OWNER ' S OPERATION AND INSTALLATION MANUAL
EN250RYLB-O
EL250RYLB-O
WARNING:
I
adjustment, alteration, service or main-
t e n a n c e can cause injury or property
damage. Refer to this manual for correct
installation and operational procedures. For
assistance or additional information con-
sult a qualified installer, service agency or
gas supplier.
WARNING:
This is an unvented gas-
fired heater. It uses air (oxygen) f r o m t h e
r o o m i n w h i c h i t i s installed. Provi-
sions for adequate combustion and venti-
lation air must b e p r o v i d e d . R e f e r t o
A i r F o r Combustion and Ventilation sec-
tion on page 5 of this manual.
Continental Appliance Inc./U.S. Office
5 Musick
4600 Highlands Parkway S.E.
Irvine
Suite# D/E
CA 92618
Smyrna GA 30080
Nanjing PRO-COM Electric Appliance Co.,Ltd.
#6 Chuangye Road,High New Tech.Zone,
Great Bridge Road North,Nanjing,210061,China.
TOLL-FREE PHONE NUMBER: (877)886-5989
mproper
installation,
WARNING:
this manual is not followed exactly, a
f i r e o r e x p l o s i o n m a y r e s u l t caus-
ing property damage, personal injury,
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your building.
Immediately
call
from a neighbor's phone. Follow the gas
supplier's
instructions.
If you cannot reach your gas supplier,
call the fire department.
Installation and service must be performed
by a qualified installer, service agency,
or gas supplier.
This appliance may be installed in an
aftermarket*, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
WATER VAPOR:
A BY-PRODUCT OF UNVENTED ROOM HEATERS
Water vapor is a by-product of gas combustion.An
unvented room heater productes approximately one
(1) ounce (30ml) of water for every 1,000 BTU's (.3KW's)
of gas input per hour. Refer to page 4.
Installer: Please leave these instructions with the
consumer
.
Consumer: Please retain these instructions for
future use.
*Aftermarket: Completion of sale, not for purpose of
resale, from the manufacturer.
1
COMPACT VENT-FREE
FIREPLACE SYSTEM
If the information in
your gas supplier

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL250RYLB-O and is the answer not in the manual?

Questions and answers

Summary of Contents for Procom EL250RYLB-O

  • Page 1 OWNER ’ S OPERATION AND INSTALLATION MANUAL EN250RYLB-O EL250RYLB-O WARNING: mproper adjustment, alteration, service or main- t e n a n c e can cause injury or property damage. Refer to this manual for correct installation and operational procedures. For...
  • Page 2: Table Of Contents

    Tabel of Contents Safety Information Warnings...3 Air for Combustion and Ventilation...5 Installation...7 Operating heater...10 Cleaning&Maintenance..12 Trouble Shooting...14 Specifications..15 Replacement Parts...16 Parts List...17 Installing the Heater..20...
  • Page 3: Safety Information Warnings

    I M P O R T A N T: R e a d t h i s owner’s manual carefully and c o m p l e t e l y b e f o r e t r y i n g assemble, operate, or service this...
  • Page 4: Product Identification

    SAFETY INFORMATION Continued 15. Turn off and unplug heater and let cool before servicing. Only a qualified service person should service and repair heater. 16. Operating heater above elevations of 4,500 feet could cause pilot outage. 17. Do not operate heater if any log is broken.
  • Page 5: Providing Adequate Ventilation

    AIR FOR COMBUSTION AND VENTILATION WARNING: This heater shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventila- tion air. Read the following in- structions to insure proper fresh air for this and other fuel-burning appliances in your home.
  • Page 6 3. Add the Btu/Hr of all fuel burning appliances in the space. Vent-free heater Gas water heater* Gas furnace Vented gas heater Gas heater logs Other gas appliances* + Total *Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
  • Page 7: Installation

    NOTICE : This heater is intended for use as supplemental heat. Use this heater along with your primary heating system. Do not install this heater as your primary heat source. If you have a central heating system, you may run system's circulating blower while using heater.
  • Page 8: Connecting To Gas Supply

    CONNECTING TO GAS SUPPLY WARNING : A qualified service person must connect heater to gas supply. Follow all local codes. CAUTION: Never connect heater directly to the gas supply. This heater requires an external regulator (not supplied). lnstall the external regulator between the heater and gas supply.
  • Page 9: Checking Gas Connections

    CHECKING GAS CONNECTIONS WARNING: Test all gas piping and connections for leaks after install- ing or servicing. Correct all leaks at once. Pressure Testing Gas Supply Piping System Test Pressures In Excess Of 1/2 PSIG(3.5kPa) 1. Disconnect heater with its appliance main gas valve (control valve) and equipment shutoff valve from gas supply piping system.
  • Page 10: Installing Logs

    INSTALLATION Continued INSTALLING LOGS WARNING: Failure to position the parts in accordance with these diagrams may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to en- sure that no flame comes in contact with any log. With the heater set to HIGH, check to see if flames contact any log.
  • Page 11 OPERATING HEATER Continued Fig 13 Back of the Transmitter OPERATIONS OF REMOTE TRANSMITTER 1.Install three AAA SIZE batteries in the bat- tery holder. The initial start-up on the LCD is: SET TEMP is 77°F, ROOM TEMP is 77°F, clock is AM12: 00, burner is on “OFF”...
  • Page 12: Cleaning&Maintenance

    3.After completion of the above-men- tioned two steps, the transmitter is kept in a state of readiness. If the appliance doesn’t working for a period time, just pull out the plug from the 110V electrical outlet. OPERATIONS OF KEY-PRESS LOCKING 1.Key press locking: when the burner is in operation or the transmitter is in a state of readiness, just...
  • Page 13: Cleaning And Maintenance

    CLEANING AND MAINTENANCE C A U T I O N : Yo u m u s t k e e p c o n t r o l a r e a s , b u r n e r , a n d circulating air passageways of h e a t e r c l e a n .
  • Page 14: Troubleshooting

    WARNING:Make sure that power is turn off before proceeding... OBSERVED PROBLEM No spark when press in ignition button When pressing the button of ignitor but- ton is pressed, there is spark at ODS/ pilot but no ignition ODS/pilot lights but flame is continuous igniting and the main burner couldn’t be lit.
  • Page 15: Specifications

    1. Improper log placement 2. Air holes at burner inlet blocked 3. Burner flame holes blocked 1. Metal expanding while heating or contracting while cooling SPECIFICATIONS EL250RYLB-O 20,000/25,000 LP Gas Automatic 8"W.C. 14" 11" 38 3/16” × 26 3/8” × 14 1/8”...
  • Page 16: Replacement Parts

    REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty c o v e r a g e f o r p a r t s r e p l a c e d u n d e r warranty.
  • Page 17: Illustrated Parts Breakdown

    ILLUSTRATED PARTS BREAKDOWN EN250RYLB-O EL250RYLB-O...
  • Page 18: Parts List

    PARTS LIST EL250RYLB-O EN250RYLB-O This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 16 of this manual.
  • Page 19 ILLUSTRATED PARTS BREAKDOWN EL250RYLB-O EN250RYLB-O...
  • Page 20: Installing The Heater

    PARTS LIST EL250RYLB-O EN250RYLB-O t t i...
  • Page 21 Install the decorating logs. Fasten decorating logs 1 ¡¢ ¡¢2 ¡¢ ¡¢ ¡¢ ¡¢ Figure 3 Insert the pinhole on the upper part of log 4 into the pin on the left side of log 1. Place the lower part on the flat roof at the left side of log 3 (Figure 5).
