SFE23RE SHOWN
Installation Instructions and Owner's Manual
WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE
MAY RESULT CAUSING PROPERTY, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
DO NOT STORE
OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS
IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE
INSTALLER: DO NOT DISCARD THIS MANUAL-LEAVE FOR HOME OWNER
PC(220)-FE23A610-0709
1
Advertisement
Table of Contents
Related Manuals for Procom SFE23RE Series
Summary of Contents for Procom SFE23RE Series
-
Page 1: For Your Safety
SFE23RE SHOWN Installation Instructions and Owner’s Manual WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE... -
Page 2: Table Of Contents
TABLE OF CONTENTS PLEASE READ THE INSTALLATION & OPERATION INSTRUCTIONS BEFORE USING THIS APPLIANCE IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty. Important Instructions ….…………………………………………………………..2 Locating Your Electric Fireplace…………………………………….…………..3 Clearance To Combustibles………………………………………….…………..3... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions 11. To disconnect heater, turn controls to OFF, then should always be followed to reduce the risk of fire, remove plug from outlet. electric shock, and injury to persons, including the 12. Connect to properly grounded outlets only. following: 13. -
Page 4: Locating Your Electric Fireplace
LOCATING YOUR ELECTRIC FIREPLACE WARNING: Electrical outlet wir- ing must comply with local build- Your new freestanding electric fireplace may be installed vir- ing codes and all other appli- tually anywhere in your home. However when choosing a cable regulations to reduce the location for your new electric fireplace, ensure that the gen- risk of fire, electrical shock and eral instructions are followed. -
Page 5: Installing Decorating Logs
Installing decorating logs Installing logs for SFE33RE Series: FIG 2 1.Place log 1, log 2 and log 3 into the correspond- FIG 1 ing holes on grate. (See FIG 2). FIG 4 FIG 3 2.Insert the pin on one end of log 4 to the recessed 3.Insert the pin on one end of log 5 to the recessed hole on log 1, with the other end of log 4 placed hole on log 2, with the other end of log 5 placed... -
Page 6: Service Instructions
GLASS INFORMATION MAINTENANCE OF MOTORS 1. Under no circumstances should this product be The motors used on the fan and flame genera- operated with missing or broken glass. tor assembly are prelubricated for extended 2. Do not strike or slam the glass. bearing life and require no further lubrication. -
Page 7: Electrical Wiring Diagram
ELECTRICAL WIRING DIAGRAM Any electrical repairs or rewiring of this unit should be carried out by a licensed electrician in accordance with national and local codes. If repairing or replacing any electrical component or wiring, the original wire routing, color coding and securing location must be followed. - Page 8 ELECTRICAL WIRING DIAGRAM SFE33RE Any electrical repairs or rewiring of this unit should be carried out by a licensed electrician in accordance with national and local codes. If repairing or replacing any electrical component or wiring, the original wire routing, color coding and securing location must be followed.
-
Page 9: Operating Instructions
Operating Instructions Before programming your transmitter you must first insert two “AAA” batteries. Make sure the main power on/off switch is “ON” position. 1. The ON/OFF button: *Note: When Fireplace is first operated, the default setting will be: brightest flame, and full heating To turn on Heater, press the “ON/OFF”... -
Page 10: Specification
SPECIFICATIONS: Model: SFE33RE series Model: SFE23RE series Voltage: 220V/50HZ Total Amps: 6.3A Voltage: 220V/50HZ Total Amps: 6.3A Total Watts: 1380W Heating Ratings: 1200W Total Watts: 1380W Heating Ratings: 1200W Dimensions, Cm (H x W X D) Dimensions,Cm (H x W X D) 96.5x100x39.7... -
Page 11: Replacement Parts
Replacement Parts SFE23RE Series... - Page 12 Replacement Parts SFE33RE Series (Logs for SFE33RE)
-
Page 13: Replacement Parts List
Replacement Parts List SFE23RE Series SFE33RE Series Part Number Item Part Description SFE23RE SFE33RE Log Set FE23A400 FE33A400 Control Box ECRMB3-220 ECRMB3-220 Receiver ECRRA1 ECRRA1 Fan Heater Assembly GL45.L(HFG2212) GL45.L(HFG2212) AC Motor FE23A307 FE23A307/FE23A307G Power Cord w/Terminal NFHL008-R NFHL008-R Light Bulb Socket w/Wiring...
