3.5 Main Screen Overview

1. Date and time: Indicates the current date and time when viewing live video.
2. A / B / C: Indicates the type of device defined for GV-Compact DVR V2 Remote Control.
3. Monitoring icon
4. Manual recording icon
recording is started manually or by schedule.
5. Input icon : Appears when the input device is installed and activated.
6. Channel number/Camera name: Displays the camera number or name.
7. Hard disk status: Indicates the amount of free space on the hard disk. When the disk is
full, the status will turn to red.
8. Motion icon : A red icon indicates movement occurs in the video image. A white icon
indicates no movement detected.
9. Motion detection mode icon
of motion detection.
18
Figure 3-8
: Appears when the monitoring is activated.
or Schedule recording icon
: Appears when the camera is set to the recording mode
: Appears when the
