Bios - EUROCOM M5 Pro User Manual

Two M.2 2280 SSDs with SATA (Serial)
Interface (RAID 0/1) (Factory Option)
OR
One M.2 2280 SSD with PCIe Gen2 x2/
x4 Interface (Factory Option)

BIOS

One 48Mb SPI Flash ROM
AMI BIOS
Audio
High Definition Audio
S/PDIF Digital Output
Built-In Array Microphone
2 Built-In 2W Speakers
Sound Blaster® X-Fi® MB3
External 51CH Audio output supported by
headphone, microphone & S/PDIF Jacks
ANSP™ 3D Sound Technology on
Headphone Output
Keyboard & Pointing Device
Full Size Winkey Illuminated White-LED
Keyboard with Numeric Keypad
Built-In TouchPad (with Multi Gesture &
Scrolling Functionality)
W/A/S/D Game Key Markings
Indicators
LED Indicators - Power/Suspend, Battery,
HDD, Airplane Mode, GPU Mode, Num
Lock, Caps Lock, Scroll Lock, Camera
Interface
Three USB 3.0 Ports (Including one
powered USB3.0 AC/DC port)
One eSATA Port (SATA USB 3.0 Combo)
Two Mini Display Ports 1.2
One HDMI™ (High-Definition Multimedia
Interface) Out Port (with HDCP)
One Microphone-In Jack
One Headphone/Speaker-Out Jack
One S/PDIF Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
- MMC / RSMMC
- SD / Mini SD / SDHC / SDXC
Specifications
Card Reader Note: Some of the cards
require PC adapters that are usually
supplied with the cards.
Slots
Three M.2 Slots:
=======================================
Slot 1: for M.2 2230 WLAN Combo Module
Card with PCIe & USB Interfaces
Slot 2: for M.2 2280 SSD Card with SATA /
PCIe Gen2 x2/x4 Interface
Slot 3: for M.2 2280 SSD Card with SATA
Interface
OR
LTE/HSPA+ M.2 3042 3G or 4G Module
Card with USB Interface
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
2.0M FHD PC Video Camera Module
Intel® Dual Band Wireless-AC 7265 (2*2
802.11 a/c) M.2 WLAN + Bluetooth Combo
M.2 2230 Module (Factory Option)
See over
Specifications D - 3
