Figure 9: System LEDs

1
System Status LEDs.
Task 5
Make Initial Configuration Changes
At this point you may need to make a few basic switch configuration changes
before connecting to the network. It is suggested to connect to the switch console
port to perform this task.
The serial port's configuration requirements are as follows: 9600 bps, 8 characters,
no parity, one stop bit, 8 data bits, and no flow control.
You can log in to the command-line interface (CLI) using default settings: User
"admin" with no password.
Go to

Figure 10: Console Port

1
Console Port
"How to Connect to the Console Port"
– 21 –
Chapter 2
| Installation Overview
Switch Installation Tasks
1
1
