Chapter 1 Introduction

The GV-Compact DVR V2 is a mobile video recorder. It can simultaneously display real-time
images from four cameras. The recording frame rate of each channel is adjustable up to 30 /
25 fps at the resolution of 720 x 480 (NTSC) / 720 x 576 (PAL). You can access the four video
channels either in the quad mode or single channel mode.
The Anti-Vibration model of the GV-Compact DVR V2 has already been tested to withstand
severe levels of shock and vibration in mobile environments. It is perfect to be installed in any
vehicles, such as buses and vans, for surveillance and recording.
The special design of the GV-Compact DVR V2 enables you to link up with TV, VGA and spot
monitors simultaneously for direct display. The GV-Compact DVR V2 offers many features
that you can expect to have.

1.1 Features

•
Vibration and mechanical shock protection (Anti-Vibration model)
•
4-channel video and audio recording and playback
•
Up to 720 x 480 (NTSC) / 720 x 576 (PAL) recording resolution
•
Up to 120 images per second recording rate at D1 resolution
•
VGA output in high resolution (1024 x 768)
•
Independent channel resolution, quality and frame rate settings
•
Video signal auto detection
•
On-screen menu and Web-based control
•
Display video on TV, VGA and Spot Monitor simultaneously
•
Continuous, motion scheduled and input-triggered recording
•
Motion detection function with 3 sensitivity values adjustable on each channel
•
4 alarm inputs, 4 relay outputs
•
Buzzer alarm on video lost, input triggered, motion detected and disk full
•
Retrieve video by date, time and event
•
Remote playback
