Vsm - GeoVision GV-Compact DVR V2 User Manual

11.2 VSM

The VSM can monitor and manage the cameras and I/O devices connected to the GV-
Compact DVR V2.
To set the appropriate port connecting to the GV-Compact DVR V2, click Configure on
the window menu, and select System Configure to display this dialog box. Under the
Connective Port, keep the default Port 2 value of 5609, or modify it to match the VSM
port on the GV-Compact DVR V2.
Figure 11-5
For further information on how to mange the received video from the GV-Compact DVR V2,
see GV-CMS Series User's manual.
X 4
X 4
GV-Compact DVR
X 4
X 4
GV-Compact DVR
Figure 11-4
CMS Configurations
11
TCP/ IP
Text Data
VSM
143
