VENT-FREE GAS FIREPLACE INSERT
Model # FBD32RT
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY, OR LOSS OF LIFE.
– Do not store or use gasoline or other flammable vapors and liquids in vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
· Do not try to light any appliance.
· Do not touch any electrical switch; do not use any phone in your building.
· Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
· If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is
installed. Provisions for adequate combustion and ventilation air must be provided.
Refer to Air for Combustion and Ventilation section on page 7 of this manual.
INSTALLER: DO NOT DISCARD THIS MANUAL – LEAVE FOR HOMEOWNER'S
FUTURE REFERENCE.
This appliance may be installed in an aftermarket, permanently located manufactured
(mobile) home, where not prohibited by local codes. This appliance is for use with the
type of gas indicated on the rating plate only. This appliance is not convertible for use
with other gases.
Questions about installation, operation, or troubleshooting? Before returning to your retailer, contact our
customer service department at 1-877-886-5989, 8:00 a.m.- 4:30p.m., EST, Monday-Friday or e-mail
customerservice@usaprocom.com.
CAUTION – FOR YOUR SAFETY
WARNING: This appliance is
equipped for (Natural and Propane)
gas. Field conversion is not
permitted other than between
natural or propane gases.
PC-FBD32RT-0903
Advertisement
Table of Contents
Related Manuals for Procom FBD32RT
Summary of Contents for Procom FBD32RT
- Page 1 Field conversion is not permitted other than between natural or propane gases. VENT-FREE GAS FIREPLACE INSERT Model # FBD32RT CAUTION – FOR YOUR SAFETY WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE.
-
Page 2: Table Of Contents
WARNING: READ THE INSTALLATION & OPERATION INSTRUCTIONS BEFORE USING THIS APPLIANCE IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. PRODUCT SPECIFICATIONS MODEL FBD32RT Input Rating 32,000 BTU/Hr 32,000 BTU/Hr Gas Type... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. Only a qualified installer, service agent, or local gas supplier may install and service this product. - Page 4 Do not place Propane/LP supply tank(s) inside any structure. Place Propane/LP supply tank(s) outdoors. This heater needs fresh air ventilation to run properly. This heater has an Oxygen Depletion Sensing (ODS) safety shut-off system. The ODS shuts down the heater if not enough fresh air is available. See Air for Combustion and Ventilation, pages 7 through 9.
-
Page 5: Product Features
PRODUCT FEATURES SAFETY PILOT This heater has a pilot with an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS/pilot shuts off the heater if there is not enough fresh air. PIEZO IGNITION SYSTEM This heater is equipped with an electronic piezo control system. This system requires AAA batteries (provided). 2 GAS OPTIONS CAPABLE Your heater is equipped to operate on either propane or natural gas. -
Page 6: Product Identification
UNPACKING 1. Remove top inner pack. 2. Tilt carton so that heater is upright. 3. Remove protective side packaging. 4. Slide heater out of carton. 5. Remove protective plastic wrap. 6. Hold the screen lift and pull forward. 7. Remove log set by cutting plastic. 8. -
Page 7: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: This heater should not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home. PRODUCING ADEQUATE VENTILATION This heater shall not be installed in a room or space unless the required volume of indoor combustion air is provided by the method described in the NATIONAL FUEL GAS CODE, ANSI Z223.1/NFPA 54, the INTERNATIONAL FUEL... - Page 8 Divide the space volume by 50 cu. ft. to determine the maximum BTU/hr the space can support. __________ (volume of space) ÷ 50 cu. ft.= (Maximum BTU/hr the space can support) Example: 2560 cu. ft. (volume of space) ÷ 50 cu. ft. = 51.2 or 51,200 (maximum BTU/hr the space can support) Add the BTU/hr of all fuel burning appliances in the space.
-
Page 9: Ventilation Air From Inside Building
Ventilation Air From Inside Building This fresh air would come from adjoining unconfined space. When ventilating to an adjoining unconfined space, you must provide two permanent openings: one within 12 inches of the wall connecting the two spaces (see options 1 and 2, Figure 2). -
Page 10: Installation
INSTALLATION NOTICE: This heater is intended for use as supplemental heat. Use this heater along with your primary heating system. Do not install this heater as your primary heat source. If you have a central heating system, you may run system’s circulating blower while using heater. -
Page 11: Built-In Fireplace Installation
NOTE: When heater is installed directly on carpeting, tile or other combustible material, other than wood flooring, the heater must be installed on a metal or wood panel extending the full width and depth of the heater. BUILT-IN FIREPLACE INSTALLATION Built-in installation of this fireplace involves installing fireplace into a framed-in enclosure. - Page 12 IMPORTANT: When finishing your firebox, Combustible materials such as wall board, gypsum board, sheet rock, drywall, plywood, etc, must have ½ -in. clearance to the sides and top of the firebox. Combustible materials should never overlap the firebox front facing. WARNING: Do not allow any combustible materials to overlap the firebox front facing.
-
Page 13: Connecting To Gas Supply
CONNECTING TO GAS SUPPLY WARNING: A qualified technician must connect heater to gas supply. Follow all local codes. WARNING: This appliance requires a 3/8 in. NPT inlet connection to pressure regulator (see Figure 10). CAUTION: Never connect heater directly to the gas supply. This heater requires an external regulator (not supplied). - Page 14 CAUTION: Use only new black iron or steel pipe. Internally tinned copper tubing may be used in certain areas. Check your local codes. Use pipe of ½ inch diameter or greater to allow proper volume gas to heater. If pipe is too small, loss of pressure will occur.
- Page 15 CAUTION: Two gas line installation at the same time is forbidden. You are not allowed to open the cover while the machine is running. Heater is pre-set at factory for propane gas; no changes are required for connecting to propane. Only a qualified installer or service technician can perform gas selection and connecting to gas supply.
-
Page 16: Checking Gas Connections
CHECKING GAS CONNECTIONS WARNING: Test all gas piping and connections for leaks after installing or servicing. Correct all leaks immediately. WARNING: Never use an open flame to check for a leak. Apply a mixture of liquid soap and water to all joints. If bubbles form, there may be a leak. - Page 17 Installation for Decorative Trim: Installation for Left/Right Decorative Trim: · Wedge two flanged screws on sides of the shell into slots of Left/Right Decorative Trim. (See Figure 18) Installation for Top Decorative Trim: · Wedge two flanged screws on top cover into slots of Top Decorative Trim. (See Figure 19) Figure 19 Figure 18 Installation for Remote Receiver:...
-
Page 18: Installing Logs
INSTALLING LOGS WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts included may result in property damage or personal injury. CAUTION: After installation, and periodically thereafter, check to ensure that no flame comes in contact with any log. - Page 19 STEP 6: Install the log 6 on the right front angle. STEP 7: Insert the pinhole on the upper part of log 7 in the pin on log 1, log 3 and log 5. STEP 9: Insert the pinhole on the upper part of log STEP 8: Insert the pinhole on the upper part of log 9 in the pin on log 4 and log 6.
-
Page 20: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. NOTICE: During initial operation of new heater, burning logs will give off a paper burning smell. Orange flame will also be present. -
Page 21: Lighting Instructions
LIGHTING INSTRUCTIONS STOP! Read the safety information on Warning plates. Make sure manual shutoff valve is fully open, installed two AAA batteries in the transmitter. Open the door of the heater, push in control knob slightly and clockwise to the OFF position. If the switch is on ON or OFF position, adjust it to REMOTE position. -
Page 22: Remote Control Operation
REMOTE CONTROL OPERATION MATCHING SECURITY CODES When matching security codes, be sure slide button on the receiver is in the REMOTE position. To program the remote receiver to LEARN a new security code, press and release the LEARN button on the top of the remote receiver, and then press ON or OFF button on the transmitter. - Page 23 OFF OPERATION Press the OFF key and the appliance flame will shut off. During this time the LCD screen will show OF (figure 30). After 3 seconds the LCD screen will default to display room temperature and the wood TEMP will show (figure 31). THERMOSTAT FUNCTION Figure 30 Figure 31...
-
Page 24: Inspecting Burners
INSPECTING BURNERS Check pilot flame pattern and burner flame patterns often. PILOT FLAME PATTERN 1. Turn control knob to pilot position 2. Inspect pilot flame and refer to Figure 34 and 35. · Figure 34 shows a correct pilot flame pattern. ·... -
Page 25: Care And Maintenance
CARE AND MAINTENANCE WARNING: Failure to keep primary air openings of burners clean may result in sooting and property damage. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service person. Heater may need more frequent cleaning due to excessive lint from carpeting, bedding material, pet hair, etc. -
Page 26: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: · Shut off gas supply. · Do not try to light any appliance. · Do not touch any electrical switch; do not use any phone in your building. · Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. ·... - Page 27 OBSERVED PROBLEM PROBABLE CAUSE REMEDY ODS/pilot lights but flame Control knob is not fully pressed in. Press in control knob fully. goes out when control Control knob is not pressed in long After ODS/pilot lights, keep control knob is released. enough.
- Page 28 OBSERVED PROBLEM PROBABLE CAUSE REMEDY Slight smoke or odor 1. Residues from manufacturing 1. Problem will stop after a few hours of during initial operation process. operation. Heater produces a 1. Turning control knob to high (5) 1. Turn control knob to low (1) position and whistling noise when position when burner is cold.
-
Page 29: Replacement Parts
REPLACEMENT PARTS NOTE: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. If they can’t supply original replacement parts, call Customer Service toll free at (1-877-886-5989) for referral information. When calling Customer Service or your dealer, have ready: ·... -
Page 30: Parts List
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on 29 of this manual. KEY NO. PART NUMBER DESCRIPTION FB32D600 Burner Assembly FB32D304 ODS Outlet Tube NDD0308x400 FB32D305 ODS Outlet Tube FB32D201 Hood... - Page 31 Printed in China...
