GV-DVR SYSTEM
GV-2016S/2008S/1480S/1240S/1120S
•
Recovery DVD in case of system failure
•
Operates on Windows XP Embedded
•
GV-Keyboard and GV-IR Remote Control included
•
Latest surveillance software preinstalled and upgradeable
•
User-friendly software interface
•
Built-in 4 Inputs and 4 Outputs
•
Available in 14 languages
•
Compatible with GeoVision optional products
•
Complete product information and testing reference
•
Global warranty
•
FCC/CE/RoHS/WEEE certification
S Series Datasheet
(S Series)
1
Update: Feb./9/2007
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GeoVision GV-2016S
Summary of Contents for GeoVision GV-2016S
- Page 1 Latest surveillance software preinstalled and upgradeable • User-friendly software interface • Built-in 4 Inputs and 4 Outputs • Available in 14 languages • Compatible with GeoVision optional products • Complete product information and testing reference • Global warranty • FCC/CE/RoHS/WEEE certification S Series Datasheet...
- Page 2 480 FPS (NTSC) / 400 FPS (PAL) display rate. Max. Resolutions can reach full D1 on the model of GV-2008S or GV-2016S to fulfill high-profile security environment needs. Flexible combinations of specifications and accessories are provided to meet any installation need, e.g.
- Page 3 Models • Sixteen-channel digital video recorder • Records up to 480 (NTSC) / 400 (PAL) fps at D1 resolution GV-2016S • 1600 GB / 2000 GB / 3000 GB storage • Eight-channel digital video recorder • Records up to 240 (NTSC) / 200 (PAL) fps at D1 resolution GV-2008S •...
-
Page 4: Front View
Front View 5.25” Hard Disk Compartment Power Switch Power LED Reset Button Hard Drive Activity LED Key Lock RW Drive USB Port x 2 ± Fan x 2 S Series Datasheet Update: Feb./9/2007... -
Page 5: Rear View
Rear View GV-1480S/1240S/1120S Ethernet Port RJ-11 Port LPT Parallel Printer Port Alarm Output x 4, Audio Microphone In Port DB-9 Serial Input Sensor Input x 4 D-Type Audio Port x 2 Audio Line In Port PS/2 Mouse Input RCA TV Output Audio Speaker Out Port PS/2 Keyboard Input D-Type Video Port x 2... - Page 6 RS-485 for PTZ Control D-Type Audio and Video Cable 1-4 RJ-11 Port D-Type Audio and Video Cable 5-8 GV-2016S Alarm Output x 4, Sensor Input x 4 D-Type Audio and Video Cable 5-8 RS-485 for PTZ Control D-Type Audio and Video Cable 9-12...
-
Page 7: Basic System Specifications
Basic System Specifications Model GV-2016S GV-2008S GV-1480S GV-1240S GV-1120S Motherboard Intel 945G Chipset or above Intel Pentium 3.0GHz, 800MHz FSB or above 512MB Dual Channel Dual Channel Dual Channel HDD * 1600GB 1200GB 900GB 600GB 300GB 2000GB 1600GB 1200GB 1200GB... - Page 8 Video Model GV-2016S GV-2008S GV-1480S GV-1240S GV-1120S Video Standard NTSC, PAL Video Input 16 channels 8 channels 16 channels 8/16 channels 16 channels Input Level 1.0 Vp-p (± 10%) composite, 75 Ω TV Output 1.0 Vp-p composite S/W: Geo MPEG4 / Geo Mpeg4...
-
Page 9: Remote Client Software
Recording Model GV-2016S GV-2008S GV-1480S GV-1240S GV-1120S H/W: H/W: S/W: S/W: S/W: Recording NTSC 480 (D1) 240 (D1) 480 (CIF) 240 (CIF) 120 (CIF) Frame H/W: H/W: S/W: S/W: S/W: 400 (D1) 200 (D1) 400 (CIF) 200 (CIF) 100 (CIF) - Page 10 System Monitoring and Recovery Power Restoration Power restored after AC power loss Monitoring Two independent Watchdogs (Hardware Watchdog + Software Watchdog) Automatic system rebuild Recovery DVD Alarm Standard 4 inputs Sensor Input GV-IO 12-In Card (Optional) 16 inputs GV-IO Box (Optional) 8 ~ 72 inputs Standard 4 outputs...
- Page 11 Environment 0 ~ 50 °C (32 ~ 104 °F) Operating Temp. 0 ~ 80% RH (non-condensing) Humidity Physical GV-2016S GV-2008S GV-1480S GV-1240S GV-1120S Model 4U Rackmount IPC Case Silver Color 483 (W) x 178 (H) x 528 (D) mm (19 x 7 x 21 inch)
- Page 12 PTZ Support PTZ Manufacturer & Model GV-System PTZ Option Ademco (Juptier) Ademco (Juptier) Bosch (TC700/8560) Bosch (TC700/8560) Canon VC-C3 VCC3 Canon VC-C4 VCC4 CBC GANZ (ZC-S120 Series) CBC GANZ (ZC-S120 Series) Chiper (V9KRV) Chiper (V9KRV) D-Max Version Protocol D-Max Dome DiGi Dome (DOH-240) DongYang Dome (DOH-240) / D-Max Dome Direct Perception (PTU-D46)
- Page 13 Note: This list is limited to the original models from the company mentioned above. Any third-party camera models, even claiming of the same protocol compatibility, may or may not work properly with GV-System. GeoVision takes no responsibility of such incompatibility.
- Page 14 GeoVision Optional Products Optional devices can expand your GV-DVR’s capabilities and versatility. Contact your dealer or go to GeoVision web-site for more information. GV-Video Loop Through Card This card can take the video signal from the GV-DVR and then split it into 16 signals while maintaining video quality.
-
Page 15: Warranty
GV-Data Capture V3 /V3E GV-Data Capture V3 can integrate the GV-DVR to an electronic POS system, while GV-Data Capture V3E can establish such integration through LAN or Internet. GV-Hub An easy way for serial port extension. This hub can add 4 RS-232/RS-485 serial ports through the GV-DVR’s USB port. -
Page 16: Order Information
Order Information Model Item GV-2016S GV-2008S GV-1480S GV-1240S GV-1120S 1600 / 1200 / 900 / 600 / 300 / HDD (GB) 2000 / 1600 / 1200 / 1200 / 600 / 3000 2000 1600 1600 1200 Default Single Single Single... - Page 17 * Product design and specifications are subject to change without prior notice. * All brand names are registered trademarks referred are the properties to their respective owners. * 2007 GeoVision Inc. all rights reserved. 9F, No. 246, Sec. 1, Neihu Rd.,...
