  • Page 1 MICRON ™ ClientPro PCI-Bus System User's Manual P/N MAS001377-00 03/97 Micron Electronics, Inc.

  • Page 2: Copyright And Trademarks

    Micron Electronics, Inc. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Safety Information

    AC power outlet does not exceed 15 amps. Unplug your product from the main electrical power outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 10. Do not use this product near water. Micron Electronics, Inc.

  • Page 4: Battery Warning

    11. Unplug this product from the main power outlet and call for service under any of the following conditions: A. If the power cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D.
  • Page 5 Note: Shielded interface cables must be used in order to comply with the emission limits. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authorization to operate the equipment. Micron Electronics, Inc.

  • Page 6: Declaration Of Conformity

    A "Declaration of Conformity" for each system can be found on file at any authorized European Micron Dealer/Distributor. For a list of authorized dealers/distributors, please contact Micron Electronics, Inc. at 208-893-8970. When requesting a "Declaration of Conformity," please refer to the FCC ID number on the system label.

  • Page 7: Table Of Contents

    How to Run the Setup Program ................ 3-3 Exit/Saving the CMOS Selections ..............3-22 Chapter 4 Common Problems Introduction ......................4-2 Appendix A: Contacting Technical Support Appendix B: Beep Codes and Error Messages Appendix C: Glossary Appendix D: Micron Power Warranty Micron Electronics, Inc.

  • Page 8: Setting Up Your System

    Maintenance ................1-12 Operating Environment ..................1-12 Transporting ..................... 1-12 Cleaning ......................1-12 Protecting ......................1-13 Backing Up ....................... 1-13 Removing the System Cover ............ 1-14 Desktop Case ....................1-14 Mini Tower Case ....................1-15 Tower Case ...................... 1-17 Micron Electronics, Inc.

  • Page 9: Unpacking

    Now that you have everything out of the packages, take the time to check the packing list to be sure you received everything. If you discover that an item is missing, call Micron Electronics, Inc. immediately to receive a replacement. Refer to Appendix A for contact information.

  • Page 10: Setup

    Setup Getting Started Before your new system left the factory, Micron configured the hardware. The display adapter was set to work with your monitor and the hard disk was partitioned and formatted with DOS using the standard default settings for your machine. Your computer system is ready to go.
  • Page 11 Micron ClientPro X User's Guide 7. Find the video cable and attach the appropriate end into the monitor (if not already attached) and attach the other end into the video connector (located in one of the expansion slots at the rear of the unit). If the connection is loose on either end, tighten the integrated screws at both ends of the cable for a secure connection.
  • Page 12 Chapter 1: Setting Up Your System Figure 1-1. Desktop Case-Front Micron Electronics, Inc.
  • Page 13 Micron ClientPro X User's Guide Figure 1-2. Desktop Case-Rear Micron Electronics, Inc.
  • Page 14 Chapter 1: Setting Up Your System Figure 1-3. Mini Tower Case-Front Micron Electronics, Inc.
  • Page 15 Micron ClientPro X User's Guide Figure 1-4. Mini Tower Case-Rear Micron Electronics, Inc.
  • Page 16 Chapter 1: Setting Up Your System Figure 1-5. Tower Case-Front Micron Electronics, Inc.
  • Page 17 Micron ClientPro X User's Guide Figure 1-6. Tower Case-Rear 1-10 Micron Electronics, Inc.

  • Page 18: Running Your System For The First Time

    Chapter 4, "Common Problems." Turning Off Your System Micron recommends that you power down your system in the following order: 1. Exit all applications you are running and save any changes. 2. Make sure that ALL disk activity has completely stopped. The floppy and hard drive indicator lights should be off and the floppy drive motors should be stopped.

  • Page 19: Maintenance

    Maintenance Operating Environment Your Micron computer has been manufactured to the highest standards. With proper care, it should provide years of trouble-free service. To ensure that your system has the longest life possible, it should be placed in an area with good ventilation and low humidity, out of direct sunlight and away from heat sources or lamps.

  • Page 20: Protecting

    Any of these alternatives are highly recom- mended. Complete, frequent backups can save years of data from total and irretrievable destruction. If you require additional information about backup systems or options, please contact Micron Electronics, Inc. Micron Electronics, Inc. 1-13...

  • Page 21: Removing The System Cover

    Micron ClientPro X User's Guide Removing the System Cover Desktop Case Refer to the Figures below. No tools are required. It is not necessary to disconnect the cable connectors on the back of the computer before opening the cover. However, note where the cables connect to the back for future reference .

  • Page 22: Mini Tower Case

    To replace the cover, gently lower the top latching hooks into the top chassis channels before pushing the rear of the cover into place. When the cover is pushed forward the flexiable release tabs will lock into place and the thumb screw can be fully tightened. Micron Electronics, Inc. 1-15...

  • Page 23: Tower Case

    Micron ClientPro X User's Guide Tower Case Refer to the Figure on the following page. Use a #2 phillips-head screwdriver or a1/4" hex driver. 1. It is not necessary to disconnect the cable connectors on the back of the computer before opening the cover. However, note where the cables connect to the back for future reference .
  • Page 24 Chapter 1: Setting Up Your System Figure 1-7. Tower Cover Removal Micron Electronics, Inc. 1-17...

  • Page 25: Technical Information

    Memory ....................... 2-3 System Board ................2-4 Jumper Settings ................2-6 Configuration ...................... 2-6 Installing Add-On Peripherals ................2-9 SIMM Modules ................2-11 Installing SIMM Modules .................. 2-12 Removing SIMM Modules ................2-14 DRAM Memory ....................2-15 Micron Electronics, Inc.

  • Page 26: Overview

    Micron ClientPro X User's Guide Overview Micron's ClientPro X system board is a high-performance system board designed to be the basis for your personal computer or workstation. The ClientPro X is based on the PCI local bus and the Intel 440FX chip set.

  • Page 27: Memory

    When installing SIMMs, start with bank 0. Refer to the section entitled "SIMM Modules" on page 2-11 for more informa- tion on upgrading your memory. Questions and purchases for memory expansion may be directed to Micron Memory Module sales (1-800-438-3343). Micron Electronics, Inc.

  • Page 28: System Board

    Micron ClientPro X User's Guide System Board Figure 2-1. ClientPro X System Board Micron Electronics, Inc.
  • Page 29 Chapter 2: Technical Information Figure 2-2. I/O Plate Connectors Figure 2-3. System Front Panel I/O Connectors Micron Electronics, Inc.

  • Page 30: Jumper Settings

    User's Guide Jumper Settings Configuration The jumpers on the Micron ClientPro X are preset at the factory and in most cases do not need to be changed. However, if certain functions need to be changed, the jumpers may need to be reconfigured. Figure 2-4. shows an example of a jumper.
  • Page 31 Chapter 2: Technical Information Figure 2-5. CPU Speed Selection Figure 2-6. CMOS Configuration Selection Micron Electronics, Inc.
  • Page 32 Micron ClientPro X User's Guide Figure 2-7. Connectors Micron Electronics, Inc.

  • Page 33: Installing Add-On Peripherals

    4. Holding the card at the center of the top edge, gently push straight in. Do not force the card into place. If it does not fit, take it out and try again. 5. Make sure the card is fully inserted. 6. Secure the card with a bracket screw. Micron Electronics, Inc.
  • Page 34 Micron ClientPro X User's Guide Figure 2-8. Installing a PCI Local Bus Card NOTE: The ISA slot (J1C1) and the PCI slot (J2D1) are “shared slots.” When a PCI card is installed into the (J2D1) PCI slot, the ( J1C1) ISA slot is disabled. Conversely, when a peripheral card is installed into the (J1C1) ISA slot, the (J2D1) PCI slot is disabled.

  • Page 35: Simm Modules

    3. Keep body movement to a minimum as you remove and handle the modules. Antistatic wrist straps with clip-on ends are commercially available. Micron Electronics, Inc. 2-11...

  • Page 36: Installing Simm Modules

    Micron ClientPro X User's Guide Installing SIMM Modules The ClientPro X has four, 36-bit (72-pin) SIMM sockets on-board and can accommo- date memory from 8MB up to 128MB using the following SIMM sizes: 4MB - organized as 1MB x 32 or 1MB x 36...
  • Page 37 The module should now be standing upright in the socket . WARNING: Failure to observe proper insertion guidelines may result in damage to the SIMM and/or the socket. Correct Incorrect Figure 2-9. Handling a SIMM Figure 2-10. Proper SIMM Insertion Micron Electronics, Inc. 2-13...

  • Page 38: Removing Simm Modules

    Micron ClientPro X User's Guide Alignment hole Keyed Post peg Notch Be sure the module is centered When the module has been and connector pins are aligned and locked in place, be sure both FULLY SEATED. silver tabs on each side of the socket are fully closed.

  • Page 39: Dram Memory

    Chapter 2: Technical Information DRAM Memory The following table lists the possible memory size combinations usable for the installation of SIMMs. Figure 2-12. DRAM Memory Configuration Micron Electronics, Inc. 2-15...

  • Page 40: The Bios Setup Program

    When Setup Should be Run ................3-2 How to Run the Setup Program ..........3-3 Setting the CMOS Main Screen ................. 3-5 Setting the CMOS Advanced Screen .............. 3-11 Setting the CMOS Security Screen ..............3-22 Exiting/Saving the CMOS Selections ........3-24 Micron Electronics, Inc.

  • Page 41: Setup

    CMOS. The Setup Program has been built into the system to provide the means for changing the CMOS. When Setup Should Be Run Although the Micron ClientPro X arrives fully configured, the system may need to be adjusted to fit your needs.

  • Page 42: How To Run The Setup Program

    When “Press <F1> to enter SETUP” appears at the bottom of the screen, press the <F1> key to begin the Setup procedure. The CMOS Main Screen (Figure 3-2) should appear and the prompt should be on the System Date line. The Setup procedure can only be activated during the boot sequence. Micron Electronics, Inc.
  • Page 43 Advanced Chipset Configuration Power Management Configuration Plug and Play Configuration Event Logging Configuration Security Exit Each screen configures specific parameters for the ClientPro XVI system board. The following section is an overview of each screen and its functions. Micron Electronics, Inc.

  • Page 44: Setting The Cmos Main Screen

    Figure 3-2. Main Screen System Date and Time Specifies the current date. Select the month from a pop-up menu. System Time Specifies the current time. Micron Electronics, Inc.
  • Page 45 Micron ClientPro X User's Guide Floppy Options When selected, this pops up the Floppy Options menu. Floppy Options Subscreen Floppy A: Reports if a diskette drive is connected to the system. There are no options. Floppy B: Reports if a second diskette drive is connected to the system. There are no options.
  • Page 46 If Hard Disk Type is set to User Definable, you must type the correct number of heads for your hard disk. If Hard Disk Type is set to Auto Configured, this reports the number of heads for your hard disk and cannot be modified. Micron Electronics, Inc.
  • Page 47 Micron ClientPro X User's Guide Number of Sectors If Hard Disk Type is set to User Definable, you must type the correct number of sectors for your hard disk. If Hard Disk Type is set to Auto Configured, this reports the number of sectors for your hard disk and cannot be modified.
  • Page 48 Boot Speed Sets the system’s boot speed. The options are Deturbo and Turbo. The default is Turbo. If Turbo is selected, boot-up occurs at full speed. If Deturbo is selected, the board operates at a slower speed. Micron Electronics, Inc.
  • Page 49 Micron ClientPro X User's Guide Num Lock Sets the beginning state of the Num Lock feature on your keyboard. The options are On and Off. Speaker Turns the on-board speaker control to on or off. The options are Enabled and Disable.

  • Page 50: Setting The Cmos Advanced Screen

    Cache Size Reports the size of the secondary cache. There are no options. If your system contains no L2 cache, this item will not appear. Peripheral Configuration When selected, this brings up the Peripheral Configuration subscreen. Micron Electronics, Inc. 3-11...
  • Page 51 Micron ClientPro X User's Guide Figure 3-6. Perpherial Configuration Screen Primary and Secondary IDE Interface Enables or disables the PCI IDE hard disk interface. The options are Enabled and Disabled. Floppy Interface Enables or disables the diskette drive interface. The options are Enabled and Disabled.
  • Page 52 This option is not affected by the Configuration Mode field above. Peripheral Status Reports Displays the current status of the various periphrals from the selectable settings above. These are informational fields and are not accessible. There are no options. Micron Electronics, Inc. 3-13...
  • Page 53 Micron ClientPro X User's Guide Figure 3-7. Advanced Chipset Configuration Screen Advanced Chipset Configuration Base Memory Size Sets the size of the base memory. The options are 512 KB and 640 KB. ISA LFB Size Sets the size of the linear frame buffer. The options are Disabled and 1 MB. If this is set to 1 MB, then the ISA LFB Base Address field will appear.
  • Page 54 Reports the type of memory found in the bank 0 SIMM slots. There are no options. Bank 1 SIMM Detected Reports the type of memory found in the bank 1 SIMM slots. There are no options. Micron Electronics, Inc. 3-15...
  • Page 55 Micron ClientPro X User's Guide Power Management Configuration The Power Management Screen (Figure 3-8) provides the control of system power usage when APM (Advanced Power Management) software is active. Figure 3-8. Advanced Power Management Screen Advanced Power Management Enables or disables the Advanced Power Management (APM) support in your system’s BIOS.
  • Page 56 This option is only available when Auto Start is Enabled. Enables the system to power on upon an incoming POTS call to a telephony device configured for operation on COM1. The options are Disabled and Enabled. Micron Electronics, Inc. 3-17...
  • Page 57 Micron ClientPro X User's Guide Figure 3-9. Plug and Play Configuration Screen Plug and Play Configuration Configuration Mode Sets how the BIOS gets information about ISA cards that do not have Plug and Play capabilities. The options are Use Setup Utility and Use ICU (ISA Configuration Utility).
  • Page 58 Used By ISA Card for that interrupt. NOTE Some of the IRQ's may not be available in this option, depending on the setting chosen for the COM1, COM2 and parallel ports in the Peripheral Configuration Subscreen. Micron Electronics, Inc. 3-19...
  • Page 59 Micron ClientPro X User's Guide Event Logging Configuration Figure 3-10. Event Logging Configuration Screen Event Logging Configuration Screens Event Log Status Advises the user if the event log has been corrupted or not. Log Capacity Advises the user if there is available space for additional logs.
  • Page 60 Multiple Bit ECC Errors This shows the number of multiple bit ECC that occurred in memory, if any. Post Errors This shows how many POST (Power On Self Test) errors that occurred. Micron Electronics, Inc. 3-21...

  • Page 61: Setting The Cmos Security Screen

    Micron ClientPro X User's Guide Setting the CMOS Security Screen The Security Screen (Figure 3-11) controls access to the computer. The security screen allows for settings of two passwords. The Administrative Password allows access to the system and Setup. The User Password will allow access to the system, but not to all Setup features.
  • Page 62 Sets a hot key that, when pressed, locks the keyboard until the User password is entered. The Keyboard LEDs flash to indicate that the keyboard is locked. When you enter the User password, you do not have to press the <Enter> key. Micron Electronics, Inc. 3-23...

  • Page 63: Exiting/Saving The Cmos Selections

    Micron ClientPro X User's Guide Exiting/Saving the CMOS Selections After you have completed configuring the BIOS, select the Exit Screen (Figure 3-12), and choose one of the following options. Figure 3-12. Exit Screen Exit Saving Changes Saves the changes to CMOS RAM and exits the Setup program. You can also press the <F10>...

  • Page 64: Common Problems

    Chapter 4: Common Problems Chapter 4 Common Problems Introduction ................. 4-2 Problems During Boot ..................4-2 System Problems ....................4-6 Hard Disk Problems ................... 4-9 Micron Electronics, Inc.

  • Page 65: Introduction

    If you continue to experience problems and this section fails to provide solutions, please feel free to contact Micron technical support (see Appendix A: Contacting Technical Support). Problems During Boot Problem When the power switch is turned on, the system does not power up (i.e., the...
  • Page 66 After this has been completed, contact Micron technical support for further assistance. Contact Micron technical support if none of the above procedures is effective. Micron Electronics, Inc.
  • Page 67 Micron ClientPro X User's Guide Problem System powers on, the display works, but the system does not complete the boot process or you see one of the following error messages: “Hard disk Controller Failure.” “Fixed Disk Configuration Error.” “Operating System Not Found.”...
  • Page 68 CMOS). Insert the DOS or Windows 95 Boot Diskette provided with your Micron system and either reset or power on your system with the disk in the floppy drive. If you boot to a setup utility, exit out so that your computer is at the A: prompt.

  • Page 69: System Problems

    Typically, Micron computers are provided with a 1.44MB 3.5" floppy drive. An attempt may have been made to format a low- density disk in one of the Micron high-density floppy drives. Solution Please refer to the DOS manual for more information about how to format low-density diskettes in high-density floppy drives.
  • Page 70 If it does, try reinstalling the video drivers specific to your video card that shipped with your system, or check the Micron Electronics Internet Site for updated video drivers. Micron Electronics, Inc.
  • Page 71 Micron ClientPro X User's Guide Problem After installing a new peripheral card, an unrelated part of the system suddenly stops working. Possible Cause The new card may be attempting to use some of the same system resources, such as address space, I/O ports, interrupt lines, etc., and may be conflicting with the failing part of the...

  • Page 72: Hard Disk Problems

    Do not attempt to low-level format the drive! If the drive cannot be formatted, either the drive or the controller may be defective. Contact Micron technical support. Problem System has to be booted from a floppy disk. Hard disk is completely functional, but cannot be used for boot-up.
  • Page 73 Micron ClientPro X User's Guide Problem Read/write, sector, data, or seek errors occur when attempting to access files on the hard drive. Possible Cause The format may be fading. The hard drive may be developing media errors. The file allocation table may be corrupted.

  • Page 74: Appendix A: Contacting Technical Support

    4. Write down all error information you can remember, including error messages, software used (with version numbers), and so We hope Micron Technical Support will be able to solve your problem over the telephone. However, in some extreme cases your system may need to be returned to Micron Electronics, Inc.
  • Page 75 User's Guide Returning Equipment to Micron Electronics If it is determined that your system needs to be returned to Micron for repair or replacement, please observe the rules listed below. Failure to follow any of these rules may result in long delays in repair or the simple return of the system without repair.

  • Page 76: Appendix B: Beep Codes And Error Messages

    Appendix B: Beep Codes and Error Messages Beep Codes and Error Messages POST (Power On Self Test) has two kinds of messages: Beep Codes and Error Messages. The following tables list these messages and explanations. BIOS Beep Codes Table B-1. Beep Codes Micron Electronics, Inc.
  • Page 77 Micron ClientPro X User's Guide BIOS Error Messages Table B-2 BIOS Error Messages Micron Electronics, Inc.
  • Page 78 Appendix B: Beep Codes and Error Messages BIOS Error Messages Table B-2 BIOS Error Messages (continued) Micron Electronics, Inc.

  • Page 79: Appendix C: Glossary

    DOS: See “Operating System.” DRAM: Dynamic Random Access Memory. Memory that requires a periodic refresh cycle to keep the stored information from being lost. Loss of power causes loss of data in this memory. Micron Electronics, Inc.
  • Page 80 Micron ClientPro X User's Guide EISA: Extended Industry Standard Architecture. Expansion Slot: A connector on the motherboard for holding a peripheral card. Floppy Disk: A 3.5 inch or 5.25 inch removable storage medium used for storing programs and files externally from the computer system.
  • Page 81 RAM: Random-Access Memory. The type of computer memory that can be used to store information while a program is running. RAM consists of a number of small integrated circuits that are plugged into the system board or an external memory card. Micron Electronics, Inc.
  • Page 82 Micron ClientPro X User's Guide ROM: Read-Only Memory. The type of computer memory that is used to permanently store the information vital to computer operation, including some parts of the operating system. ROM is permanent and the contents will not be lost when the computer is turned off.

  • Page 83: Appendix D: Micron Power

    FIVE-YEAR LIMITED WARRANTY Micron Electronics, Inc. (Micron) warrants that the microprocessor and main memory included in the new product sold by Micron will be free from defects in materials and workmanship for five (5) years from date of shipment by Micron.
  • Page 84 Purchase Order to cover the replacement cost of the part at the time you obtain the RMA number. Micron will process this charge only if you fail to return the defective part at your expense within ten (10) business days from the date you obtain the RMA number.
  • Page 85 Terms of Limited Warranties and other Terms set forth herein, you may return the product(s) to Micron for a full refund of the purchase price paid (less any restocking charge for opened software). This policy does not include payment by Micron for original or return shipping and handling charges.
  • Page 86 THESE LIMITED WARRANTIES ARE INCORPORATED INTO AND ARE ESSENTIAL AND MATERIAL PROVISIONS OF THE TERMS AND CONDITIONS OF SALE OF NEW MICRON PRODUCTS TO YOU (SALE TERMS). ALL DISPUTES ARISING OUT OF OR RELATED TO THE LIMITED WARRANTIES SET FORTH HEREIN (CUS- TOMER DISPUTES) SHALL BE GOVERNED BY THE LAWS OF THE STATE OF IDAHO.
  • Page 87 Micron also warrants that the hardware other than the microprocessor and main memory (but not the software) included in the new product sold by Micron will be free from defects in materials and workmanship for three (3) years from the date of shipment by Micron.
  • Page 88 Purchase Order to cover the replacement cost of the part at the time you obtain the RMA number. Micron will process this charge only if you fail to return the defective part at your expense within ten (10) business days from the date you obtain the RMA number.
  • Page 89 Please retain your shipping information, including tracking numbers, until your amount has been credited by Micron. This will serve as your proof of return. Upon receipt by Micron and verification that the product(s) have not been damaged or altered, Micron will provide you with a full refund (less any restocking charge for opened software).
  • Page 90 THESE LIMITED WARRANTIES ARE INCORPORATED INTO AND ARE ESSENTIAL AND MATERIAL PROVISIONS OF THE TERMS AND CONDITIONS OF SALE OF NEW MICRON PRODUCTS TO YOU (SALE TERMS). ALL DISPUTES ARISING OUT OF OR RELATED TO THE LIMITED WARRANTIES SET FORTH HEREIN (CUS- TOMER DISPUTES) SHALL BE GOVERNED BY THE LAWS OF THE STATE OF IDAHO.
