Operating System - EUROCOM M5 Pro User Manual

Specifications
Intel® Dual Band Wireless-N 7265 (2*2
802.11 b/g/n) M.2 WLAN
bo M.2 2230 Module (Factory Option)
Intel® Dual Band Wireless-AC 3160 (1*1
802.11 a/c) M.2 WLAN
M.2 2230 Module (Factory Option)
3rd Party Combo WLAN (802.11b/g/n)
and Bluetooth v4.0+LE Combo M.2 2230
Module (Factory Option)
3G UTMS/HSPA+ M.2 3042 Card Module
(Factory Option)
4G LTE M.2 3042 Card Module (Factory
Option)

Operating System

Windows® 8.1 (64-bit)
Features
Al-Alloy Plate
Intel® Rapid Start Technology
Intel® Smart Response Technology
D
Shipping Mode
D - 4 Specifications
Security
+
Bluetooth Com-
Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Reader Module (Factory Option)
+
Bluetooth Combo
Trusted Platform Module 2.0
Power Management
Supports Wake on LAN
Supports Wake on USB
Supports Wake on RTC Alarm
Power
Embedded 4 Cell Polymer Battery Pack
60WH
Full Range AC/DC Adapter – AC in 100 -
240V, 50 - 60Hz DC Output 19.5V, 7.7A
(150 Watts)
Environmental Spec
Temperature
Operating:
Non-Operating: -20°C - 60°C
Relative Humidity
Operating:
Non-Operating: 10% - 90%
Physical Dimensions & Weight
385mm(w) * 271mm(d) * 25mm(h)
2.5kg *Barebone System with 60WH
Battery
*A barebone system does not include the HDD,
RAM, adapter, power cord and factory option
modules (weight tolerance within +/- 5%).
° °
5 C - 35 C
20% - 80%
