Specifications

Communication (Cont'd)

Bluetooth v2.1 + EDR (Enhanced Data
Rate) Module (Factory Option)
1.3M Pixel PC Camera Module with USB
interface
UMTS/HSPDA-based 3.75G Module with
USB Mini-Card Interface (Factory Option
for Model A Computers)
Quad-band GSM/GPRS (850 MHz, 900
MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Note that UMTS modes CAN NOT be
used in North America

Power Management

Supports Wake on LAN
Supports Wake on USB (Not Supported
by the USB 3.0 Port)
Supports Resume from Modem Ring
C
C - 4 Specifications

Power

Full Range AC/DC Adapter
AC input 100 - 240V, 50 - 60Hz,
DC Output 19V, 4.74A (90 Watts)
Removable 6 Cell Smart Lithium Ion Battery
Pack 48.84WH
Removable 6 Cell Smart Lithium Ion Battery
Pack 62.16WH (Factory Option)

Security

Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Security (Factory Option for
Model A Computers)

Operating System

Windows® 7

Design Feature

MOFA II (Magic Of Film Art) Changeable
LCD Back Covers (Model A Computers
Only)

Environmental Spec

Temperature
° °
Operating: 5 C - 35
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
Model A:
374mm (w) * 250mm (d) * 25 - 37.2mm (h)
2.6 kg with ODD & 48.84WH Battery
Model B:
413mm (w) * 277.5mm (d) * 25.1 - 38.9mm
(h)
3.1 kg with ODD & 48.84WH Battery
C
