Usb 3.0 Port; Powered Usb 3.0 Port - EUROCOM M5 Pro User Manual

Interface (Ports & Jacks)
Item Description

USB 3.0 Port

These USB ports are for low-speed peripherals such as keyboards, mice or scanners, and for
high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners
3.
etc. Devices can be plugged into the computer, and unplugged from the computer, without the
0

Powered USB 3.0 Port

need to turn the system off (if the power rating of your USB device is 500mA or above, make sure
you use the power supply which comes with the device).
3.
0
The USB 3.0 ports are denoted by their blue color and are backwards-compatible with USB 2.0.
The powered USB 3.0 port (see may be toggled on /off by
)
Figure 1 - 10 on page 1 - 18
Note:
means of the Fn + Power Button key combination. When the powered USB port is on it will supply
power (for charging devices only, not for operating devices) when the system is off but still
powered by the AC/DC adapter plugged into a working outlet, or powered by the battery with a
capacity level above 20% (this may not work with certain devices - see page
7 - 11).
A
Note: This function is designed to help charge USB compliant devices, but is not designed to
allow their operation.
Interface (Ports & Jacks) A - 5
