Interface (Ports & Jacks)
Item

Headphone-Out Jack

Microphone-In Jack

Mini DisplayPort

RJ-45 LAN Jack

A

S/PDIF-Out Jack

Security Lock Slot

A - 4 Interface (Ports & Jacks)
Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.
Plug an external microphone in to this jack to record on your computer.
The Mini DisplayPort is a miniatuarized version of the DisplayPort, which is a digital display
interface standard that allows a digital audio/video interconnect, between the computer and its
external display or a home-theater system.
This port supports LAN (Network) functions.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-
capable PC to a Dolby AC-3 compatible receiver for "5.1" or 'dts' surround sound.
To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be
purchased at any computer store.
Description
