5. Plug in the speaker cables (you may require an adapter to connect each cable to
the appropriate jack e.g a stereo mini to dual RCA adapter) from your speakers
into the jacks as follows:
• Headphone-Out Jack = Side Speaker Out
• Microphone-In Jack = Center/Subwoofer Speaker Out
• S/PDIF-Out Jack = Front Speaker Out
6. As you plug in each cable a dialog box will pop up (see
page 2 - 6).
7. Click to put a check in the appropriate box according to the speaker plugged-in
(e.g. Rear Speaker Out), and then click OK to save the setting.
8. Click OK to exit Realtek HD Audio Manager.
Storage Devices, Mouse, & Audio
"Auto Popup Dialog" on
Audio Features 2 - 7
