ALPHATECH TECHNOLOGIES s.r.o.
www.alphatechtechnologies.cz
IP BOLD HW reset guide
In case you can´t access the IP BOLD doorphone via web interface, you
need to set HW DIP switch Nr. 2 (the second DIP switch from the left
side) to „ON" position.
This way you will set the IP BOLD to default with IP address
192.168.1.250.
User name: admin
Password: 1234
Please be careful when sliding down the front grill, there is a speaker
connected to the electronic board (PCB), you can break the wiring and
damage some components inside.
Uncareful opening and damaging the PCB will be considered as out of
warranty.
Before you start the reset process, please make sure your PC uses a
static IP address in the same segment of network as the IP BOLD. It
means your PC should not use DHCP, but a static address, for
example 192.168.1.50
Connect the IP BOLD to your PC directly via LAN cable, do not use any
switch or router between your PC and the IP BOLD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP BOLD HW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alphatech IP BOLD HW

  • Page 1 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz IP BOLD HW reset guide In case you can´t access the IP BOLD doorphone via web interface, you need to set HW DIP switch Nr. 2 (the second DIP switch from the left side) to „ON“ position.
  • Page 2 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz...
  • Page 3 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz...
  • Page 4 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz...
  • Page 5 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz...
  • Page 6 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz...
  • Page 7 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz...
  • Page 8 ALPHATECH TECHNOLOGIES s.r.o. www.alphatechtechnologies.cz After you set DIP switch Nr. 2 to „ON“ position, you must turn off the power supply. This means disconnect the power supply, disconnect the LAN cable from your PC. Leave IP BOLD disconnected from any source of power supply for 1 minute.
