Edge-Core ECS5550-30X Quick Start Manual

Quick Start Guide
Ethernet Switch
ECS5550-30X | ECS5550-54X
1.
Ethernet Switch ECS5550-30X or ECS5550-54X
2.
Rack mounting kit—2 front-post brackets, 2 rear-post brackets,
and 16 screws
3.
AC power cord
1
2
5
6
1.
Management Ports: 1000BASE-T RJ-45, RJ-45 console, USB
2. System LEDs
3.
24 or 48 x 10G SFP+ ports
4.
6 x 100G QSFP28 ports
SYS: Green (OK), Flashing Green (booting), Yellow (fault)
MST: Green (stack master)
STACK: Green (stack mode)
FAN: Green (OK), Yellow (fault)
PSU: Green (OK), Yellow (fault)
FRU Replacement
PSU Replacement
1. Remove the power cord.
2.
Press the release latch and
remove the PSU.
3.
Install replacement PSU with
matching airflow direction.

Package Contents
1
3
7
System LEDs/Buttons
Fan Tray Replacement
1. Press the release latch in the
fan tray handle.
2.
Remove fan tray from the
chassis.
3.
Install replacement fan with
matching airflow direction.
2 3
4.
Console cable—RJ-45 to DE-9
5.
Grounding wire
6.
Documentation—Quick Start Guide (this document) and Safety
and Regulatory Information
Overview
4 1
2
5
5.
Grounding screw (maximum torque 10 kgf-cm (8.7 lb-in))
6. 4 x fan trays
7.
2 x AC PSUs
SFP+ 10G LEDs: Green (10G), Orange (1G or 2.5G)
QSFP28 LEDs: Green (100G or 40G)
– 1 –
www.edge-core.com
4 5
3
6
6
4
7
E012025-CS-R01
150200002699H
