Disassembly

Removing the Wireless LAN Module

1. Turn off the computer, remove the battery
2. If there is a module currently installed which needs to be upgraded/replaced then remove it.
Figure 10
3. Disconnect the antenna cable
Wireless LAN
in the direction of the arrow.
Module Removal
4. The wireless LAN module
5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the slot.
a. Disconnect the cable
6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot
and pull the release
as it will go. DO NOT FORCE IT; it should fit without much pressure.
latches.
7. Press the module down towards the mainboard until the slot levers click into place to secure the module.
b. Remove the wireless
8. Replace the hard disk, hard disk cover and the 9 screws
LAN module.
a.
Antenna Cable
Connection
When re-inserting a
Wireless LAN module,
make sure the antenna
cable connects to the
connector J1 which is
indicated in Figure
10a.
4. WLAN Module
.
2 - 14 Removing the Wireless LAN Module
(page 2 - 5) and hard disk
from the wireless LAN module and gently pull the two release latches (
1
(Figure 3b) will pop-up, and you can remove it.
4
(page 2 -
b.
1
2 3
(page 2 - 11).
6).
4
& )
2 3
