Connection Procedure
How to Connect to SFP/SFP+ Fiber Optic Ports
Table 5: 1000BASE-T MDI and MDI-X Port Pinouts (Continued)
Pin
MDI Signal Name
3
Bi-directional Pair B Plus (BI_DB+)
4
Bi-directional Pair C Plus (BI_DC+)
5
Bi-directional Pair C Minus (BI_DC-)
6
Bi-directional Pair B Minus (BI_DB-)
7
Bi-directional Pair D Plus (BI_DD+)
8
Bi-directional Pair D Minus (BI_DD-)
1000BASE-T Cable Requirements
All Category 5 UTP cables that are used for a 100BASE-TX connection should also
work for 1000BASE-T, providing that all four wire pairs are connected. However, it is
recommended that for all critical connections, or any new cable installations,
Category 5e (enhanced Category 5) or Category 6 cable should be used. The
Category 5e and 6 specifications include test parameters that are only
recommendations for Category 5. Therefore, the first step in preparing existing
Category 5 cabling for running 1000BASE-T is a simple test of the cable installation
to be sure that it complies with the IEEE 802.3-2008 standards.
To make a connection to the switch's management port follow the procedure
described in
"How to Connect to the Management Port" on page
The switch provides 48 slots for SFP/SFP+ fiber-optic transceivers. Note that all 10G
SFP+ fiber optic ports operate at 10 Gbps full duplex. All 1000 Mbps SFP fiber optic
ports operate at 1 Gbps full duplex.
Table 6: Maximum 10 Gigabit Ethernet Fiber Cable Lengths
Fiber Size
10GBASE-SR
62.5/125 micron multimode
62.5/125 micron multimode
50/125 micron multimode
50/125 micron multimode
50/125 micron multimode
10GBASE-LR
9/125 micron single-mode
How to Connect to SFP/SFP+ Fiber Optic Ports
MDI-X Signal Name
Bi-directional Pair A Plus (BI_DA+)
Bi-directional Pair D Plus (BI_DD+)
Bi-directional Pair D Minus (BI_DD-)
Bi-directional Pair A Minus (BI_DA-)
Bi-directional Pair C Plus (BI_DC+)
Bi-directional Pair C Minus (BI_DC-)
Fiber Bandwidth
Maximum Cable Length
160 MHz/km
2-26 m (7-85 ft.)
200 MHz/km
2-33 m (7-108 ft.)
400 MHz/km
2-66 m (7-216 ft.)
500 MHz/km
2-82 m (7-269 ft.)
2000 MHz/km
2-300 m (7-984 ft.)
N/A
10 km (6.2 miles)
– 39 –
Chapter 5
| Port Connections
49.
Connector
LC
LC
LC
LC
LC
LC
