adjust processor core voltage manually. We recommend to leave SW1 DIP1 at default, the default means the correct processor core voltage is generated according to VID of CPU. SW1 DIP2 ~ DIP6 SETTING SW1 DIP1 0.0v...

  • Page 24: 2-4.4 Cpu External Frequency Setting (By Sw2)

    75ERV 2-4.4 CPU External Frequency Setting (By SW2) CPU EXTERNAL CLOCK PCI CLOCK FSB CLOCK 100MHz 33.3MHz 200MHz (Default) 133.3MHz 33.3MHz 266MHz 140MHz 35.0MHz 280MHz 150MHz 37.5MHz 300MHz 166MHz 33.3MHz 333MHz IMPORTANT: • Do figure out the correct processor type by processor’s OPN (Ordering Part Numbers).

  • Page 25: Jumper Settings

    Chapter 2 Hardware Setup 2-5 Jumper Settings • The following diagrams show the locations and settings of jumper blocks on the mainboard. FAN1 SOCKET A JP1: Power Lost Resume Disabled (default) Enabled VT8366A AGP 4X PCI 1 AC'97 JCD_IN1 PCI 2 Codec JBAT1: Clear CMOS Data PCI 3...

  • Page 26: 2-5.1 Jp1 Power Lost Resume

    75ERV 2-5.1 JP1 Power Lost Resume JP1: Power Lost Resume Disabled (default) Enabled NOTE: This jumper allows user to use the switch of ATX power supply to control ON/OFF switch directly instead of using the power switch on the mainboard. 2-5.2 JBAT1 For Clear CMOS Data A battery must be used to retain the mainboard configuration in CMOS RAM.

  • Page 27: Connectors Configurations

    Chapter 2 Hardware Setup 2-6 Connectors Configurations • This section lists out all connectors configurations for users’ reference. 2-6.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) FAN1 SOCKET A +12V SENSOR VT8366A AGP 4X On-Board FAN Connectors PCI 1 CPU FAN1 FAN1 AC'97...

  • Page 28: 2-6.2 Wol1 Wake On Lan

    75ERV 2-6.2 WOL1 Wake On LAN FAN1 SOCKET A Standby VT8366A AGP 4X PCI 1 WOL1: Wake On LAN AC'97 JCD_IN1 PCI 2 Codec Connect the Wake On PCI 3 VT8233A LAN signal from LAN JBAT1 WOL1 LPC I/O PCI 4 Controller card to WOL1 PCI 5...

  • Page 29: 2-6.4 Complex Header Con1

    Chapter 2 Hardware Setup 2-6.4 Complex Header CON1 • This complex Header consists of 9 connectors providing various supports: CON1 SUSPEND LED SMI SIGNAL SUSPEND LED SIGNAL POWER SWITCH ATX POWER SWITCH NO CONNECTION NO CONNECTION NO CONNECTION POWER LED NO CONNECTION NO CONNECTION INFRARED(IR)

  • Page 30: 2-6.5 Atx Power Supply Connector

    75ERV 6. Power LED Connector: Connection: Connected to System Power LED. Function : To supply power to “System Power LED”. 7. Reset Switch Connector: Connection: Connected to the case-mounted “Reset Switch”. Function : To supply power to “Reset Switch” and support system reboot function.

  • Page 31: 2-6.6 Chassis Panel Connector

    Chapter 2 Hardware Setup 2-6.6 Chassis Panel Connector A : PS/2 MOUSE PORT B : USB 0 PORT C : LPT1 PORT D : GAME/MIDI PORT E : PS/2 KEYBOARD PORT F : USB 1 PORT G : COM 1 PORT H : COM 2 PORT : LINE OUT / SPEAKER OUT PORT J : LINE IN...

  • Page 32: 2-6.7 Communication And Networking Riser Slot (Cnr)

    75ERV 2-6.7 Communication And Networking Riser Slot (CNR) • This connector allows you to use network, modem or audio riser cards. FAN1 SOCKET A VT8366A AGP 4X PCI 1 AC'97 JCD_IN1 PCI 2 Codec PCI 3 VT8233A JBAT1 LPC I/O PCI 4 Controller PCI 5...

  • Page 33: 2-6.8 Usb Ports And Usb Headers (Header Usb 3)

    Chapter 2 Hardware Setup 2-6.8 USB Ports and USB Headers (Header USB 3) • This series of mainboards provides two USB ports USB0 and USB1 on board supporting various USB devices. In addition, the USB header is added on board to provide two additional USB ports by using one additional USB Cables.
  • Page 34 75ERV MEMO MEMO...

  • Page 35: Chaper 3 Software Setup

    Chapter 3 Software Setup Chaper Software Setup Drivers, Utilities and Software Installation • Support CD: This series of mainboards will always be shipped with a Support CD which contains those necessary driver files, Application Softwares and some helpful utilities. It is a user-friendly, auto-run CD which will open itself up in a CD-ROM automatically.

  • Page 36: Open Up The Suport Cd And Choose Drivers And Utilities

    75ERV 3-1 Open up the Suport CD and choose Drivers and Utilities 1 Please put the Support CD enclosed in your mainboard package into the CD-ROM drive. In a few seconds, the Main Menu will automatically appear, displaying the contents to be installed for this series: Install VIA 4in1 Driver Install AC’97 Audio Driver Install Hardware Monitor Utility...

  • Page 37: Proceed To Via 4-In-1 Drivers Installation

    Chapter 3 Software Setup 3-2 Proceed to VIA 4-In-1 Drivers Installation 1 Following the procedures of opening the Support CD, click to “ VIA 4in1 Drivers” to proceed. 2 T h e V I A S e r v i c e P a c k 3 “VIA Service Pack README”...
  • Page 38 75ERV 6 Select “Install VIA ATAPI 7 Click on “Click to enable DMA Vendor Support Driver” Mode” checkbox to enable DMA checkbox, then click the “Next” function, then click the “Next” button to continue. button to continue. Next Next 8 Select “Install VIA AGP VxD” 9 Select “Install VIA IRQ Routing in turbo mode and press Miniport Driver”...

  • Page 39: Proceed To Ac'97 Audio Driver Installation

    Chapter 3 Software Setup 3-3 Proceed to AC’97 Audio Driver Installation 1 Following the installation of VIA 4in1 drivers, you have to restart system so that your system can be reconfigured with VIA 4in1. When restarting procedures finish, please open the Support CD with your CD-ROM to enter the Main Installation Menu.

  • Page 40: Proceed To Hardware Monitor Installation

    75ERV 3-4 Proceed to Hardware Monitor Installation 1 Following the installation of AC’97 driver, you have to install Hardware Monitor manually. Please click to the following path to execute Hardware Monitor installation: D: \ Hardwaremonitor\ ITE2 \ Install.exe (assuming that your CD-ROM Drive is Drive D) 2 In case you are already on the Installation Main Menu of the Support CD, please click to the “Install Hardware Monitor”.
  • Page 41 Chapter 3 Software Setup 5 To display the Hardware Monitor Utility, just click on the “ITE SMARTGUARDIAM” icon in your program file, and the following screen of Smartguardian Control Panel will show up, displaying the information about system temperatures, voltages and Fan speed. Clicking to the “Option”...
  • Page 42 75ERV MEMO MEMO...

  • Page 43: Chaper 4 Bios Setup

    Chapter 4 BIOS Setup Chaper BIOS Setup THE BIOS • BIOS stands for Basic Input and Output System. It is sometimes called ROM BIOS because it is stored in a Read-Only Memory(ROM) chip on the mainboard. BIOS is the first program to run when you turn on your computer.

  • Page 44: What Is Bios Setup

    75ERV 4-1 What Is BIOS Setup • BIOS setup is an interactive BIOS program that you need to run when: 1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.) 2. Modifying the behavior of your computer. (For example: changing the system time or date, or turning special features on or off etc.) 3.

  • Page 45: Bios Upgrade

    Chapter 4 BIOS Setup 4-5 BIOS Upgrade • System BIOS is incorporated into a Flash memory component of the mainboard. Flash BIOS allows user to upgrade BIOS without the need to replace an EPROM component. • The upgrade utility can be loaded on a floppy diskette and used to provides the capability to save, verify, and update the system BIOS.
  • Page 46 75ERV Step 4. Type awdflash *.bin /sn/py/cc and then press <Enter> to run BIOS upgrade program. (*.bin depends on your mainboard model and version code. Instead of typing “*”, you should type specific file name for your specific mainboard). Step 5. Please press <F1> or <F10> to exit or reset your system, Warning ! If the message “Write Fail”...
  • Page 47 Chapter 4 BIOS Setup Award Flash Memory Writer Start Screen Award Flash Memory Writer Complete Screen...
  • Page 48 75ERV The parameters of AWDFLASH.EXE /sn: No original BIOS backup /py: Program flash memory /cc: Clear CMOS data (and update data automatically) after pro- gramming NOTE: Users can type AWDFLASH /? to get further details about the parameters. Incorrect usage of the parameter will damage the BIOS information, so we strongly recommend user to leave parameters alone unless you fully understand their function.

  • Page 49: Bios Setup

    Chapter 4 BIOS Setup 4-6 BIOS Setup --- CMOS Setup Utility 4-6.1 CMOS Setup Utility • This mainboard comes with the AWARD BIOS from AWARD Software Inc. Enter the CMOS Setup Utility Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 50: 4-6.2 Standard Cmos Setup

    75ERV 4-6.2 Standard CMOS Setup • Standard CMOS Setup records some basic system hardware configuration and sets the system clock and error handling. You only need to modify the configuration values of this option if you want to change your system hardware configuration or when the data stored in the CMOS memory gets lost or damaged.
  • Page 51 Chapter 4 BIOS Setup Date (mm:dd:yy) The BIOS determines the day of the week from the other date information. This field is for information only. Press the left or right arrow key to move to the desired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the desired value into the field.
  • Page 52 75ERV Drive A / Drive B Select this field to the type(s) of floppy disk drive(s) installed in your system. The choices are: 360KB, 5.25in; 1.2MB, 5.25in; 720KB, 3.5in; 1.44MB, 3.5in; 2.88MB, 3.5in; None. Video Select the type of primary video subsystem in your computer.

  • Page 53: 4-6.3 Advanced Bios Features

    Chapter 4 BIOS Setup 4-6.3 Advanced BIOS Features • Advanced BIOS Features improves your system performance or sets up system features according to your preference. Run the Advanced BIOS Features as follows: 1. Choose “Advanced BIOS Features” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced BIOS Features...
  • Page 54 75ERV 2. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys. An explanation of the <F> keys follows: <F1>: “Help” gives options available for each item. <F5>: Get the previous values.
  • Page 55 Chapter 4 BIOS Setup Quick Power On Self Select Enabled to reduce the amount of time required to Test run the power-on self-test (POST). A quick POST skips certain steps. We recommend that you normally enable quick POST. First/Second/Third/ The BIOS attempts to load the operating system from Other Boot Device the devices in the sequence selected in these items.
  • Page 56 75ERV Typematic Rate Setting When Disabled, the following two items (Typematic Rate and Typematic Delay) are irrelevant. Keystroke repeats at a rate determined by the keyboard controller in your system. When Enabled, you can select a typematic rate and typematic delay. Typematic Rate (Chars When the typematic rate setting is enabled, you can / Sec)

  • Page 57: 4-6.4 Advanced Chipset Features

    Chapter 4 BIOS Setup 4-6.4 Advanced Chipset Features • Advanced Chipset Features is used to modify the values of chipset buffers. These buffers control the system options. Run the Advanced Chipset Features as follows: 1. Choose “Advanced Chipset Features” from the Main Menu and a list of option will appear: 2.
  • Page 58 75ERV DRAM Clock/Drive Control CMOS Setup Utility - Copyright (C) 1984-2001 Award Software DRAM Clock/Drive Control Item Help Current FSB Frequency 100MHz Menu Level DRAM Clock 100MHz DRAM Timing By SPD SDRAM Cycle Length Bank Interleave Disabled DRAM Command Rate 1T Command :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults...
  • Page 59 Chapter 4 BIOS Setup AGP & P2P Bridge Control CMOS Setup Utility - Copyright (C) 1984-2001 Award Software AGP & P2P Bridge Control Item Help AGP Aperture Size Menu Level AGP Mode Auto AGP Driving Control AGP Driving Value Disabled AGP Fast Write Disabled AGP Master 1 WS Write...
  • Page 60 75ERV * AGP Master 1 ws Leave this field at default. write * AGP Master 1 ws Leave this field at default. read CPU & PCI Bus Control CMOS Setup Utility - Copyright (C) 1984-2001 Award Software CPU & PCI Bus Control Item Help Enabled PCI1 Master 0 WS Writer...
  • Page 61 Chapter 4 BIOS Setup Memory Hole In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory space below 16MB. The choices: 15M-16M; Disabled. System BIOS Selecting Enabled allows caching of the system Cacheable BIOS ROM at F0000h-FFFFFh, resulting in better system performance.

  • Page 62: 4-6.5 Integrated Peripherals

    75ERV 4-6.5 Integrated Peripherals • Integrated Peripherals option allows you to get some information inside your system when it is working. Run the Integrated Peripherals as follows: 1. Choose “Integrated Peripherals” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Integrated Peripherals Item Help...

  • Page 63: Via Onchip Ide Device

    Chapter 4 BIOS Setup VIA OnChip IDE Device CMOS Setup Utility - Copyright (C) 1984-2001 Award Software VIA OnChip IDE Device Item Help OnChip IDE Channel0 Enabled OnChip IDE Channel1 Enabled Menu Level IDE Prefetch Mode Enabled Primary Master PIO Auto Primary Slave PIO Auto...

  • Page 64: Via Onchip Pci Device

    75ERV * Primary Ultra DMA33/66/100 implementation is possible only Master / Slave UDMA if your IDE hard drive supports it, if the operating Secondary environment includes a DMA drive, and if your sys- Master / Slave UDMA tem software both support Ultra DMA33/66/100. Select “Auto”...
  • Page 65 Chapter 4 BIOS Setup VIA SuperIO Device CMOS Setup Utility - Copyright (C) 1984-2001 Award Software VIA SuperIO Device Item Help Onboard FDC Controller Enabled Onboard Serial Port 1 3F8/IRQ4 Menu Level Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal UR2 Duplex Mode Half...
  • Page 66 75ERV * UR2 Duplex Mode This item allows you to select the IR half / full duplex function. The choices: Half; Full. * Onboard Parallel Port This item allows you to determine onboard parallel port controller I/O address setting. The choices: 378H/IRQ7; 278H/IRQ5; 3BC/IRQ7; Disabled.
  • Page 67 Chapter 4 BIOS Setup USB Keyboard Sup- Select Enabled if your system contains a Universal port Serial Bus (USB) controller and you have a USB keyboard. IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/write per sector the...

  • Page 68: 4-6.6 Power Management Setup

    75ERV 4-6.6 Power Management Setup • Power Management Setup allows you to set the system’s power saving functions. Run the Power Management Setup as follows: 1. Choose “Power Management Setup” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Power Management Setup Item Help...
  • Page 69 Chapter 4 BIOS Setup ACPI Function Select Enabled only if your computer’s operating system supports the Advanced Configuration and Power Interface (ACPI) specification. Currently, Windows NT 5.0 support ACPI. ACPI Suspend Type This item allows you to select the ACPI suspend type.
  • Page 70 75ERV Monitor will remain on during power saving Always On modes. Monitor blanked when the systems enters the Suspend -->Off Suspend mode. Monitor blanked when the system enters either All Modes -->Off Suspend or Standby modes. Video Off Method This determines the manner by which the monitor is blanked.
  • Page 71 Chapter 4 BIOS Setup IRQ/Event Activity Detect CMOS Setup Utility - Copyright (C) 1984-2001 Award Software IRQ/Event Activity Detect Item Help Disabled USB Resume from S3 Menu Level LPT/COM LPT & COM HDD & FDD PCI Master Disabled PowerOn by PCI Card Disabled Wake Up On LAN/Ring Disabled...
  • Page 72 75ERV * PowerOn by PCI Card This item allows system wake up by PCI Device. * Wake Up On LAN/ An input signal on the serial Ring Indicator (RI) line Ring (in other words, an incoming call on the modem) awakens the system from a soft off state.
  • Page 73 Chapter 4 BIOS Setup * IRQ Activity Monitoring CMOS Setup Utility - Copyright (C) 1984-2001 Award Software IRQ Activity Monitoring Primary INTR Item Help IRQ-3 (COM2) Enabled Menu Level IRQ-4 (COM1) Enabled IRQ-5 (LPT2) Enabled IRQ-6 (Floppy Disk) Enabled IRQ-7 (LPT1) Enabled IRQ-8 (RTC Alarm) Disabled...

  • Page 74: 4-6.7 Pnp / Pci Configuration

    75ERV 4-6.7 PNP / PCI Configuration • PNP/PCI Configuration allows you to modify the system’s power saving functions. Run the PNP/PCI Configuration as follows: 1. Choose “PNP/PCI Configuration” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software PnP/PCI Configurations Item Help...
  • Page 75 Chapter 4 BIOS Setup PNP OS Installed Select Yes if the system operating environment is Plug-and-Play aware (e.g., Windows95). NOTE: BIOS will automatically disable all PnP resources except the boot device card when you select Yes on Non-PnP operating system. Reset Configuration Normally, you leave this Disabled.
  • Page 76 75ERV PCI SLOT1/5, 2, 3, 4 These options allow you to assign an IRQ for each IRQ Assigned PCI SLOT and this is a useful function when you want to clear the IRQ conflict for a specific device. The options are available : Auto; 3; 4; 7; 9; 10; 11. IRQ RESOURCES Press Enter.

  • Page 77: 4-6.8 Smartdoc Anti-Burn Shield

    Chapter 4 BIOS Setup 4-6.8 SmartDOC Anti-Burn Shield • This section helps you to get more information about your system including CPU temperature, FAN speed and voltage. It is recommended that you contact with your mainboard supplier to get proper values about the setting of the CPU temperature.
  • Page 78 75ERV Shutdown Tempera- This feature prevents your CPU from damage by ture over heat. If the CPU’s temperature is higher than “CPU warning temperature” that you select in this field, the BIOS will shut down your system within 3 seconds. CPU Vcore Shows CPU core actual voltage value.

  • Page 79: 4-6.9 Frequency/Voltage Control

    Chapter 4 BIOS Setup 4-6.9 Frequency/Voltage Control Run the “Frequency/Voltage Control” as following: 1. Choose “Frequency/Voltage Control” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Frequency/Voltage Control Item Help Press Enter...
  • Page 80 75ERV Redstorm Please press <Enter> to start RED STORM OVER- Overclocking CLOCKING TECH, this option helps user an easy Tech way to overclocking, it will increase CPU external clock automatically, when CPU external clock in- creasing to unacceptable value, BIOS will restart your system, then running at acceptable CPU ex- ternal clock.

  • Page 81: 4-6.10 Load Optimized Defaults

    Chapter 4 BIOS Setup 4-6.10 Load Optimized Defaults • When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y / N) ? N ” Pressing “Y” loads the BIOS default values that are factor settings for optimal performance of system operations.

  • Page 82: 4-6.12 Save & Exit Setup

    75ERV 7. Move the cursor to Save & Exit Setup to save the option you have just configured; otherwise the old password will still be there the next time you turn your system on. 8. Press <Enter> to exit to the Main Menu. NOTE: If you forget or lose the password, the only way to access the system is to clear the CMOS RAM.
  • Page 83 Chapter 4 BIOS Setup MEMO MEMO...

  • Page 84: Appendices

    APPENDIX Appendices APPENDIX-1 Identify BIOS Version & BIOS Part Number APPENDIX-2 Identify Mainboard Model Number APPENDIX-3 Technical Terms...

  • Page 85: Appendix-1 Identify Bios Version & Bios Part Number

    APPENDIX Appendix-1 Identify BIOS Version & BIOS Part Number • See Picture-2 below for BIOS version and BIOS part number identification. Picture-2 BIOS VERSION example: REV T2.1 BIOS ID STRING example: 6A69RSNCC...

  • Page 86: Appendix-2 Identifying Mainboard Model Number

    APPENDIX Appendix-2 Identifying Mainboard model Number • Usually the mainboard model number is labeled on the side of ISA side of slot or PCI slot. Please see the picture below as an illustration: MAINBOARD MODEL NUMBER example: SL-65KV2 MAINBOARD SERIAL NUMBER example: 0012000T005679...

  • Page 87: Appendix-3 Technical Terms

    APPENDIX Appendix-3 Technical Terms AC’97 AC’97 is a device designed to include a digital processor for modem and an audio CODEC for analog I/O. These two parts are linked together by AC’97 link bus. Putting the digital processor into the main system chipset will reduce the cost of sound/modem onboard solution.
  • Page 88 APPENDIX ATAPI (AT Attachment Packet Interface) This is the exension of the EIDE (extended IDE) that enables the interface to support CD-ROM players and tape drives. BIOS (Basic Input/Output System) BIOS is a set of assembly routine/program that resides in EPROM or Flash ROM.
  • Page 89 APPENDIX DIMM (Dual In Line Memory Module) DIMM socket is built with a 168-pin assignment and supports 64-bit data. DIMM can be single or double sided. The golden finger signals on each side of the module are different, and that is why it is called Dual In Line. Almost all DIMMs are made with SDRAM now, which operate at 3.3V.
  • Page 90 APPENDIX FC-PGA (Flip Chip-Pin Grid Array) FC means Flip Chip, while FC-PGA is a new package of Intel for Pentium III CPU. It is compatible with SKT370 socket, but requires mainboard to add some signals on socket 370. Flash ROM Flash ROM can be re-programmed by electronic signals.
  • Page 91 APPENDIX PC-1600 or PC-2100 DDR SDRAM PC-1600 DDR SDRAM with a 64-bit data bus doubles the data transfer rate of PC100 SDRAM and hence provides data transfer bandwidth up to 100x64/ 8x2=1600MB/s. PC2100 DDR SDRAM doubles the data transfer rate of PC-133 and hence provides data transfer bandwidth up to 133x64/ 8x2=2100MB/s.
  • Page 92 APPENDIX SDRAM (Synchronous DRAM) SDRAM is one of the Dynamic Random Access Memory (DRAM) technologies that allow DRAM to use the same clock as the CPU host clock (EDO and FPM are asynchronous and do not have clock signal). SDRAM comes in 64-bit 168-pin DIMM and operates at 3.3V.
  • Page 93 APPENDIX USB (Universal Serial Bus) USB is a 4-pin serial peripheral bus that is capable of cascading low/medium speed peripherals (less than 10Mbit/s) such as keyboard, mouse, joystick, scanner, printer and modem. VCM (Virtual Channel Memory) NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements.
  • Page 94 APPENDIX MEMO MEMO...
