12.3 Camera Power Supply
The cameras can be powered through GV-Compact DVR V2. Using the supplied Camera
Power Adaptor, connect the black wire to Pin 10 and the green wire to Pin 11.
Figure 12-3
I/O Terminal Block
Pin 10
Pin 11
The I/O Terminal Block
12
Camera Power Adaptor
Black Wire
Green Wire
147
