4.3 Parameters of video, access

Video for WEB:
InternetExplorer - (batch JPEG pictures - port 80) is used over and over
again repeated http request ADRESA/video.jpg
Mozilla, opera, Firefox ... and programme PopUp (UDVguard) - (MJPEG
stream - port 80) is used http request ADRESA/video.mjpg (sometimes it
is necessary reload than it start up).This video is continuous and has
smaller load nets.
Stream video for IP phones:
H.263 - IPDPvrátný and videophone settling over SIP/SDP protocol on
standard SIP port and video (also sound) then runs by RTP protocol on
ports settle over SIP (usually 9078).
Parameters of video:
JPG pictures creates in camera and for all transport protocol are same
Size (resolution) of video selects in "Setting video" on WEB
Maximum size is given by type USB camera and mostly is 640x480
Stream H.263 knows only CIF resolution (352x288), so that bigger
JPEG is cuts and smaller will frame
Frequency (1 5obr./sec) JPG pictures selects in "Setting video" on WEB
Frequency MJPG and Stream H.263 comes from camera, will use every
second and result is moves among 7- 12 fig./sec
Ports:
Port 80 for http (WEB pages and JPG (MJPG) video on them)
Port 5060 for SIP
Ports RTP with adverse party reason with over SIP, usually suggests
port 7078 for audio and port 9078 for video
Video port 554 not (yet H264) provided by doorphone (server) protocol
RTSP
Telnet: name: root / password:876
Setup: Default IP address 192.168.1.250
name: admin / password: 1234
