THERMOSTATIC CONTROL OPERATION
The thermostatic control used on this model differs from standard thermostats. Standard thermostats simply
turn the burner on and off. The thermostat used on this heater senses the room temperature. At times the
room may exceed the set temperature. If so, the burner will shut off. The burner will cycle back on when room
temperature drops below the set temperature. The control knob can be set to any comfort level.
Note: The thermostat sensing bulb measures the temperature (depending on housing construction,
The thermostatic control used on this model differs from standard thermostats. Standard thermostats simply turn
the burner on and off. The thermostat used on this heater senses the room temperature. At times the room may
exceed the set temperature. If so, the burner will shut off. The burner will cycle back on when room temperature
drops below the set temperature. The control knob can be set to any comfort level between HIGH (5) and LOW (1).
LIGHTING INSTRUCTIONS
1.
STOP! Read the safety information on page 3.
2.
Unscrew ignitor cap and install a AAA type battery with its anode ("+") pointing out. Replace cap
3.
Make sure equipment shutoff valve is fully open.
4.
Warning: You must operate this fireplace with the fireplace screen in place. Make sure fireplace screen is
installed before running fireplace.
5.
Turn control knob clockwise to the OFF position, see Figure 14.
6.
Wait five (5) minutes to clear out any gas. Then smell for gas around heater and near floor. If you smell
gas, STOP! Follow "B" in the safety information on Warnings plate. If you don't smell gas, go to the next
step.
7.
Turn control knob counterclockwise to the PILOT position. Keep control knob pressed in for five (5)
seconds. Note: You may be running this heater for the first time after hooking up to gas supply. If so , the
control knob may need to be pressed in for 30 seconds. This will allow air to bleed from the gas system. If
control knob does not pop up when released, contact a qualified service person or gas supplier for repairs.
8.
With control knob pressed in, push and hold ignitor button. This will light pilot. The pilot is attached to the
rear of the front burner. If needed, keep pressing ignitor button until pilot lights. Note: If pilot does not
stay lit, contact a qualified service person or gas supplier for repairs. Until repairs are made, light pilot with
match.
9.
Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob.
Note: If pilot goes out, repeat steps 3 through 8. This heater has a safety interlock system. Wait one (1)
minute before lighting pilot again.
10. Warning: Make sure while the input gas type is NG, pilot burner NG ignites; while the input type is LP,
pilot burner LP ignites. Note: If you find anything abnormal in this step, repeat steps 2 through 8.
11. Turn control knob counterclockwise to the desired heating level. The main burner should light. Set control
knob to any heat level between HI and LO (5 –1).
TO TURN OFF GAS TO APPLIANCE
Shut off heater
Turn Control Knob clockwise
www.PartsFor.com 1-800-446-1446
to the OFF position. Do not force.
16
For replacement parts contact:
1-866-607-2787
Figure 14
Figure 14
