EUROCOM M5 Pro User Manual page 140

Modules
6
Figure 6 - 3
Select Disks
(Advanced > Intel(R)
Rapid Storage
Technology)
6 - 6 Setting Up SATA RAID or AHCI Mode
13. Go to RAID Level: and press <Enter>.
14. Choose the RAID Level required (see
press <Enter>.
• RAID0 (Stripe)
• RAID1 (Mirror)
• Recovery
15. Go to any of the disks listed under Select Disks: and select a disk name and
press <Enter>.
16. Move the cursor down (use the arrow keys) onto to X (o select the disk required
and press <Enter>.
• If you have selected a Recovery level RAID then you need to select one disk to
be Master disk (M) and one disk to be the Recovery disk (R)
For Recovery
For Stripe or Mirror
Table 6 - 1, on page 6 - 3
for details) and
